Elite Screens Kestrel Tab-Tension 3 CineGrey 4D User Manual

Floor rising tab-tensioned motorized projector screen
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Kestrel Tab-Tension 3 CineGrey 4D
Floor Rising Tab-Tensioned Motorized Projector Screen
Ambient Light Rejecting Screen for Standard "Long" Throw Projectors
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future use. If this product is passed to a third party,
then these instructions must be included.
Elite Screens allows a 1.5% tolerance within the viewing surface for expansion and contraction of the
screen materials over time.
Caution:
The screen's Black Bottom Rise is already set to its maximum distance. There is NO
extra Black Bottom Rise in the roller. Please be aware of this as it will void your
warranty with Elite Screens
the power cord for hardwire installations) to this unit are prohibited and will void your
warranty.
 To avoid damaging the unit, do not use with any unauthorized accessories not recommended by
the manufacturer.
 Handle the unit carefully during transportation to avoid any damages.
 To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
 The power outlet supplying power to the unit should be close to the unit and easily accessible.
 Do not install the unit on uneven or inclined surfaces.
 Do not put heavy objects on the power cord and position it properly to avoid creating a trip
obstacle.
 Never overload the power cord to prevent an electric shock or fire due to a loose contact or a
short circuit.
 There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by
yourself. No one except authorized technicians can open and make repairs to this unit.
Rev. V01112025JP (DZUG0064)
User's Guide – E/H Type (RC1 V1.0)
Visit
www.elitescreens.com
®
. Unapproved changes or modifications (except for cutting
www.elitescreens.com
(For models below 150")
for latest updated version.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kestrel Tab-Tension 3 CineGrey 4D and is the answer not in the manual?

Questions and answers

Related Manuals for Elite Screens Kestrel Tab-Tension 3 CineGrey 4D

Summary of Contents for Elite Screens Kestrel Tab-Tension 3 CineGrey 4D

  • Page 1 Read these instructions carefully and retain them for future use. If this product is passed to a third party, then these instructions must be included. Elite Screens allows a 1.5% tolerance within the viewing surface for expansion and contraction of the screen materials over time.
  • Page 2 Keep away from children when the screen is in operation.  WARNING Individual modifications to this product are prohibited and will void the manufacturer’s warranty. Please contact the Elite Screens Customer Service Team with any questions. ® SCREEN MAINTAINANCE Dust, dirt, and scratches on the projection screen surface will affect the quality and performance of the projection image.

  • Page 3: Parts Identification

    User’s Guide Kestrel Tab-Tension 3 Series FCC Regulatory Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Screen Operation

    User’s Guide Kestrel Tab-Tension 3 Series Back of screen Closing Panel/Lid Cross-rising spring scissor mechanism Case/Housing Feet Note: Please always store the screen flat horizontally. Never store the screen in a vertical position as it will permanently damage the screen’s structure, shift the material, and cause wrinkles/folds which will void the warranty.

  • Page 5: Back View

    User’s Guide Kestrel Tab-Tension 3 Series 5 ways to control your Kestrel Tab-Tension 3 Screen 1. IR Remote Control (Item A, Fig.1): The Infrared functions by direct line of sight contact using an effective beam range of 25 feet within a 30-degree angle. Aim the IR remote directly at either the IR receiver on the Wall Box Controller.
  • Page 6 User’s Guide Kestrel Tab-Tension 3 Series 3. Wall box controller (Item C, Fig.3): The wall box controller switch is a wall mounted control box with an up/stop/down button. Plug one end of the RJ50 cable (Item D) to the wall box controller and the other to the screen’s RJ50 port.
  • Page 7 User’s Guide Kestrel Tab-Tension 3 Series Here’s how to set up your Wireless 5-12 volt trigger The 5-12V wireless trigger should already be synced and ready to work. Step1: Connect one end of the 3.5 mm mono trigger cable to the RF remote. Step 2: Connect the other 3.5 mm mono end of the cable to your projector Step 3: Turn on the projector and the screen should automatically deploy.
  • Page 8 Note: Improper installation will result in light loss and produce a foggy image. This is due to the projector’s light reflecting in the wrong direction. Images are not up to scale and are for illustrations purposes only For more information, technical support or your local Elite Screens ® contact, http://www.elitescreens.com/...
