- Page 1 Yard Master Lite Series Ultra-Portable Outdoor Projector Screen User’s Guide 125” (16:9) Visit www.elitescreens.com/ymlite-assemble Scan QR code for our how to assemble video Rev.11162021JA www.elitescreens.com...
- Page 2 Warning ▪ The warranty will only be valid if screen is used for its intention. Misuse, abuse, negligence, accidental damage, or damages caused by environmental factors are not covered under warranty. ▪ Improper use and operation may cause serious injury and / or damage to the screen, use only as directed.
- Page 3 Assembly Join 4x “A” tubes with the straight joint “D” to assemble each top/bottom crossbar. Join 2 x “B" tubes and 1 x “C" tube together using a straight joint “D” and a T-joint “F” to assemble the left/right sides. Note: Top side has tethering loops...
- Page 4 Attach and secure the joints at both ends of the top/bottom crossbars. Insert the L/R sides through the material and secure to the joints. Note: Use the tethering rope and stakes to stabilize the screen on grass or soil ground. 4 stakes used on base and 4 stakes used...
- Page 5 Disassembly Remove the stakes from the tethering ropes and base. Then remove the tethering ropes from the screen. Remove the pins, pull out the L/R posts from the base and remove the water bags. Rev.11162021JA www.elitescreens.com...
- Page 6 Remove the elbow joints at both ends of the top crossbar and slide both top/bottom crossbars out of the screen. Disassemble the L/R posts by disjointing the straight and T-joints. Disassemble the Top/Bottom posts by disjointing the straight joints. Rev.11162021JA www.elitescreens.com...
