Evanesce Tab-Tension B CineGrey 5D®
Recessed In-Ceiling Ambient Light Rejecting Projection Screen
This user manual is written for the comprehension of licensed professional
installers/integrators experienced in building and electrical wiring codes.
DIY "do -it-yourself" enthusiasts should consult a professional for assistance
Congratulations on your new Evanesce Tab-Tension B CineGrey 5D purchase! The screen material included is
our award winning ISF Certified CineGrey 5D™ which is a front projection material, precisely formulated for
environments with minimal control over room lighting. It was designed to enhance picture brightness, offer
accurate color fidelity, and improve contrast levels. The CineGrey 5D™ is best for family rooms, educational
facilities, conference rooms, house of worship or any applications in which incident light is a factor.
In order for the CineGrey 5D™ to maintain its projection qualities and optimum performance please refer to the
list below for proper maintenance and cleaning.
• Use a dry microfiber cloth to remove dust from the screen's surface.
• When cleaning, use a damp microfiber cloth with warm water to remove any marks.
• Never rub or apply pressure when cleaning the surface.
• Never attempt to use any solutions, chemicals or abrasive cleaners on the screen surface.
• In order to avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any
other sharp or abrasive objects.
JA09252018
User's Guide
This Product is Designed for Integrators
1
www.elitescreens.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite Screens Evanesce Tab Tension B CineGrey 5D
Summary of Contents for Elite Screens Evanesce Tab Tension B CineGrey 5D
- Page 1 Evanesce Tab-Tension B CineGrey 5D® Recessed In-Ceiling Ambient Light Rejecting Projection Screen User’s Guide This Product is Designed for Integrators This user manual is written for the comprehension of licensed professional installers/integrators experienced in building and electrical wiring codes. DIY “do -it-yourself” enthusiasts should consult a professional for assistance Congratulations on your new Evanesce Tab-Tension B CineGrey 5D purchase! The screen material included is our award winning ISF Certified CineGrey 5D™...
-
Page 2: Pre-Installation
Important Safety & Warning Precautions Make sure to read this user’s guide and follow the procedures below. Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black Top Drop in the roller. Please be aware of this as it will void your warranty. Unapproved changes or modifications (except for cutting the power cord for hardwire installations) to this unit are prohibited and will void your warranty. -
Page 3: Installation Warning
Installation Warning Due to various installation environments, the instructions provided in this user’s guide are for reference only. Please consult a professional installation company for further installation and safety advice. The installer must insure that proper mounting hardware is used to provide adequate strength suitable for the installation. Individual modifications to this product are prohibited and will void the manufacturer warranty. -
Page 4: Installation
Installation IMPORTANT! 1. Make sure the ceiling structure can support the screen’s weight. (31.2 kgs/68.7 lbs). 2. It is strongly recommended to provide a 6” x 12” access panel at the left end of the screen’s case to access the left side of the screen. Minimum space requirement If possible, measure the height from the ceiling structure to the bottom of the drywall/sheetrock or the location of where the screen will be installed. - Page 5 Screen Installation (Requires two or more people) 6. Once the Threaded rods (G) are secured in the Ceiling hanging brackets (D), Fig. 7, hang the screen from the threaded rods one side at a time through the mounting hole tabs located on the side end of the screen’s case, Fig.
-
Page 6: Screen Operation
8. Once the end covers (F) have been attached, finally insert the End cover caps (E) to conclude the installation. Fig 14 Fig 13 Cover the end cover holes with the end cover caps Standard controls included with the Evanesce Tab-Tension 2 CineGrey 5D C. - Page 7 2. RF remote control: The RF remote does not require line-of-sight and can be used up to 50ft. Press the Down button to Drop the screen Press the Stop button to Stop the screen Press the UP button to Retract the screen How to program your RF remote to your screen Press and hold the UP button Stop pressing the UP button upon...
- Page 8 DO NOT overtighten the strings as this will cause them to snap and void your warranty. Screen material Tension string Adjustment Push tab knob Adjustment knob Weight bar For Additional Service, Please Contact Elite Screens Technical Support, Email: techsupport@elitescreens.com JA09252018 www.elitescreens.com...
