Home Accents Holiday 24RTY12002414 Use And Care Manual

Safety Information
CAUTION:
Grasp the plug to insert or remove from the power source. Do not unplug by pulling on cord.
CAUTION:
The lighting string on this product is rated at 19.2 Watts (0.16 Amps). Do not overload. Do not connect to another lighting string,
decorative outfit or other electrical products. Before you use or re-use this product inspect it carefully. Discard or return to place of purchase with
purchase receipt if the product has cuts, damage, frayed wire insulation on cords, cracks in the socket enclosures, loose connections, exposed
copper wire or other obvious damage.
Pre-Assembly
Carefully remove all the parts from the box and place them on the ground. Many parts are connected by the lighting
string that runs throughout the item. Take special care not to pull, cut or damage the lighting string. Read the entire
manual prior to assembly and identify all the parts included in the package against the parts list. It is recommended
to assemble parts of the product while lying flat on the ground or a flat surface, versus standing the item up to
assemble the parts. If any parts are missing or damaged do not attempt assembly but contact our customer service
center or return to place of purchase with purchase receipt,1-855-HDHoliday (1-855-434-6543)
Assembly of this product may require more than one person.
PACKAGE CONTENTS
E
F
K
C
D
Assembly
1
Assembling the Support Poles inside the Legs to
Base Stand
Insert each Support Pole inside the Legs (H) [with the tapered end up]
into the short connecting tubes on the Base Stand (G) and secure with
the built in locking pin.
Use and Care Guide
8 ft Yuletide Lane GIANT-SIZED LED Collapsible Santa
A
J
I
G
H
H
Part
L
C
M
N
B
O
H
P
2
Assembling the Legs to Base Stand
Drape the Legs (D) over the Support Poles inside the Legs (H)
then insert the tapered end, facing up, of the Support Poles
inside the Legs (H) into the short connecting tubes on the
round metal frame at the top of the Legs (D) with the built in
locking pin. Hook the connecting rods on each foot into the
connecting holes on the Base Stand (G).
G
Please contact 1-855-HD-HOLIDAY (1-855-434-6543) for further assistance.
Item #1009466750
Model # 24RTY12002414
TOOLS REQUIRED
Description
A Halves of Hat
B Head & Body
C Arm
D Legs
E Mouth & Beard
F Tree
G Base Stand
H Support Pole inside the Legs
I Stabilizing Pole
J Support Pole inside the Body
K Support Bracket w / Arm Brackets
L Ground Stake
M Anchoring String
N Plastic Tie
O Bolt & Wingnut
P Cotter Pin
H
Plier Screwdriver
Quantity
2
1
2
1
1
1
1
2
1
1
1
8
4
20
4
4
D
H
G
