QUICK START
GUIDE
ASR-2000
ASR-2050/2100
ASR-2050R/2100R
EN
ISO-9001 CERTIFIED MANUFACTURER

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASR-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GW Instek ASR-2000

Summary of Contents for GW Instek ASR-2000

  • Page 1 QUICK START GUIDE ASR-2000 ASR-2050/2100 ASR-2050R/2100R ISO-9001 CERTIFIED MANUFACTURER...
  • Page 2 This quick start guide contains proprietary information, which is protected by copyright. All rights are reserved. No part of this quick start guide may be photocopied, reproduced or translated to another language without prior written consent. The information in this quick start guide was correct at the time of printing. However we continue to improve our products and therefore reserve the right to change the specifications, equipment, and maintenance procedures at any time without notice.

  • Page 3: Afety Instructions

    AFETY INSTRUCTIONS Safety Symbols These safety symbols may appear in the user manual or on the instrument. Warning: Identifies conditions or practices that could result Warning in injury or loss of life. Caution: Identifies conditions or practices that could result Caution in damage to the instrument or to other properties.

  • Page 4: Etting Started

    ETTING STARTED Main Features Performance • Maximum AC output voltage is 350 Vrms • Maximum DC output voltage is 500 Vdc • Maximum output frequency is 999.9 Hz in AC mode • Supported AC+DC waveform application • DC full capacity output ability •...
  • Page 5 Appearance Front Panel Overview 17 16 19 18 Description 1. Power switch 2. Air Inlet 3. LCD Screen 4. V and V-Limit key 5. F and F-Limit key 6. Irms and IPK-Limit key 7. Range Key 8. Display Mode Select Key 9.
  • Page 6 Rear Panel Overview Description 1. GPIB Connector 2. RS232C Connector (25 pins Micro-D) 3. Ethernet Port 4. USB Port 5. External Control I/O Connector 6. Exhaust Fan 7. Remote Sensing Input Terminal 8. Output Terminal 9. AC Line Input 10. External Signal Input Connector www.gwinstek.com...
  • Page 7 ET UP Power Up 1. Connect the power cord to the rear panel socket. 2. Press the POWER key. The splash screen will appear momentarily before the continuous mode screen appears with the settings loaded. The power supply takes around 15 seconds to fully turn on and shutdown.
  • Page 8 How to Use the Instrument Background The ASR AC power supplies generally use the scroll wheel, Arrow keys and Enter keys to edit numerical values or to select menu options. Menu navigation is performed using the menu keys and function keys on the front panel.
  • Page 9 Using the Arrow Use the Arrow keys to select a digit power and then Keys and Scroll use the scroll wheel to edit the value by that power. Wheel to Edit Parameter Values Use the Arrow keys to move the cursor to the digit of the desired value.
  • Page 10 Using the The function keys are quick settings keys, the function of Function Keys which depends on the current menu or operation. Press the Function key that corresponds to the setting directly to its left side. The setting or parameter is immediately executed.
  • Page 11 TATUS BAR Status bar Indicates if the output is ON or OFF. Indicates the output power as a percentage of full scale. Indicates if the output range is 100V, 200V or AUTO. Indicates if the output waveform is Sine, Square, Triangle or ARB 1 - 16.
  • Page 12 UTPUT TERMINALS Rear Panel The rear panel output is used to supply higher power DUTs. Output Connection Disconnect the unit from the mains power socket and turn the power switch off. Remove the protective lid from the output terminals by loosening the screw.
  • Page 13 Cover the protective lid onto the output terminals as the figure below shown. Fasten the screw of protective lid with the unit. Turn the power on. The AC power supply is now ready to power the DUT. Grounded Neutral Output: Note ASR allows for a grounded return on the neutral output.
  • Page 14 Grounding The output terminals of the ASR are isolated with respect to the protective grounding terminal. The insulation capacity of the load, the load cables and other connected devices must be taken into consideration when connected to the protective ground or when floating. Grounded Basically, grounded return on the neutral output is allowed Neutral Output...
  • Page 15 PECIFICATIONS General Specifications Interface Standard Type A: Host, Type B: Device, Speed: 1.1/2.0, USB-CDC MAC Address, DNS IP Address, User Password, Gateway IP Address, Instrument IP Address, Subnet Mask External Signal Input Control External Control I/O RS232C Complies with the EIA-RS232 specifications ASR- GPIB...
  • Page 16 Environment Operating Indoor use, Overvoltage Category II environment Operating 0 °C to 40 °C temperature range Storage -10 °C to 70 °C temperature range Operating humidity 20 % RH to 80 % RH (no range condensation) Storage humidity 90 % RH or less (no condensation) range Altitude Up to 2000 m...
  • Page 17 NFORMATION OF NAME ORDER The name order of ASR-2000 series has its rules in definition for each character by order. Refer to the following contents for details. Background The definitions below describe the meanings behind each group of alphanumeric characters, in varied colors, of naming code for ASR models.
  • Page 18 eclaration of Conformity GOOD WILL INSTRUMENT CO., LTD. declare that the below mentioned product satisfies all the technical relations application to the product within the scope of council: Directive: EMC; LVD; WEEE; RoHS The product is in conformity with the following standards or other normative documents ◎...
