Elite Screens ZU12V1 User Manual

1. Product
(1) Product introduction: The ZU12V1 is a wireless 5-12 volt trigger for projectors that don't have a dedicated trigger port.
It is compatible only with Elite motorized screens with the RC1 control system to drop/rise or rise/drop automatically
using the projector's power cycle. It connects to the projector's power port to send a radio frequency signal to the Elite
motorized screen.
(2) Schematic diagram of the trigger:
Button1 (Learning)
Button2 (Pairing)
Button3 (Function)
2. Instructions
Before starting the process, unplug the Elite motorized screen and projector from the power supply. Then, unplug the
power cord of the projector and connect it to the trigger, then work on the code pairing.
①
Code learning:
(Pairing with screen)
Button1
1.
Button2
2.
Button3
3.
4.
Note: After using ZU12V1 to learn the code, the RF code on the back of the RF remote control must be
Projector power cord
adjusted to "000" mode and then can continue using it.
Projector
②
Learning:
(Setup with projector)
Button1
Button2
1. Connect ZU12V1 to the projector.
Button3
2. With the projector power off, press and hold Button 1 (Learning) for 3 seconds. A faint red light
3. Turn on the projector, and the light will stop blinking and stay on. The screen will deploy to
4. Final step, turn off the projector, and the red light will turn off.
Rev. V05232024BR (DZUG0324)
Plug in the power cord of the projector to the power supply.
Plug your projector screen to the power supply
Plug in Wall Box to the Screen's RJ50, then press and hold the "Program" key + "UP" key on wall box
to enter the learning mode. Red light will begin to blink.
Press and hold the ZU12V1 Button 2 (Pairing) for 3 seconds. The red light on the wall box will disappear
confirming that the code learning is successful.
will begin to flash.
confirm a successful pairing.
ZU12V1 Wireless Trigger
Trigger Operation Diagram
User's Guide
(H type)
