Power Supply Unit (PSU)
User Manual
Specification Number: 1R505500E4
Model Number: R50-5500E4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R50-5500E4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vertiv R50-5500E4

Summary of Contents for Vertiv R50-5500E4

  • Page 1 Power Supply Unit (PSU) User Manual Specification Number: 1R505500E4 Model Number: R50-5500E4...
  • Page 2 Vertiv. This document is the property of Vertiv and contains confidential and proprietary information owned by Vertiv. Any copying, use or disclosure of it without the written permission of Vertiv is strictly prohibited. Names of companies and products are trademarks or registered trademarks of the respective companies.

  • Page 3: Table Of Contents

    Power Supply Unit Current Sharing Imbalance ............................... 18 3.1.2 Power Supply Unit Fault Symptoms and Troubleshooting .......................... 18 3.2 Replacement Procedures ..............................................18 3.2.1 Power Supply Unit Module Replacement ..................................18 3.2.2 Power Supply Unit Fan Replacement ....................................19 Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 4: Admonishments Used In This Document

    (ISO) SAFETY! Informs the reader of general safety information, reminders, precautions, or policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA) Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 5: Important Safety Instructions

    ALERT! Installation or removal of equipment containing static sensitive components requires careful handling. Before handling any equipment containing static sensitive components, read and follow the instructions contained on the Static Warning Page. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 6: Static Warning

    Store and ship equipment containing static sensitive components only in static shielding containers. If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist strap, work on a conductive surface, use a grounded soldering iron, and use grounded test equipment. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 7: Introduction

    1 Introduction 1.1 Overview The R50-5500E4 Power Supply Unit provides load power and battery recharge current (if applicable) during normal operating conditions. The Power Supply Unit is rated at its maximum output power 5500W. This means that, within the normal operating ambient temperature range and input voltage range, the maximum available output power is 5500W.
  • Page 8 WARNING! The module is rated for continuous operation at full output power up to +45°C (+113°F). Operation between +45°C (+113°F) and +65°C (+149°F) is considered abnormal and should be used on a temporary basis only. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 9 5Hz to 100MHz measured across a steady-state resistive load. Measurements is made differentially using an oscilloscope with 100Mhz bandwidth limit enabled. Compliance is verified using a 0.1uF capacitor connected locally to the oscilloscope probe tips during this measurement. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 10: Ac Input Ratings

    AC operating voltage and a temperature of 25C. This specified inrush current shall not include the X- Capacitors charging. Under the above conditions, standard AC distribution circuit breakers will not trip. • Typical Input Data: Refer to Table 1.2. Typical Input Current: Refer to Table 1.2. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 11 97.31% 0.999 408.46 18.15 5006.2 97.10% 0.999 495.33 100% 20.19 5565.8 96.84% 0.999 600.07 • Efficiency Curve: (Refer to Figure 1.5) Figure 1.5 Efficiency Curve Efficiency Curve Load (% of rated load) Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 12: Dc Input Ratings

    333.42 11.73 4450.9 97.29% 411.53 13.20 5008.9 97.03% 507.55 100% 14.70 5574.7 96.70% 627.65 • Efficiency Curve: (Refer to Figure 1.6) Figure 1.6 Efficiency Curve Efficiency Curve Load (% of rated load) Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 13: Environmental Ratings

    1)Each PSU sets its SYNC_START signal to high when the PSU is ready to turn on the output. 2)Only PSU in SLOT #1 generates a random timer and set SYNC_START to high when ready and the random timer is finished. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 14: Start-Up

    When a BBU receives either one of the active AC_Loss signals, it pulls the Sync_Start_L signal low, allowing the BBU shelf to initiate immediate discharge. The output voltage of the BBU shelf ramps up to the normal setting range within 5ms. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 15: Forced Discharge Mode

    Power Supply Unit slot location 5: 100 Power Supply Unit slot location 6: 101 For shelf design with more than 1-row Power Supply Units, a 4th bit and signal pin might be defined. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 16: Random Timer And Synchronization

    Number of AC outages (can be determined by going into backup without counting the battery test conditions) Power supply event data is saved to the Black Box for the following events: Any events that caused the Main Output to shut down: Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 17: Metering Function

    Accurate reporting of input power (power factor, input current, input current harmonics and voltage) and output power (output current and voltage) readings are reported via communication system at all rated voltage. The accuracy is maintained across the operating temperature range and between 200 VAC and 305 VAC. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 18: Standard Features

    High Voltage Disable Point: 309 V AC, ±3 V AC; hysteresis is 19 V AC for restart. Low Voltage Disable Point: 180 V DC, hysteresis is 15 V DC for restart. High Voltage Disable Point: 420 V DC, hysteresis is 15 V DC for restart. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 19 Monitoring Function: The Power Supply Unit has a built-in advanced DSP that monitors and controls the operation of the Power Supply Unit. The DSP also communicates with the PMM in real time through the RS485. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 20: Mechanical Specifications

    2) Solid Amber: Primary/Secondary/Fan/bootloading Failure and/or loss of DC output▪ (refer to Power Supply Unit Modbus /Pmbus registers for specific failures) 3) No LED: fault NOT present/condition 1 and 2 are false. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 21: Operation

    Turn the power to the Power Supply Unit off or remove the Power Supply Unit, wait 30 seconds or more (until the LEDs on the Power Supply Unit extinguish), then turn the power to the Power Supply Unit on or re-insert the Power Supply Unit. 2.4 PSU Connector PIN Assignment Figure 2.2 PIN Assignment Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 22: Installing Power Supply Units

    Open-collector/drain output, internal pull up 100k and a diode to 3.3V Ground Ground 2.5 Installing Power Supply Units CAUTION! The Power Supply Unit contains double pole, neutral fusing. Disconnect mains before servicing. The fuse is non-replaceable by the customer. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 23 After the Power Supply Unit s are physically installed in the mounting shelf(s), they are ready for operation immediately after power is supplied to them. If the system is operating, ensure that there are no local or remote alarms active on the system. Figure 2.3 Installing Power Supply Unit Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 24: Troubleshooting And Repair

    Push the spring latch handle located on the front of the Power Supply Unit to the right (this will retract the securing latch located on the side of the Power Supply Unit). Pull the Power Supply Unit out of the shelf and release the spring latch handle. Proprietary and Confidential © 2025 Vertiv Group Corp.

  • Page 25: Power Supply Unit Fan Replacement

    Secure the faceplate to the Power Supply Unit chassis with the four (4) screws previously removed. Replace the Power Supply Unit into the shelf. Refer to the previous procedure for step-by-step instructions. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 26 Reinstall the Power Supply Unit and again check for proper airflow. Enable the external alarms or notify appropriate personnel that this procedure is finished. Ensure that there are no local or remote alarms active on the system. Figure 3.1 Fan Replacement Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 27 Vertiv™ Power Supply Unit User Manual This page intentionally left blank. Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 28 Vertiv™ Power Supply Unit User Manual Connect with Vertiv on Social Media https://www.facebook.com/vertivI https://www.instagram.com/vertiv/ https://www.linkedin.com/company/vertiv/ https://www.twitter.com/vertiv/ Proprietary and Confidential © 2025 Vertiv Group Corp.
  • Page 29 Vertiv.com | Vertiv Headquarters, 505 N Cleveland Ave, Westerville, OH 43082, USA © 2025 Vertiv Group Corp. All rights reserved. Vertiv™ and the Vertiv logo are trademarks or registered trademarks of Vertiv Group Corp. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
