- Page 1 English Instruction and operation manual High pressure installation device For S410 and S430...
- Page 2 The device is destined exclusively for the described application. SUTO offers no guarantee for the suitability for any other purpose. SUTO is also not liable for consequential damage resulting from the delivery, capability or use of this device.
-
Page 3: Table Of Contents
Table of contents 1 Safety Instructions..............4 2 Application.................6 3 Features..................6 4 Technical Data................6 5 Dimensional Drawing..............7 6 Installation.................8 6.1 Installation Requirements............8 6.2 Installation ................8 7 Disposal of Waste..............11 High pressure installation device... -
Page 4: Safety Instructions
1 Safety Instructions 1 Safety Instructions Please check if this instruction manual accords to the product type. Please observe all notes and instructions indicated in this manual. It contains essential information which must be observed before and during installation, operation and maintenance. - Page 5 1 Safety Instructions ATTENTION! Permitted operating parameters! Observe the permitted operating parameters, any operation exceeding this parameters can lead to malfunctions and may lead to damage on the instrument or the system. • Do not exceed the permitted operating parameters. •...
-
Page 6: Application
2 Application 2 Application The high pressure installation device is designed for safety reasons. In applications where the pressure exceeds 1.6 MPa(g) the installation of a sensor must be done in combination with the high pressure installation device. This installation device is suitable for pressures up to 5 MPa(g). There are different types of installation devices depending on the sensor: •... -
Page 7: Dimensional Drawing
5 Dimensional Drawing 5 Dimensional Drawing High pressure installation device... -
Page 8: Installation
6 Installation 6 Installation Make sure that all components listed below are included in your package. Description Item No. High pressure installation device A530 1105/A530 1106 A530 1111/A530 1113 Instruction manual No P/N • The high pressure installation device is for indoor use only! At an outdoor installation, the device must be protected from solar radiation and rain. - Page 9 6 Installation 3. Turn the wing nuts to the top position. 4. Place the S401 / S450 in the holding plate as indicated. 5. Mount the connection head onto the ball valve and tighten it up with a wrench. Ensure that the O-ring is proper fitted on the ball valve.
- Page 10 6 Installation 8. Now turn the wing nuts until the sensor shaft is inserted to the correct depth. For more information, please refer to the instruction manual of the sensor. 9. Turn the counter nuts until the holdings plate is secured in the position.
-
Page 11: Disposal Of Waste
7 Disposal of Waste 7 Disposal of Waste Electronic devices are recyclable material and do not belong in the household waste. The sensor, the accessories and its packings must be disposed according to your local statutory requirements. The disposal can also be carried by the manufacturer of the product, for this please contact the manufacturer. - Page 12 SUTO iTEC GmbH SUTO iTEC (ASIA) Co., Ltd. Grißheimer Weg 21 Room 10, 6/F, Block B, Cambridge Plaza D-79423 Heitersheim 188 San Wan Road, Sheung Shui, N.T. Germany Hong Kong Tel: +49 (0) 7634 50488 00 Tel: +852 2328 9782 Email: sales@suto-itec.com...
