Summary of Contents for GW Instek AFG-3000

  • Page 1 任意波形訊號產生器 AFG-3000 系列 使用手冊 固緯料號 NO. ISO-9001 認證企業 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 2 2010.10 本手冊所含資料受到版權保護,未經固緯電子實業股份有限公司預 先授權,不得將手冊內任何章節影印、複製或翻譯成其它語言。 本手冊所含資料在印製之前已經過校正,但因固緯電子實業股份有 限公司不斷改善產品,所以保留未來修改產品規格、特性以及保養 維修程式的權利,不必事前通知。 固緯電子實業股份有限公司 臺灣臺北縣土城市中興路 7-1 號 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 3: Table Of Contents

    目錄 目錄 安全說明 ............6 產品介紹 ............10 主要特點 ..............10 面板介紹 ..............12 設置訊號產生器 ............18 快速操作 ............20 如何使用數位輸入 ............ 22 如何使用說明功能表 ..........23 選擇波形 ..............25 調製 ................27 掃描 ................31 脈衝串 ..............33 ARB ................35 工具功能表...
  • Page 4 AFG-3000 系列使用手冊 脈衝串模式 ............. 108 輔助系統功能設置 ........119 存儲和調取 ............. 120 選擇遠端介面 ............123 系統和設置 ............. 127 任意波形 ............. 133 插入內置波形 ............135 顯示任意波形 ............148 編輯任意波形 ............155 輸出任意波形 ............164 存儲/調取任意波形 ..........170 遠端介面 ............. 178 確立遠端連接 ............179 指令語法...
  • Page 5 目錄 錯誤資訊 ..............270 SCPI 狀態寄存器 ............. 284 附錄 ............. 290 保險絲更換 ............. 290 AFG-3000 系列規格 ..........291 EC 符合性聲明書 ............. 297 索引 ............. 298 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 6: 安全說明

    AFG-3000 系列使用手冊 安 全說明 本章節包含操作和存儲訊號產生器時必須遵照的重 要安全說明。在操作前請詳細閱讀以下內容,確保 安全和優化的使用。 安全符號 這些安全符號會出現在本使用手冊或 AFG-3000 上。 警告:產品在某一特定情況下或實際應用中可能對 警告 人體造成傷害或危及生命 注意:產品在某一特定情況下或實際應用中可能對 注意 產品本身或其它產品造成損壞 高壓危險 注意: 請參考使用手冊 保護導體端子 接地端子 表面高溫危險 雙層絕緣 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 7 勿將易燃物置於儀器上 注意  避免嚴重撞擊或不當放置而損壞儀器  避免靜電釋放至儀器  請使用匹配的連接線,切不可用裸線連接  若非專業技術人員,請勿自行拆裝儀器 (測量等級) EN 61010-1:2001 規定了如下測量等級,AFG-3000系 列屬於等級II。  測量等級 IV:測量低電壓設備電源  測量等級 III:測量建築設備  測量等級 II: 測量直接連接到低電壓設備的電路  測量等級 I: 測量未直接連接電源的電路 交流輸入電壓: 100 ~ 240V AC, 50 ~ 60Hz 電源  ...
  • Page 8 AFG-3000 系列使用手冊 操作環境  地點: 室內,避免陽光直射,無灰塵,無導電污染 (下注),避免強磁場 相對濕度: < 80%  海拔: < 2000m  溫度: 0°C~40°C  (污染等級) EN 61010-1:2001 規定了如下污染程度。AFG-3000 系 列屬於等級 2。 污染指“可能引起絕緣強度或表面電阻率降低的外界物質,固 體,液體或氣體(電離氣體)”。  污染等級 1:無污染或僅乾燥,存在非導電污染,污染無影響  污染等級 2:通常只存在非導電污染,偶爾存在由凝結物引起 的短暫導電  污染等級 3:存在導電污染或由於凝結原因使乾燥的非導電性 污染變成導電性污染。此種情況下,設備通常處於避免陽光 直射和充分風壓條件下,但溫度和濕度未受控制 存儲環境...
  • Page 9 安全說明 英制電源線 在英國使用訊號產生器時,確保電源線符合以下安全說明。 注意: 導線/設備連接必須由專業人員操作 警告: 此裝置必須接地 重要: 導線顏色應與下述規則保持一致: 綠色/黃色: 接地 藍色: 零線 棕色: 火線(相線) 導線顏色可能與插頭/儀器中所標識的略有差異,請遵循如下操作: 顏色為綠色/黃色的線需與標有字母“E”,或接地標誌 ,或顏色為綠色/黃綠 色的接地端子相連; 顏色為藍色的線需與標有字母“N”,或顏色為藍色或黑色的端子相連; 顏色為棕色的線需與標有字母“L”或“P”,或者顏色為棕色或紅色的端子相 連; 若有疑問,請參照本儀器提供的用法說明或與經銷商聯繫。 電纜/儀器需有符和額定值和規格的 HBC 保險絲保護:保險絲額定值請參照儀 器說明或使用手冊。如: 0.75mm 的電纜需要 3A 或 5A 的保險絲。保險絲型號 與連接方法有關,再大的導體通常應使用 13A 保險絲。 在移動保險絲或保險絲座時連接器定會被損壞,然而將帶有裸線的插 頭插入火線插座是非常危險的。若需重複連接,必須嚴格按照本手冊 說明操作。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 10: 產品介紹

    AFG-3000 系列使用手冊 產 品介紹 本章節介紹了訊號產生器的主要特點、外觀、設置 過程和開機。 主要特點 型號 頻寬 AFG-3081 80MHz AFG-3051 50MHz 性能 DDS 信号发生器系列  全频段 1μHz 高频分辨率  1ppm 频率稳定度  任意波形能力  200 MSa/s 采样率  100 MSa/s 重复率  1 M 点波形长度  16 位幅值分辨率...
  • Page 11 產品介紹 正弦波, 方波, 斜波, 脈衝波, 雜訊波, Sinc 標準波 特點  形 內部和外部 LIN/LOG 掃描,帶標記輸出  內部/外部 AM, FM, PWM, FSK 調製   調製/掃描訊號輸出  內部和外部觸發的脈衝串訊號,無標記輸出 存儲/調取 10 組設置記憶體   輸出超載保護 GPIB, RS232, USB 標準介面 介面  4.3’’彩色 TFT LCD (480 × 272)使用者介面 ...
  • Page 12: 面板介紹

    AFG-3000 系列使用手冊 面板介紹 前面板 LCD Display Number Scroll Wheel Selection Power Switch keys AFG-3081 Arbitrary Function Generator Output SYNC Terminals MAIN MAIN Output Waveform FREQ/Rate AMPL DC Offset UTIL Output key Sweep Burst Preset Function keys Operation Output USB port...
  • Page 13 產品介紹 用於設置任意波形參數 MOD, Sweep 和 Burst 鍵用於設置 調製、掃描和脈衝串選項和參數 Sweep Burst 復位鍵 用於調取預設狀態 Preset 輸出鍵 用於打開或關閉波形輸出 Output 輸出指示燈 當輸出指示燈變綠,輸出啟動 USB host 介面 用於存儲、還原波形資料和圖像, 以及更新固件 輸出端子 調製輸出端子 SYNC 輸出端子。50Ω 輸出阻抗。 SYNC 主輸出端子。50Ω 輸出阻抗。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 14 AFG-3000 系列使用手冊 待機鍵 使訊號產生器處於開機(綠色)或待 機模式(紅色) 方向鍵 當編輯參數時,可用於選擇數位 可調旋鈕 用於編輯值和參數 減小 增加 用於鍵入值和參數,常與方向鍵和 數位鍵盤 可調旋鈕一起使用 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 15 產品介紹 後面板 Trigger Mark output Power socket and Power Switch Input fuse DISCONNECT POWER CORD AND TEST LEADS BEFORE REPLACING FUSE SER.NO. LABEL FUSE RATING AC 250V T 0.63A USB Port RS232 INPUT OUTPUT Trigger MARK 240V 60Hz 65VA WARNING GPIB Trigger TO AVOID ELECTRIC SHOCK THE POWER CORD...
  • Page 16 AFG-3000 系列使用手冊 Mini-B 類 USB 介面用於連接 PC 機 USB 介面 和遠端控制 9 針母頭 RS232 插孔用於 PC 遠程控 RS232 RS232 介面 制 24 針母頭 GPIB 介面用於 GPIB GPIB PC 遠端控制 觸發輸出 Trigger 觸發輸出端子 MOD 輸入 調製輸入端子 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 17 產品介紹 顯示 Parameter Windows Status Tabs Waveform Display Soft Menu Keys 參數窗口 參數顯示和編輯視窗 狀態功能表 顯示調製、掃描和脈衝串模式的狀態 波形顯示 用於顯示波形 軟選單鍵 功能鍵(F1~F6)與下方的軟選單鍵對應 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 18: 設置訊號產生器

    AFG-3000 系列使用手冊 設置訊號產生器 背景 本章節介紹了如何調整訊號產生器的把手以及如何 開機。 調整把手 將把手拉至側面並旋 AFG-3081 Arbitrary Function Generator 轉 SYNC Output Waveform FREQ/Rate AMPL DC Offset UTIL Sweep Burst Preset 水準放置 AFG 或傾斜放置 手把垂直放置以方便 手提 1. 將電源線接入後面板插座 開機 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 19 產品介紹 2. 打開位於後面板的電源開關 3. 按下前面板的待機鍵打開儀 器,待機鍵將由紅(待機)轉 待機 打開 綠(打開) 4. 當待機鍵為綠色時,螢幕顯示載入狀態 此時,訊號產生器已經可以使用。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 20 AFG-3000 系列使用手冊 快 速操作 本章節介紹了 AFG-3000 的快捷方式、內置說明和預設出廠設置,方 便用戶快速入門。有關參數、設置和限制的詳細內容,參見操作章節 或規格(291 頁)。 如何使用數位輸入 ............. 22 如何使用說明功能表 ............23 選擇波形 ................25 方波 ..................25 三角波 .................. 25 正弦波 .................. 26 調製................... 27 AM ..................27 FM ..................28 FSK 調製 ................29 PWM 調製...
  • Page 21: 快速操作

    快速操作 選單樹 ................42 波形 ..................43 ARB-顯示 ................43 ARB-編輯 ................44 ARB–內置 ................45 ARB–內置–更多 ..............46 ARB–存儲 ................47 ARB-調取 ................47 ARB-輸出 ................48 MOD ..................49 掃描 ..................49 掃描–更多 ................50 脈衝串–N 次迴圈 ..............51 脈衝串–門控...
  • Page 22: 如何使用數位輸入

    AFG-3000 系列使用手冊 如何使用數位輸入 AFG-3000 有三類主要的數位輸入: 數位鍵盤, 方向鍵 背景 和可調旋鈕。下面將為您介紹如何使用數字輸入編 輯參數。 1. 按(F1~F6)對應功能鍵選擇選單項。例如,功能 鍵 F1 對應軟鍵“Sine” 2. 使用方向鍵將游標移至需要 編輯的數位 3. 使用可調旋鈕編輯數位。順 時針增大,逆時針減小 4. 數位鍵盤用於設置高光處的 參數值 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 23: 如何使用說明功能表

    快速操作 如何使用說明功能表 背景 說明功能表詳細描述了每個鍵的含義和它的功能 1. 按 UTIL UTIL 2. 按 System (F5) System 3. 按 Help (F3) Help 4. 可調旋鈕用於導航說明選 單。按 Select 選擇該項 Keypad 用於解釋任一前面板鍵 Create Arbitrary 解釋如何建立任意波形 Waveform Modulation 解釋如何建立調製波形 Function Sweep Function 解釋掃描功能 Burst Function 解釋脈衝串功能 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 24 AFG-3000 系列使用手冊 DSO Link 提供 DSO 連接 Hardcopy 解釋如何使用硬拷貝功能 5. 例如,選擇專案 4 可以查看掃描功能 6. 可調旋鈕用於導航說明頁面 7. 按 F6 返回上級選單 Return 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 25: 選擇波形

    快速操作 選擇波形 方波 例子: 方波, 3Vpp, 75%占空比, 1 kHz 1. 按 Waveform 鍵, 選 輸出 Waveform Square 擇 Square (F2) 2. 分別按(F1), 7 + 5 + Duty %(F5) 3. 分別按 Freq/Rate, 1 輸入: N/A FREQ/Rate + kHz (F5) 4. 分別按 AMPL, 3 + AMPL VPP (F6) 5.
  • Page 26 AFG-3000 系列使用手冊 正弦波 例子: 正弦波, 10Vpp,100kHz 1. 按 Waveform 鍵, 選 輸出 Sine Waveform 擇 Sine (F1) 2. 分別按 Freq/Rate FREQ/Rate 鍵, 1 + 0 +0 + kHz (F5) 輸入: N/A 3. 分別按 AMPL 鍵, 1 AMPL + 0 +VPP (F6) 4.
  • Page 27 快速操作 調製 例子: AM 調製. 100Hz 調製方波. 1kHz 正弦載波. 80%調製深度 1. 按 MOD 鍵, 選擇 輸出 AM (F1) 2. 按 Waveform, 選擇 Sine Waveform Sine (F1) 3. 分別按 Freq/Rate 輸入: N/A FREQ/Rate 鍵, 1 + kHz (F5) 4. 按 MOD 鍵, 選擇 Shape AM (F1), Shape (F4), Square...
  • Page 28 AFG-3000 系列使用手冊 10. 按 Output 鍵 Output 例子: FM 調製. 100Hz 調製方波, 1kHz 正弦載波, 100 Hz 頻移, 內部源 1. 按 MOD 鍵, 選擇 輸出 FM (F2) 2. 按 Waveform, 選擇 Sine Waveform Sine (F1) 3. 分別按 Freq/Rate 輸入: N/A FREQ/Rate 鍵, 1 + kHz (F5)
  • Page 29 快速操作 10. 按 Output 鍵 Output FSK 調製 例子: FSK 調製, 100Hz 跳躍頻率, 1kHz 載波, 三角波, 10 Hz 頻率, 內 部源 1. 按 MOD 鍵, 選擇 輸出 FSK (F3) 2. 按 Waveform, 選擇 Triangle Waveform Triangle (F3) 3. 分別按 Freq/Rate 輸入: N/A FREQ/Rate 鍵, 1 + kHz (F5)
  • Page 30 AFG-3000 系列使用手冊 PWM 調製 例子: PWM 調製, 800Hz 載波, 15 kHz 調製正弦波, 50%占空比, 內部 源 1. 按 Waveform, 選擇 輸出 Square Waveform Square (F2) 2. 按 MOD 鍵, 選擇 PWM (F4) 3. 分別按 Freq/Rate 輸入: N/A FREQ/Rate 鍵, 8 + 0 + 0 + Hz (F4) 4.
  • Page 31 快速操作 掃描 例子: 頻率掃描. 起始頻率 10mHz, 截止頻率 1MHz. Log 掃描, 1 s 掃 描, 標記頻率 550 Hz, 手動觸發, 上升沿觸發 1. 按 Sweep, Start (F3) 輸出 Start Sweep 2. 按 1 + 0 + mHz (F2) 3. 按 Sweep, Stop (F4) Stop Sweep 4.
  • Page 32 AFG-3000 系列使用手冊 11. 按 Output 鍵 Output 12. 按 Sweep, Source Source Manual Sweep (F1), Manual (F3), Trigger Trigger (F1) 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 33: 脈衝串

    快速操作 脈衝串 例子: 脈衝串模式, N 次迴圈(內部觸發), 1kHz 脈衝串頻率, 脈衝串數= 5, 10 ms 脈衝串週期, 0˚脈衝串相位, 內部觸發, 10 us 延遲, 上升沿觸發 1. 按 FREQ/Rate 1 輸出 FREQ/Rate kHz (F5) 2. 按 Burst, N Cycle N Cycle Cycles Burst (F1), Cycles (F1) 3. 按 5 + Cyc (F5) 輸入: N/A 4.
  • Page 34 AFG-3000 系列使用手冊 11. 按 Burst, N Cycle N Cycle TRIG setup Burst (F1), TRIG Setup TRIG out ON/OFF Rise (F5), TRIG out (F5), ON/OFF (F3), Rise (F1) 12. 按 Output 鍵 Output 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 35: Arb

    快速操作 ARB–增加內置波形 例子: ARB 模式, 上升指數函數. Start 0, Length 100, Scale 32767 1. 按 ARB, Built in 輸出 Built in More (F3), More (F5), Exp Exp Rise Rise (F1) 2. 按 Start (F1), 0 + Start Enter Enter (F5), Return (F6) Return 3.
  • Page 36 AFG-3000 系列使用手冊 3. 按 Duty (F2), 25, Duty %(F5), Return (F6) Return 4. 按 Scale (F3), 32767, Scale Enter (F5), Return (F6), Done (F4) Enter Return Done ARB-增加點 例子: ARB 模式, 增加點, 位址 40, 資料 30,000 1. 按 ARB, Edit (F2), 輸出...
  • Page 37 快速操作 3. 按 Start Data (F2), 3 Start Data + 0, Enter (F5), Return (F6) Enter Return 4. 按 Stop ADD (F3), 5 Stop ADD + 0, Enter (F5), Return (F6) Enter Return 5. 按 Stop Data (F4), 1 Stop Data + 0 + 0, Enter (F5), Return (F6), Done Enter...
  • Page 38 AFG-3000 系列使用手冊 2. 按 Start (F1), 0 + Start Enter Enter (F5), Return (F6) Return 3. 按 Length (F2), 1 + 0 Length + 0, Enter (F5), Return (F6) Enter Return 4. 按 N Cycle (F4) N Cycle 5. 按 Cycles (F1), 1 + 0 Cycles 6.
  • Page 39 快速操作 ARB–輸出標記 例子: ARB 模式, 輸出標記, Start 0, Length 80 1. 按 ARB, Output 輸出 Output Marker (F6), Marker (F3) OUTPUT MARK 2. 按 Start (F1), 3+0, Start Enter (F5), Return (F6) Enter Return 3. 按 Length (F2), 8 + Length 0, Enter (F5), Return (F6)
  • Page 40: 工具功能表

    AFG-3000 系列使用手冊 工具功能表 存儲 例子: 存儲至記憶體檔#5 1. 按 UTIL, Memory Memory Store UTIL (F1), Store (F1) 2. 使用可調旋鈕和 Select (F1)選擇檔, Select Done 按 Done (F5) 調取 例子: 調取記憶體檔#5 1. 按 UTIL, Memory Memory Recall UTIL (F1), Recall (F2) 2. 使用可調旋鈕和...
  • Page 41 快速操作 介面 RS232 例子: RS232 介面, 串列傳輸速率 115200, 無奇偶性, 8 位 1. 按 UTIL, Interface RS232 Interface RS232 UTIL RS232 (F2), RS232 (F2) 2. 按串列傳輸速率(F1), Baud Rate 115k 115k (F5) 3. 按 UTIL, Interface Interface RS232 UTIL (F2), RS232 (F2) 4.
  • Page 42: 選單樹

    AFG-3000 系列使用手冊 選單樹 常規 使用者可以將功能表樹用作對訊號產生器的功能和 特性的簡易參考。AFG-3000 功能表系統逐層排列, 每層都由操作或軟鍵導航。返回軟鍵用於返回上級 選單。 例子: 將奇偶性設置為偶數/7Bits; (1) 按 UTIL 鍵 (2) Interface 軟鍵 (3) RS232 (4) 奇偶性/Bits (5) 偶數/7Bits UTIL Level 1 Interface Level 2 Level 3 GPIB RS-232 Return Address Baud Rate Level 4...
  • Page 43 快速操作 波形 Waveform Sine Square Triangle Pulse Ramp Noise Width Duty nSEC Return uSEC Return mSEC Return ARB-顯示 Display Horizon Vertical Next Page Back Page Overview Return Start Clear Clear Enter Enter Return Return Length High Clear Clear Enter Enter Return Return Center...
  • Page 44 AFG-3000 系列使用手冊 ARB-編輯 Edit Point Line Copy Clear Protect Return Address Start ADD Start Start Done Clear Clear Clear Clear Enter Enter Enter Enter Start Return Return Return Return Clear Data Start Data Length Length Enter Return Clear Clear Clear...
  • Page 45 快速操作 ARB–內置 Built in Sine Square Ramp Sinc More Return Go to ARB Start Start Start Start Built in - Clear Clear Clear Clear Enter Enter Enter Enter More Return Return Return Return Length Length Length Length Clear Clear Clear Clear Enter Enter...
  • Page 46 AFG-3000 系列使用手冊 ARB–內置–更多 Built in More Exp Rise Exp Fall Pulse Return Start Start Start Freq Clear Clear Clear Enter Enter Enter Return Return Return Length Length Length Clear Clear Clear Return Enter Enter Enter Duty Return Return Return Scale...
  • Page 47 快速操作 ARB–存儲 Save Start Length Memory Return Clear Clear Select Select Enter Enter Return New Folder Return Return Enter Char Back Space Save Return New File Enter Char Back Space Save Return Return ARB-調取 Load Memory Done Return Clear Select Select Enter Return...
  • Page 48 AFG-3000 系列使用手冊 ARB-輸出 Output Start Length Marker N Cycle Infinite Return Clear Clear Start Cycles Enter Enter Clear Clear Return Return Enter Enter Return Return Length Trigger Return Clear Enter Return Return 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 49 快速操作 Source Source Source Source Return Return Return Return Depth Freq Dev Hop Freq Duty Return Return AM Freq PWM Freq Return Return FM Freq FSK Rate Return Return Shape Shape Sine Sine Square Square Return Triangle Triangle Return Shape UpRamp UpRamp Return...
  • Page 50 AFG-3000 系列使用手冊 掃描–更多 Sweep More Span Center Marker TRIG out Return Freq Rise Fall ON/OFF Return Return Return Return ON/OFF Return 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 51 快速操作 脈衝串–N 次迴圈 Burst N Cycle Cycles Infinite Phase Period TRIG Setup Return Clear Clear uSEC Degree mSEC Return Return Rise Return Fall Return Manual Trigger Return Delay nSEC uSEC mSEC Return TRIG out Rise Fall ON/OFF Return Return 脈衝串–門控 Burst Gate Polarity...
  • Page 52 AFG-3000 系列使用手冊 UTIL UTIL Memory Interface Cal. Load System DSO-Link Search Store Go to the Self Test 50 OHM Hardcopy UTIL – High Z Software Language Select Done Interface Return 中文 Version Return menu Upgrade English Recall Return Return Return...
  • Page 53 快速操作 UTIL–介面 UTIL Interface GPIB RS-232 Return Address Baud Rate Clear 9600 Done 19.2K Return 38.4K 57.6K Return 115K Return Parity/Bits None/8Bits Odd/7Bits Even/7Bits Return Return 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 54: 預設設置

    AFG-3000 系列使用手冊 預設設置 復位鍵用於恢復預設面板設置。 Preset 輸出設置 功能 正弦波 1kHz 頻率 3.000 Vpp 幅值 0.00V dc 偏置 輸出單位 50Ω 輸出端 調製 1kHz 正弦波 載波 (AM/FM/FSK) 100Hz 正弦波 調製波形 AM 深度 100% FM 偏移 100Hz FSK 跳躍頻率 100Hz FSK 頻率 10Hz PWM 占空比...
  • Page 55 快速操作 1kHz 脈衝串 脈衝串頻率 N 次迴圈 10ms 脈衝串週期 脈衝串起始相位 0˚ 脈衝串狀態 系統設置 斷電調用 顯示模式 錯誤佇列 已清除 記憶體設置 無更改 輸出 觸發 觸發源 內部(立即) GPIB 地址 介面設置 RS232 介面 115200 串列傳輸速率 奇偶性 無(8 個數據位元) 校正 校正選單 加密 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 56 AFG-3000 系列使用手冊 操 作 本章節介紹了如何輸出基本波形。有關調製、掃描、脈衝串和任意波 形的部分, 選擇波形 ................57 正弦波 .................. 57 設置方波 ................57 三角波 .................. 58 設置脈衝寬度 ..............59 設置斜波 ................60 雜訊波 .................. 61 設置頻率 ................61 設置幅值 ................63 設置 DC 偏置 ............... 64 北京海洋兴业科技股份有限公司 电话:010-62176775...
  • Page 57: 選擇波形

    操作 選擇波形 AFG-3000 可以輸出六種標準波形: 正弦波, 方波, 三角波, 脈衝波, 斜波 和雜訊波。 正弦波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F1 (Sine) Sine 設置方波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F2 (Square)建立一個方波 Square 3. 按 F1 (Duty)將使位於參數窗 DUTY 口處的占空比參數變亮...
  • Page 58: 三角波

    AFG-3000 系列使用手冊 4. 使用方向鍵和可調旋鈕或數 位鍵盤輸入占空比範圍 5. 按 F5 (%)選擇%單位 範圍 頻率 占空比範圍 20%~80% ≤25MHz 40%~60% 25MHz~≤50MHz >50MHz~80MHz 50% (固定的) 三角波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F3 (Triangle) Triangle 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 59: 設置脈衝寬度

    操作 設置脈衝寬度 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F4 (Pulse)建立一個脈衝波 Pulse 3. 按 F1 (Width)將使位於參數 Width 窗口處的脈寬參數變亮 4. 使用方向鍵和可調旋鈕或數 位鍵盤輸入脈衝寬度 5. 按 F2~F5 選擇單位範圍 nSEC 8ns~1999.9s 範圍 脈衝寬度 最小脈衝寬度 頻率 ≤ 50MHz: 8ns 脈衝 注意 寬度 頻率 ≤ 6.25 MHZ: 5% 占 空比...
  • Page 60: 設置斜波

    AFG-3000 系列使用手冊 解析度 頻率 ≤ 50MHz: 1ns 脈衝 寬度 頻率 ≤ 6.25 MHZ: 1% 占 空比 設置斜波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F5 (Ramp)建立一個斜波 Ramp 3. 按 F1 (SYM)將使位於參數窗 口處的 SYMM 參數變亮 4. 使用方向鍵和可調旋鈕或數 位鍵盤輸入對稱百分比 5. 按 F5 (%)選擇%單位...
  • Page 61: 雜訊波

    操作 雜訊波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F6 (Noise) Noise 設置頻率 1. 按 FREQ/Rate 鍵 面板操作 FREQ/Rate 2. 位於參數窗口處的 FREQ 參數將變亮 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 62 AFG-3000 系列使用手冊 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入頻率 4. 按 F2~F6 選擇頻率單位 1μHz~80MHz(3081)/50MHz(3051) 範圍 正弦波 1μHz~80MHz(3081)/50MHz(3051) 方波 三角波 1μHz~1MHz 500μHz~50MHz 脈衝波 1μHz~1MHz 斜波 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 63: 設置幅值

    操作 設置幅值 1. 按 AMPL 鍵 面板操作 AMPL 2. 位於參數窗口處的 AMPL 參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入幅值 4. 按 F2~F6 選擇單位類型 高阻抗 50Ω 負載 10mVpp~10Vpp 20mVpp~20Vpp 範圍 Vpp, Vrms, dBm 單位 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 64: 設置 Dc 偏置

    AFG-3000 系列使用手冊 設置 DC 偏置 1. 按 DC 偏置鍵 面板操作 DC Offset 2. 位於參數窗口處的 DC 偏置參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 DC 偏置 4. 按 F5 (mVDC)或 F6 (VDC) mVDC 選擇電壓範圍 高阻抗 50Ω 負載 ±5Vpk ±10Vpk 範圍 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 65 調製 調 製 AFG-3000 系列任意波形訊號產生器能夠產生 AM, FM, FSK 和 PWM 調製波形。調製類型不同,調製參數的設置也有所不同。無論何時, 只允許啟動一種調製模式,且掃描或脈衝串模式不能與 AM/FM 同時 啟用。一旦啟動一種調製模式,就意味著關閉前一個調製模式。 幅值調製 (AM) ..............67 選擇 AM 調製 ............... 68 AM 載波波形 ................ 68 載波頻率 ................69 調製波形 ................70 AM 頻率................71 調製深度 ................72 設置...
  • Page 66 AFG-3000 系列使用手冊 調製波形頻率 ..............93 調製占空比 ................94 PWM 調製源 ................ 95 頻率掃描 ................97 選擇掃描模式 ..............98 設置起始和停止頻率 ............98 中心頻率和跨距 ..............100 掃描模式 ................102 掃描時間 ................103 標記頻率 ................104 掃描觸發源 ................ 105 觸發輸出 ................106 脈衝串模式 ..............108 選擇脈衝串模式...
  • Page 67: 幅值調製 (Am)

    調製 幅值調製 (AM) AM 波形由載波和調製波組成。載波幅值與調製波幅值有關。AFG- 3000 訊號產生器可以設置載波頻率、幅值、偏置電壓以及內部或外部 調製源。 Modulated Carrier Waveform Modulating waveform 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 68: 選擇 Am 調製

    AFG-3000 系列使用手冊 選擇 AM 調製 1. 按 MOD 鍵 面板操作 2. 按 F1 (AM) AM 載波波形 AM 載波波形:正弦波、方波、三角波、斜波、脈 背景 衝波或任意波。預設情況為正弦波。不能使用雜訊 波作為載波波形。在選擇載波波形前,請先選擇 AM 調製模式 1. 按 Waveform 鍵 選擇一個標準載 Waveform 波波形 2. 按 F1~F5 選擇載波波形 Sine Ramp 3. 有關任意波的使用部分,詳 35 頁...
  • Page 69: 載波頻率

    調製 載波頻率 最大載波頻率與載波波形的選擇有關。預設載波頻率為 1kHz。 1. 對任一載波波形,按 面板操作 FREQ/Rate FREQ/Rate 鍵 2. 位於參數視窗處的頻率參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入載波頻率 4. 按 F2~F6 選擇頻率範圍 Carrier Frequency 範圍 載波波形 1μHz~80MHz(3081)/ 正弦波 50MHz(3051) 1μHz~80MHz(3081)/ 方波 50MHz(3051) 1μHz~1MHz 三角波 500μHz~50MHz 脈衝波 斜波 1μHz~1MHz 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 70: 調製波形

    AFG-3000 系列使用手冊 調製波形 訊號產生器可以接收內部和外部源。AFG-3000 的調製波形包括正弦 波, 方波, 三角波, 上斜波, 下斜波。預設波形為正弦波。 1. 選擇 MOD 面板操作 2. 按 F1 (AM) 3. 按 F4 (Shape) Shape 4. 按 F1~F5 選擇波形 Sine DnRamp 5. 按 F6 (Return)返回選單 Return 50% 占空比 注意 方波 100% 對稱...
  • Page 71: Am 頻率

    調製 AM 頻率 調製波形的頻率(AM 頻率)可設為 2mHz~20kHz。 1. 按 MOD 鍵 面板操作 2. 按 F1 (AM) 3. 按 F3 (AM Freq) AM Freq 4. 位於波形顯示區域處的 AM 頻率參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 AM 頻率 6. 按 F1~F3 選擇頻率範圍 2mHz~20kHz 範圍 調製頻率 100Hz 預設頻率 北京海洋兴业科技股份有限公司...
  • Page 72: 調製深度

    AFG-3000 系列使用手冊 調製深度 調製深度為未調載波幅值與調製波形最小幅值偏差的比值(以百分比顯 示)。換句話說, 調製深度就是調製波形與載波波形的最大幅值之 比。 1. 按 MOD 鍵 面板操作 2. 按 F1 (AM) 3. 按 F2 (Depth) Depth 4. 位於波形顯示區域處的 AM 深度參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 AM 深度 6. 按 F1 (%)選擇%單位 0%~120% 範圍 深度 100% 預設深度 北京海洋兴业科技股份有限公司...
  • Page 73: 設置 (Am) 調製源

    調製 即使調製深度大於 100%, 輸出也不超過±5V 的峰值 注意 (10kΩ 負載) 如果選擇外部調製源, 那麼調製深度將由後面板 MOD INPUT 上的± 5V 訊號電壓控制。例如, 如果調 製深度設置為 100%, 那麼最大幅值為+5V, 最小幅值 為-5V 設置 (AM) 調製源 訊號產生器將接受用於 AM 調製的內部或外部源。預設為內部源。 1. 按 MOD 鍵 面板操作 2. 按 F1 (AM) 3. 按 F1 (Source) Source 4.
  • Page 74 AFG-3000 系列使用手冊 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 75: 頻率調製 (Fm)

    調製 頻率調製 (FM) FM 波形由載波和調製波組成。載波的暫態頻率隨調製波形的幅值而 變化。當使用 AFG-3000 時,無論何時只允許啟用一種調製模式。 Modulating waveform Modulated Carrier Waveform 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 76: 選擇頻率調製 (Fm)

    AFG-3000 系列使用手冊 選擇頻率調製 (FM) 選擇 FM 後, 調製波形由載波頻率、輸出幅值和偏置電壓決定。 1. 按 MOD 鍵 面板操作 2. 按 F2 (FM) FM 載波波形 背景 FM 載波預設為正弦波。雜訊波和脈衝波不能用作載 波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F1~F5 選擇載波波形(bar Sine Ramp 範圍 載波波形 正弦波, 方波, 三角波, 斜...
  • Page 77: Fm 載波頻率

    調製 FM 載波頻率 使用 AFG-3000 時,載波頻率必須大於或等於頻率偏移。如果頻率偏 移大於載波頻率,函數產生器會自動將偏移調整到當前載波頻率所允 許的最大值。載波最大頻率與所選波形有關。 1. 按 FREQ/Rate 鍵選擇載波頻 面板操作 FREQ/Rate 率 2. 位於參數窗口處的 FREQ 參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入載波頻率 4. 按 F2~F6 選擇頻率單位 範圍 載波波形 載波頻率 1μHz~80MHz(3081)/ 正弦波 50MHz(3051) 方波 1μHz~80MHz(3081)/ 50MHz(3051) 1μHz~1MHz 三角波 1μHz~1MHz 斜波 1 kHz 預設頻率...
  • Page 78: Fm 波形

    AFG-3000 系列使用手冊 FM 波形 訊號產生器能接受內部和外部源。AFG-3000 的內部調製波形包括正 弦波、方波、三角波、正和負斜波(UpRamp, DnRamp)。預設情況為 正弦波。 1. 選擇 MOD 面板操作 2. 按 F2 (FM) 3. 按 F4 (Shape) Shape 4. 按 F1~F5 選擇波形 Sine DnRamp 5. 按 F6 (Return)返回選單 Return 50% 占空比 注意 方波 100% 對稱 上升波...
  • Page 79: 頻率調製波形

    調製 頻率調製波形 訊號產生器將接受用於 FM 的內部或外部調製源。 1. 按 MOD 鍵 面板操作 2. 按 F2 (FM) 3. 按 F3 (FM Freq) FM Freq 4. 位於波形顯示區域處的 FM 頻率參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 FM 頻率 6. 按 F1~F3 選擇頻率單位 2mHz~20kHz 範圍 調製頻率 100Hz 預設頻率 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 80: 頻率偏移

    AFG-3000 系列使用手冊 頻率偏移 頻率偏移是載波與調製波的頻率最大偏差。 1. 按 MOD 鍵 面板操作 2. 按 F2 (FM) 3. 按 F2 (Freq Dev) Freq Dev 4. 位於波形顯示區域處的 Freq Dev 參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入頻率偏移 6. 按 F1~ F5 選擇頻率單位 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 81: 選擇 (Fm) 調製源

    調製 DC~80MHz (3081) 範圍 頻率偏移 DC~50MHz (3051) DC~1MHz (三角波) 100kHz 預設深度 選擇 (FM) 調製源 訊號產生器將接受用於 FM 調製的內部或外部源。預設為內部源。 1. 按 MOD 鍵 面板操作 2. 按 F2 (FM) 3. 按 F1 (Source) Source 4. 按 F1 (INT)或 F2 (EXT)選擇 調製源 5. 按 F6 (Return)返回選單 Return 從後面板的...
  • Page 82 AFG-3000 系列使用手冊 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 83: 頻移鍵控 (Fsk) 調製

    調製 頻移鍵控 (FSK) 調製 FSK 調製用於在兩個預設頻率(載波頻率和跳躍頻率)間交替輸出頻 率。內部頻率產生器或後面板 Trigger INPUT 上的訊號準位決定交替 頻率。 函數產生器一次只允許啟用一種調製模式。當開啟 FSK 調製時,其它 調製模式將禁用。在啟用掃描和脈衝串時不允許啟用 FSK 調製。在啟 用 FSK 時,將關閉掃描或脈衝串模式。 Carrier Frequency Hop Frequency 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 84: 選擇 Fsk 調製

    AFG-3000 系列使用手冊 選擇 FSK 調製 當使用 FSK 模式時, 輸出波形使用預設載波頻率、幅值和偏置電壓。 1. 按 MOD 鍵 面板操作 2. 按 F3 (FSK) FSK 載波波形 背景 預設波形為正弦波。雜訊波不能用作載波 1. 按 Waveform 鍵 面板操作 Waveform 2. 按 F1~F5 選擇載波波形(bar Sine Ramp 範圍 載波波形 正弦波, 方波, 三角波, 斜...
  • Page 85: Fsk 載波頻率

    調製 FSK 載波頻率 最大載波頻率與載波波形有關。預設載波頻率均為 1kHz。選擇外部 源時,Trigger INPUT 訊號的訊號準位控制輸出頻率。當訊號為邏輯 低準位時,輸出載波頻率;當訊號為邏輯高準位時,輸出跳躍頻率。 1. 按 FREQ/Rate 鍵選擇載波頻 面板操作 FREQ/Rate 率 2. 位於參數窗口處的 FREQ 參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入載波頻率 4. 按 F2~F6 選擇 FSK 頻率單位 範圍 載波波形 載波頻率 1μHz~80MHz(3081)/ 正弦波 50MHz(3051) 1μHz~80MHz(3081)/ 方波 50MHz(3051) 1μHz~1MHz 三角波 1μHz~1MHz 斜波...
  • Page 86: Fsk 跳躍頻率

    AFG-3000 系列使用手冊 FSK 跳躍頻率 預設跳躍頻率均為 100 Hz。內部調製波是占空比為 50%的方波。選擇 外部源時,Trigger INPUT 訊號的訊號準位控制輸出頻率。當訊號為 邏輯低準位時,輸出載波頻率;當訊號為邏輯高準位時,輸出跳躍頻 率。 1. 按 MOD 鍵 面板操作 2. 按 F3 (FSK) 3. 按 F2 (Hop Freq) Hop Freq 4. 位於波形顯示區域處的 Hop Freq 參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入跳躍頻率 6. 按 F1~F5 選擇頻率範圍...
  • Page 87: Fsk 頻率

    調製 範圍 波形 載波頻率 1μHz~80MHz(3081)/ 正弦波 50MHz(3051) 1μHz~80MHz(3081)/ 方波 50MHz(3051) 1μHz~1MHz 三角波 1μHz~1MHz 斜波 脈衝波 500μHz~50MHz FSK 頻率 FSK 頻率是決定輸出載波頻率或跳躍頻率的頻率值。 1. 選擇 MOD 面板操作 2. 按 F3 (FSK) 3. 按 F3 (FSK Rate) FSK Rate 4. 位於波形顯示區域處的 FSK Rate 參數將變亮 北京海洋兴业科技股份有限公司...
  • Page 88: Fsk 源

    範圍 10Hz 預設 注意 如果選擇外部源, 忽視 FSK 頻率設置 FSK 源 AFG-3000 接受內部和外部 FSK 源,預設為內部 FSK 源。當選擇內部 FSK 源時,使用 FSK Rate 功能設置 FSK 頻率。當選擇外部源時, FSK 頻率與後面板 Trigger INPUT 訊號的頻率一致。 1. 按 MOD 鍵 面板操作 2. 按 F3 (FSK) 3. 按 F1 (Source) Source 4.
  • Page 89 調製 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 90: 脈衝寬度調製

    AFG-3000 系列使用手冊 脈衝寬度調製 對於脈寬調製,脈衝寬度由調製波形的暫態電壓決定。無論何時僅允 許啟用一種調製模式。若使用 PWM,將禁用其它調製模式。此外不 允許掃描和脈衝串模式與 PWM 同時使用。若使用 PWM,將關閉掃 描和脈衝串模式。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 91: 選擇脈衝寬度調製

    調製 選擇脈衝寬度調製 選擇 PWM, 需要考慮載波頻率的當前設置、幅值調製頻率、輸出和偏 移電壓。 1. 按 MOD 鍵 面板操作 Waveform 2. 按 F2 (Square) Square 3. 按 MOD 鍵 4. 按 F4 (PWM) PWM 載波波形 PWM 僅使用方波作為載波波形,否則會彈出錯誤資訊。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 92: Pwm 載波頻率

    AFG-3000 系列使用手冊 PWM 載波頻率 載波頻率與方波有關。預設載波頻率為 1kHz。 1. 按 FREQ/Rate 鍵選擇載波頻 面板操作 FREQ/Rate 率 2. 位於參數窗口處的 FREQ 參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入載波頻率 4. 按 F2~F6 選擇 PWM 頻率單 位 PWM 調製波形 調製波形(內部源)包括正弦波、方波、三角波、正斜波和負斜波。預 設波形為正弦波。 1. 按 MOD 鍵 面板操作 2. 按 F4 (PWM) 3.
  • Page 93: 調製波形頻率

    調製 5. 按 F6 (Return)返回選單 Return 範圍 波形 50%占空比 方波 100%對稱 正斜波 50%對稱 三角波 0%對稱 負斜波 調製波形頻率 1. 選擇 MOD 面板調製 2. 按 F4 (PWM) 3. 按 F3 (PWM Frequency) PWM Freq 4. 位於波形顯示區域處的 PWM Freq 參數將變亮 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 94: 調製占空比

    AFG-3000 系列使用手冊 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 PWM 頻率 6. 按 F1~F3 選擇頻率單位 PWM 頻率 2mHz~20kHz 範圍 20kHz 預設 調製占空比 用於設置占空比(%) 1. 按 MOD 鍵 面板操作 2. 按 F4 (PWM) 3. 按 F2 (Duty) Duty 4. 位於波形顯示區域處的 Duty 參數將變亮 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 95: Pwm 調製源

    6. 按 F1 (%)選擇百分號 0% ~ 100% 範圍 占空比 預設 注意 如果使用外部調製源,則脈衝波形由外部調製源調 製。此時,MOD INPUT 端子上的±5V 電壓控制脈 寬。 PWM 調製源 AFG-3000 接受內部和外部 PWM 調製源。預設為內部調製源。 1. 按 MOD 鍵 面板操作 2. 按 F4 (PWM) 3. 按 F1 (Source) Source 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 96 AFG-3000 系列使用手冊 4. 按 F1 (INT)或 F2 (EXT)選擇 調製源 5. 按 F6 (Return)返回選單 Return 外部源 選擇外部調製源時,需要使用後 ±5V 面板的 MOD INPUT 端子 當您選擇外部調製源時,脈寬調製由後面板 MOD 注意 INPUT 端子上的±5V 電壓控制。例如:如果您已將 調製深度設為 100%,則在調製訊號為+5V 時,輸出 最大脈寬;在調製訊號為-5V 時,輸出最小脈寬。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 97: 頻率掃描

    調製 頻率掃描 除雜訊波和脈衝波外,訊號產生器可以對正弦波、方波或斜波產生一 個掃頻。在啟動掃描模式時,將關閉脈衝串或其它調製模式。 在掃描模式下,訊號產生器以指定步進從起始頻率到停止頻率掃描。 您能夠以線性或對數間隔由高頻向低頻掃描,或者由低頻向高頻掃 描。您也可以配置訊號產生器,使其用外部觸發或手動觸發輸出單個 掃描。 Sweep 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 98: 選擇掃描模式

    AFG-3000 系列使用手冊 選擇掃描模式 選擇 Sweep 按鈕,進入掃描模式。如果不預先設 置,輸出幅值、偏移和頻率使用預設值。 Sweep 設置起始和停止頻率 起始頻率和停止頻率定義掃描上限和下限。訊號產生器從起始頻率開 始,一直掃描到停止頻率,然後又重定回起始頻率。在整個掃描範圍 內,相位連續(100μHz-80MHz: AFG-3081/50MHz: AFG-3051)。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F3 (Start)或 F4 (Stop)選擇 Start 起始或停止頻率 3. 位於波形顯示區域處的 Start 或 Stop 參數將變 亮 起始 停止 4. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 Stop/Start 頻率...
  • Page 99 調製 5. 按 F1~F5 選擇 Start/Stop 頻 率單位 100μHz~80MHz(3081) 範圍 掃描範圍 100μHz~50MHz(3051) (正弦波/方波) 100μHz~1MHz (三角波) 起始 – 預設 100Hz 停止 – 預設 1kHz 注意 從低頻到高頻掃描,設置起始頻率<停止頻率。從 高頻到低頻掃描,設置起始頻率>停止頻率。關閉 標記後,同步訊號為 50%占空比的方波。在掃描開 始時,同步訊號處於 TTL 低準位,掃描中點上升到 TTL 高準位。同步訊號頻率與指定掃描時間相等。 打開標記,在掃描開始時同步訊號處於 TTL 高準位 ,到達標識頻率處下降到 TTL 低準位。標記輸出端 輸出同步訊號。 北京海洋兴业科技股份有限公司...
  • Page 100: 中心頻率和跨距

    AFG-3000 系列使用手冊 中心頻率和跨距 使用中心頻率和跨距來設置掃描上限和下限(起始/停止)。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F6 (More) More 3. 按 F1 (Span)或 F2 (Center)選 Span Center 擇跨距或中心 4. 位於波形顯示區域處的 Span 或 Center 參數將 變亮 跨距 中心 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 Span/Center 頻 率 6. 按 F1~F5 選擇 Start/Stop 頻...
  • Page 101 調製 100μHz~1MHz (三角波) DC~80MHz(3081) 跨距頻率 DC~50MHz(3051) (正弦波/方波) DC ~1MHz (三角波) 中心 – 預設 550Hz 跨距 – 預設 900Hz 注意 從低頻到高頻掃描,設置正頻率跨距。從高頻到低 頻掃描,設置負頻率跨距。關閉標記後,同步訊號 為 50%占空比的方波。在掃描開始時,同步訊號處 於 TTL 低準位,掃描中點上升到 TTL 高準位。同步 訊號頻率與指定掃描時間相等。打開標記,在掃描 開始時同步訊號處於 TTL 高準位,到達標識頻率處 下降到 TTL 低準位。標記輸出端輸出同步訊號。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 102: 掃描模式

    AFG-3000 系列使用手冊 掃描模式 掃描模式用於選擇線性或對數掃描。預設線性掃描。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F2 (Type) Type 3. 按 F1 (Linear)或 F2 (Log)選 Linear 擇線性或對數掃描 4. 按 F6 (Return)返回選單 Return 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 103: 掃描時間

    調製 掃描時間 從起始頻率到截止頻率完成一次掃描所需的時間稱為掃描時間。訊號 產生器自動限定掃描的離散頻率點,該數目與掃描長度有關。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F5 (SWP Time) SWP Time 3. 位於波形顯示區域處的掃描時間參數將變亮 4. 使用方向鍵和可調旋鈕或數 位鍵盤輸入掃描時間 5. 按 F1~F2 選擇時間單位 mSEC 1ms ~ 500s 範圍 掃描時間 預設 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 104: 標記頻率

    AFG-3000 系列使用手冊 標記頻率 標記訊號變為低準位時的頻率稱為標記頻率(掃描開始時標記訊號都處於高準 位)。後面板 MARK 端子輸出標記訊號。預設 550 Hz。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F6 (More) More 3. 按 F3 (Marker) Marker 4. 按 F2 (ON/OFF)打開/關閉 ON/OFF 標記 5. 按 F1 (Freq)選擇標記頻率 Freq 6. 位於波形顯示區域處的頻率參數將變亮 7. 使用方向鍵和可調旋鈕或數...
  • Page 105: 掃描觸發源

    調製 8. 按 F1~F5 選擇頻率單位 100μHz~80MHz(3081) 範圍 頻率 100μHz~50MHz(3051) 100μHz~1MHz (斜波) 550Hz 預設 標記頻率必須設置在起始頻率和停止頻率之間。如 注意 果無設置,標記頻率將等於起始頻率和停止頻率的 均值。 啟用掃描模式後,標記模式將忽略同步模式的設 置。 掃描觸發源 掃描模式下,訊號產生器在收到觸發訊號時輸出一個掃描。掃描輸出 完成後,訊號產生器輸出起始頻率,並等待下一次觸發。預設內部觸 發源。 1. 按 SWEEP 鍵 面板掃描 Sweep 2. 按 F1 (Source) Source 3. 按 F1 (Internal), F2 Manual (External)或...
  • Page 106: 觸發輸出

    AFG-3000 系列使用手冊 注意 選擇內部源時,訊號產生器輸出一個連續的掃描, 其頻率由掃描時間決定。 選擇外部源時,每收到一個從後面板 Trig Out 的 TTL 脈衝,訊號產生器就輸出一個掃描。 觸發週期必須大於或等於掃描時間+1ms。 5. 如果選擇手動觸發,按 F1 Trigger (Trigger)執行手動掃描 觸發輸出 後面板的 Trig Out 端子輸出觸發輸出訊號(掃描和脈衝串模式)。預設 在掃描開始時輸出具有上升沿的 TTL 方波。訊號也可以設為下降沿。 1. 按 SWEEP 鍵 面板操作 Sweep 2. 按 F6 (More) More 3. 按 F4 (TRIG out) TRIG out 4.
  • Page 107 調製 注意 選擇內部觸發源,在每次掃描開始時,訊號產生器 就從 Trig out 端輸出占空比為 50%的方波。波形頻 率與掃描時間相等。 選擇外部觸發源時,訊號產生器自動禁用觸發輸出 訊號。 選擇手動觸發,在每次掃描或脈衝串開始時,訊號 產生器從 Trig Out 端輸出一個>1us 的脈衝。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 108: 脈衝串模式

    AFG-3000 系列使用手冊 脈衝串模式 訊號產生器能建立一個具有指定迴圈數的波形脈衝串。脈衝串模式支 援正弦波、方波、三角波和斜波。 Burst 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 109: 選擇脈衝串模式

    調製 選擇脈衝串模式 選擇脈衝串模式後,任何調製或掃描模式都將自動 關閉。如果無設置,輸出幅值、偏移和頻率啟用預 Burst 設值。 脈衝串模式 觸發(N 次迴圈模式)或閘控模式可以設置脈衝串模式。在 N 次迴圈/ 觸發模式下,每次接收觸發時訊號產生器都將輸出一個指定迴圈次數 的波形(脈衝串)。執行完成後,訊號產生器將停止並等待下一次觸 發。預設為 N 次迴圈模式。內部或外部觸發均可使用。 相比指定迴圈次數,門控模式使用外部觸發打開或關閉輸出。當觸發 輸入訊號為高準位時,波形持續輸出。當觸發輸入訊號為低準位時, 訊號產生器在輸出最後一個完整波形後停止。輸出電壓準位仍與脈衝 串波形的起始相位相同。 脈衝串模式 脈衝串計數 脈衝串週期 相位 觸發源 Triggered (Int) 可用 可用 可用 立即 Triggered (Ext) EXT, Bus 可用 不可用 可用 Gated pulse (Ext) 不可用 不可用...
  • Page 110: 脈衝串頻率

    AFG-3000 系列使用手冊 脈衝串頻率 在 N 次迴圈和門控模式下,波形頻率定義了脈衝串波形的重複率。在 N 次迴圈模式下,以指定迴圈次數輸出波形。在門控模式下,當觸發 訊號為高準位時輸出波形頻率。脈衝串模式支援正弦波、方波、三角 波或斜波。 1. 按 FREQ/Rate 鍵 面板操作 FREQ/Rate 2. 位於參數窗口處的 FREQ 參數將變亮 3. 使用方向鍵和可調旋鈕或數 位鍵盤輸入頻率 4. 按 F2~F6 選擇頻率單位 2mHz~80MHz(3081)/ 範圍 頻率 50MHz(3051) 頻率 – 斜波 2mHz~1MHz 1kHz 預設 波形頻率不同於脈衝串週期。脈衝串週期指 N 次迴...
  • Page 111: 脈衝串迴圈/計數

    調製 脈衝串迴圈/計數 脈衝串迴圈/計數是指脈衝串波形的迴圈次數。僅用於 N Cycle 模式 (內部, 外部或手動觸發)。預設 1 次迴圈。 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F1 (Cycles) Cycles 4. 位於波形顯示區域處的 Cycles 參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入迴圈數 6. 按 F5 選擇 Cyc 單位 1~1,000,000 範圍...
  • Page 112: 無限脈衝串計數

    AFG-3000 系列使用手冊 注意 選擇內部觸發源時,持續輸出迴圈數。脈衝串週期 決定脈衝串頻率和脈衝串之間的時間間隔。 脈衝串計數須小於脈衝串週期和波形頻率的乘積。 脈衝串計數 < (脈衝串週期 x 波形頻率) 如果脈衝串計數超出上述限制,訊號產生器將自動 增大脈衝串週期,以滿足條件。 選擇門控脈衝串模式時,忽略脈衝串計數。如果從 遠端介面更改計數,訊號產生器將記錄新計數,並 在下次使用。 無限脈衝串計數 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F2 (Infinite) Infinite 注意 無限脈衝串僅用在手動觸發模式 25MHz 以上, 無限脈衝串僅適合方波和正弦波...
  • Page 113: 脈衝串週期

    調製 脈衝串週期 從一個脈衝串的開始至下一個脈衝串的開始所經歷的時間稱為脈衝串 週期。僅用於內部觸發脈衝串模式。 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F4 (Period) Period 4. 位於波形顯示區域處的週期參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入週期 6. 按 F1~F3 選擇週期單位 uSEC 1ms~500s 範圍 週期 10ms 預設 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 114: 脈衝串相位

    AFG-3000 系列使用手冊 注意 脈衝串週期僅用於內部觸發。當使用門控脈衝串模 式或外部和手動觸發時,關閉脈衝串週期設置。 脈衝串週期一定要夠長,且滿足如下條件: 脈衝串週期>脈衝串計數/波形頻率 + 200ns 脈衝串相位 脈衝串波形的起始相位稱為脈衝串相位,預設 0˚。 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F3 (Phase) Phase 4. 位於波形顯示區域處的相位參數將變亮 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入相位 6. 按 F5 (Degree)選擇相位單位 Degree 北京海洋兴业科技股份有限公司...
  • Page 115: 脈衝串觸發源

    調製 範圍 相位 -360˚~+360˚ 預設 0˚ 注意 當使用正弦波、方波、三角波或斜波時,0˚與波形 0V 點相對應。 0˚是波形的起始點。對於正弦波、方波或三角波、 斜波,0˚對應 0V 電壓(假設沒有 DC 偏置) 脈衝串相位用於 N 次迴圈和門控脈衝串模式。在門 控脈衝串模式下,當觸發 INPUT 訊號下降到低準位 時,訊號產生器完成當前波形後停止輸出。電壓輸 出準位仍與起始脈衝串相位對應的電壓值相同。 脈衝串觸發源 觸發脈衝串(N-Cycle)模式下,訊號產生器在收到觸發後輸出一個波形 脈衝串。脈衝串迴圈(脈衝串計數)指定每個脈衝串的波形數。輸出完 成後,訊號產生器停止並等待下一次觸發。預設啟用內部觸發的脈衝 串(N-cycle)模式。 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3.
  • Page 116 AFG-3000 系列使用手冊 注意 選擇內部觸發源時,脈衝串以指定頻率持續輸出, 該頻率和脈衝串之間的時間間隔由脈衝串週期決 定。 選擇外部觸發時,訊號產生器接收後面板觸發輸入 端的觸發訊號(TTL)。每收到一個觸發訊號,訊號產 生器就輸出一個脈衝串(迴圈數已設)。輸出脈衝串期 間接收到的觸發訊號將被忽略。 若使用手動或外部觸發,僅可用脈衝串相位和脈衝 串迴圈/計數,脈衝串週期不可用。 在接收觸發後、脈衝串開始之間可以插入時間延 遲。 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 117: 脈衝串延遲

    調製 脈衝串延遲 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F5 (TRIG setup) TRIG setup 4. 按 F4 (Delay) Delay 5. 位於波形顯示區域處的 Delay 參數將變亮 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入週期 7. 按 F1~F4 選擇延遲時間單位 nSEC 0s~80s 範圍...
  • Page 118: 脈衝串觸發輸出

    AFG-3000 系列使用手冊 脈衝串觸發輸出 後面板的 Trig Out 端子提供觸發輸出訊號(僅用於脈衝串和掃描模 式)。在脈衝串開始時預設輸出具有上升沿的 TTL 相容觸發訊號。 1. 按 Burst 鍵 面板操作 Burst 2. 按 F1 (N Cycle) N Cycle 3. 按 F5 (TRIG setup) TRIG setup 4. 按 F5 (TRIG out) TRIG out 5. 按 F3 (ON/OFF)打開/關閉...
  • Page 119 輔助系統功能設置 輔 助系統功能設置 輔助系統功能設置包括存儲和調取設置、RS232/USB/GPIB 設置、查 看軟體版本、更新固件、自我校準、輸出阻抗設置、改變語言和 DSO 連接設置。 存儲和調取 ..............120 選擇遠端介面 ..............123 GPIB 介面 ................123 RS232 介面 ................. 124 RS232 奇偶性/數據位元設置 ..........125 USB 介面 ................126 系統和設置 ..............127 查看和更新固件版本............127 設置輸出阻抗 ..............128 語言選擇 ................129 設置蜂鳴器...
  • Page 120: 存儲和調取

    AFG-3000 系列使用手冊 存儲和調取 AFG-3000 的非易失性記憶體有 10 個記憶體檔 0~9,可以保存儀器狀 態、波形資料(ARB)和設置。記憶體檔中的資料(ARB 或設置資料)以 紅色字體顯示。若沒有資料則呈現藍色。 存儲/調取內容  速率  顯示垂直位置   頻率 輸出開始  長度  輸出長度  顯示水準位置 設置  功能   調製源  波形  波形  頻率  深度...
  • Page 121 輔助系統功能設置  時間  占空比  起始頻率  頻率   停止頻率 脈衝串類型  中心頻率  源  跨距頻率  觸發   標記頻率 類型  迴圈數  相位  週期  延遲 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F1 (Memory) Memory 3.
  • Page 122 AFG-3000 系列使用手冊 4. 使用可調旋鈕選擇一個記憶 體檔。按 F1 (Select)確認 5. 使用可調旋鈕選擇資料類型。按 F1 (Select)確 認 Memory0 ~ Memory9 範圍 記憶體檔 資料類型 ARB, 設置, ARB+設置 6. 按 F5 (Done)確認操作 Done 7. 按 F4 刪除 Memory0 ~ 刪除所有 Delete All Memory9 所有檔 8. 按 F1 (Done)確認刪除...
  • Page 123: 選擇遠端介面

    輔助系統功能設置 選擇遠端介面 AFG-3000 具有 RS232, GPIB 和 USB 介面,方便遠端控制。一次僅可 以使用一個遠端介面。 GPIB 介面 使用 GPIB 介面必須指定 GPIB 位址。預設 GPIB 介 背景 面為 10 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F2 (Interface) Interface 3. 按 F1 (GPIB) GPIB 4. 按 F1 (Address) Address 5.
  • Page 124: Rs232 介面

    AFG-3000 系列使用手冊 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 GPIB 位址 7. 按 F5 (Done)確認 GPIB 地址 Done GPIB 地址 1~30 範圍 RS232 介面 使用 RS232 介面必須指定串列傳輸速率 背景 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F2 (Interface) Interface 3. 按 F2 (RS-232) RS-232 4.
  • Page 125: Rs232 奇偶性/數據位元設置

    輔助系統功能設置 6. 按 F1~F5 選擇串列傳輸速率 9600 115k 9600, 19200, 38400, 範圍 串列傳輸速率 57600, 115200 RS232 奇偶性/數據位元設置 RS232 用作遠端介面時可以設置同位元。預設無同 背景 位元/8 個數據位元 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F2 (Interface) Interface 3. 按 F2 (RS-232) RS-232 4. 按 F2 (Parity) Parity 5.
  • Page 126: Usb 介面

    AFG-3000 系列使用手冊 6. 按 F1, F2 或 F3 選擇奇偶性和 None/8Bits Even/7Bits 資料位元 範圍 無同位/8 位, 奇數同位檢查/7 位, 偶校驗/7 位 USB 介面 背景 用於遠程控制 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F2 (Interface) Interface 3. 按 F3 (USB) 北京海洋兴业科技股份有限公司 电话:010-62176775...
  • Page 127: 系統和設置

    輔助系統功能設置 系統和設置 使用者也可以設置語言選項、輸出阻抗、DSO 連接以及固件配置等。 查看和更新固件版本 面板操作 1. 按 UTIL 鍵 UTIL 2. 按 F3 (Cal.) Cal. 3. 按 F2 (Software) Software 4. 按 F1(Version)查看固件版本 查看版本 Version 螢幕顯示版本資訊: 儀器, 版本, FPGA 版次, Bootload 版本 5. 將包含固件檔的 USB 閃盤插 更新固件 Upgrade 入 USB host 驅動中,按 F2 (Upgrade)更新固件...
  • Page 128: 設置輸出阻抗

    AFG-3000 系列使用手冊 設置輸出阻抗 AFG-3000 提供可選輸出阻抗: 50Ω(預設)或 High- 背景 Z。輸出阻抗僅供參考,如果與實際負載阻抗不同, 那麼實際幅值和偏移也將相應改變。 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F4 (Load) Load 3. Load 將變亮變紅 4. 按 F1 (50 OHM)或 F2 (High 50 OHM High Z Z)選擇輸出阻抗 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 129: 語言選擇

    輔助系統功能設置 語言選擇 AFG-3000 提供英語(預設)和簡體中文兩種語言操作 背景 環境。 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F5 (System) System 3. 按 F2 (Language) Language 4. Language 參數將變亮 5. 按 F1 (中文)或 F2 (English) 中文 English 選擇語言 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 130: 設置蜂鳴器

    AFG-3000 系列使用手冊 設置蜂鳴器 背景 打開或關閉蜂鳴器。 1. 按 UTIL 鍵 面板操作 UTIL 2. 按 F5 (System) System 3. 按 F3 (Beep)打開或關閉蜂鳴 Beep 器 4. Beep 參數將變亮 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 131: 螢幕截圖

    輔助系統功能設置 螢幕截圖 訊號產生器能截取螢幕圖像並將它們保存在 U 盤中 背景 1. 將 USB key 插入前面板的 連接 USB 端子 2. 按 UTIL 鍵 面板操作 UTIL 3. 按 F5 (System) System 4. 按 F1 (Hardcopy) Hardcopy 5. 使用可調旋鈕選擇螢幕圖 像,每次截取一張 功能: 波形, ARB, (AM, FM, FSK, PWM), Sweep, Burst, UTIL 6.
  • Page 132: Dso 連接

    AFG-3000 系列使用手冊 DSO 連接 DSO 連接使 AFG-3000 和 GDS-2000 系列數位存儲 背景 示波器之間進行無損資料傳輸。 1. 將 AFG-3000 USB host 介面 與 GDS-2000 的 USB B device 介面相連 2. 按 UTIL 鍵 面板操作 UTIL 3. 按 F6 (DSO Link) DSO Link 4. 按 F1 (Search) Search 5.
  • Page 133 任意波形 任 意波形 AFG-3000 系列訊號產生器能夠建立自訂的任意波形,取樣速率 200MHz。每個波形 1M 資料點,垂直範圍在±32767(65535)以內。 插入內置波形 ..............135 建立正弦波 ................ 135 建立方波 ................136 建立斜波 ................138 建立 Sinc 波形 ..............139 建立指數上升波形 ............140 建立指數下降波形 ............142 建立 DC 波形 ..............144 建立脈衝波形 ..............145 顯示任意波形 ..............148 設置水準顯示範圍...
  • Page 134 AFG-3000 系列使用手冊 從 USB 調取波形 ............... 176 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 135: 插入內置波形

    任意波形 插入內置波形 AFG-3000 系列訊號產生器可以建立一些常見波形,包括正弦波、方 波、斜波、sinc、指數上升、指數下降和 DC 波形。 建立正弦波 1. 按 ARB 鍵 面板操作 2. 按 F3(Built in) Built in 3. 按 F1 (Sine) Sine 4. 按 F1 (Start) Start 5. Start 將變亮 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 7. 按 F5 (Enter)確認 Start 點...
  • Page 136: 建立方波

    AFG-3000 系列使用手冊 10. 按 F4 (Done)完成操作 Done 11. 按 F6 (Return)返回上級選單 Return 如下建立一個正弦波,start:0, Length: 524288, Scale: 32767 建立方波 1. 按 ARB 鍵 面板操作 2. 按 F3 (Built in) Built in 3. 按 F2 (Square) Square 4. 按 F1 (Start) Start 5.
  • Page 137 任意波形 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 7. 按 F5 (Enter)確認 Start 點 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F2) Length Scale 和 Scale (F3)設置 10. 按 F4 (Done)完成操作 Done 11. 按 F6 (Return)返回上級選單 Return 如下建立一個方波,start:0, Length: 524288, Scale: 32767 北京海洋兴业科技股份有限公司...
  • Page 138: 建立斜波

    AFG-3000 系列使用手冊 建立斜波 1. 按 ARB 面板操作 2. 按 F3 (Built in) Built in 3. 按 F3 (Ramp) Ramp 4. 按 F1 (Start) Start 5. Start 呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 7. 按 F5 (Enter)確認起始點 Enter 8. 按 F6 (Return)返回上級選單 Return 9.
  • Page 139: 建立 Sinc 波形

    任意波形 如下建立一個斜波,start:0, Length: 524288, Scale: 32767 建立 Sinc 波形 1. 按 ARB 鍵 面板操作 2. 按 F3 (Built in) Built in 3. 按 F4 (Sinc) Sinc 4. 按 F1 (Start) Start 5. Start 呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 140: 建立指數上升波形

    AFG-3000 系列使用手冊 7. 按 F5 (Enter)確認起始點 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F2) Length Scale 和 Scale (F3)設置 10. 按 F4 (Done)完成操作 Done 11. 按 F6 (Return)返回上級選單 Return 如上建立一個 sinc 波形,start:0, Length: 524288, Scale: 32767 建立指數上升波形...
  • Page 141 任意波形 4. 按 F1 (Exp Rise) Exp Rise 5. 按 F1 (Start) Start 6. Start 呈現亮紅色 7. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 8. 按 F5 (Enter)確認起始點 Enter 9. 按 F6 (Return)返回上級選單 Return 10. 重複 4~8 步完成 Length (F2) Length Scale 和 Scale (F3)設置 11.
  • Page 142: 建立指數下降波形

    AFG-3000 系列使用手冊 建立指數下降波形 1. 按 ARB 鍵 面板操作 2. 按 F3 (Built in) Built in 3. 按 F5 (More) More 4. 按 F2 (Exp Fall) Exp Fall 5. 按 F1 (Start) Start 6. Start 呈現亮紅色 7. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 北京海洋兴业科技股份有限公司 电话:010-62176775...
  • Page 143 任意波形 8. 按 F5 (Enter)確認起始點 Enter 9. 按 F6 (Return)返回上級選單 Return 10. 重複 4~8 步完成 Length (F2) Length Scale 和 Scale (F3)設置 11. 按 F4 (Done)完成操作 Done 12. 按 F6 (Return)返回上級選單 Return 如下建立一個指數下降波形,start:0, Length: 524288, Scale: 32767 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 144: 建立 Dc 波形

    AFG-3000 系列使用手冊 建立 DC 波形 1. 按 ARB 鍵 面板操作 2. 按 F3 (Built in) Built in 3. 按 F5 (More) More 4. 按 F3 (DC) 5. 按 F1 (Start) Start 6. Start 呈現亮紅色 7. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 8. 按 F5 (Enter)確認起始點...
  • Page 145: 建立脈衝波形

    任意波形 12. 按 F6 (Return)返回上級選單 Return 如下建立一個 DC 波形,start:0, Length: 524288, Data: 10000 建立脈衝波形 範圍 頻率 解析度 占空比解析度 1pHz~5Hz 1pHz 0.0001% >5Hz~50Hz 1uHz 0.0001% >50Hz~500Hz 10uHz 0.001% >500Hz~5kHz 100uHz 0.01% >5kHz~50kHz 1mHz 0.1% >50kHz~500kHz 10mHz 1. 按 ARB 鍵 面板操作 2.
  • Page 146 AFG-3000 系列使用手冊 5. 按 F1 (Freq) Freq 6. Pulse Freq 呈現亮紅色 7. 使用方向鍵和可調旋鈕或數 位鍵盤輸入脈衝頻率 8. 按 F1~F5 選擇頻率單位 9. 按 F6 (Return)返回上級選單 Return 10. 按 F2 (Duty)並使用數位鍵盤 Duty 或可調旋鈕選擇占空比 11. 按 F5 (%)完成操作 12. 按 F6 (Return)返回上級選單 Return 13. 按 F5 (Done)完成操作...
  • Page 147 任意波形 如下建立一個脈衝波(200Hz 頻率、25%占空比) 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 148: 顯示任意波形

    AFG-3000 系列使用手冊 顯示任意波形 設置水準顯示範圍 兩種方式設置水準顯示範圍: 使用起始點和長度或者使用中心點和長 度 1. 按 ARB 鍵 面板操作 2. 按 F1 (Display)進入顯示功能 Display 表 3. 按 F1 (Horizon)進入水準選 Horizon 單 4. 按 F1( Start) 使用起始點 Start 5. Horizontal From 參數變亮 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入水準值 7. 按 Clear (F4, Not F1)取消...
  • Page 149 任意波形 10. 重複 4~9 步完成 Length (F2) 設置長度 Length 設置 11. 重複 4~9 步完成 Center (F3) 使用中心點 Center 設置 12. 按 F4 (Zoom In)放大波形。 Zoom in Zoom in 長度每次減小一半。允許的 最小長度為 3 13. 按 F5 (Zoom out)沿波形中點 Zoom out Zoom out 縮小。長度每次增加一倍。...
  • Page 150: 設置垂直顯示範圍

    AFG-3000 系列使用手冊 設置垂直顯示範圍 與水準視窗類似,兩種方式設置垂直顯示範圍:設置高和低值,或者 設置中心點。 1. 按 ARB 鍵 面板操作 2. 按 F1 (Display) Display 3. 按 F2 (Vertical) Vertical 4. 按 F1 (Low) 設置最低點 5. Vertical Low 參數變亮 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入垂直最小值 7. 按 Clear (F4)取消 Clear 8. 按 F5 (Enter)保存設置...
  • Page 151 任意波形 11. 重複 4~9 步完成 Center (F3) 設置中心點 Center 設置 12. 按 F4 (Zoom In)沿波形的中 Zoom Zoom in 心放大。長度每次減小一 半。允許的最小垂直低點為- 2,最小垂直高點為 2 13. 按 F5 (Zoom out)縮小波形。 Zoom out 長度每次增加一倍。允許的 最大垂直低點為- 32767,最 大垂直高點為+32767 如下正弦波:垂直最低點-32767、垂直最高點 32767、中心點 0 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 152: 頁面導航(前移)

    AFG-3000 系列使用手冊 頁面導航(前移) 觀察波形時,使用 Next/Back Page 功能可以向前/ 背景 向後移動顯示視窗。 1. 按 ARB 鍵 面板操作 2. 按 F1 (Display) Display 3. 按 F4 (Back Page)將顯示視 Back Page 窗向前移動一個觀察長度 Horizon start*=Horizon start - Length Center*=Center – Length *Length 不小於 0 選擇 Back Page 後,螢幕顯示如下:...
  • Page 153: 頁面導航(後移)

    任意波形 頁面導航(後移) 觀察波形時,使用 Next/Back Page 功能可以向前/ 背景 向後移動顯示視窗。 1. 按 ARB 鍵 面板操作 2. 按 F1 (Display) Display 3. 按 F3 (Next Page)將顯示視 Next Page 窗向後移動一個觀察長度 Horizon start*=Horizon start + Length Center=Center + Length *Horizon start +Length≤1048576 選擇 Next Page 後,螢幕顯示如下: Horizon From: 10 ...
  • Page 154 AFG-3000 系列使用手冊 顯示 1. 按 ARB 鍵 面板操作 2. 按 F1 (Display) Display 3. 按 F5 (Overview)顯示整個波 Overview 形 水準: 0~1048575, 垂直: 32767~ -328767 選擇 Overview 後,螢幕顯示如下: Horizon From: 0  0 Length: 4001048576 Center:200 524288 Vertical low/high: ±32767 北京海洋兴业科技股份有限公司...
  • Page 155: 編輯任意波形

    任意波形 編輯任意波形 增加一個點 AFG-3000 提供強大的編輯功能,用戶可以在波形的 背景 任何位置建立點或線 1. 按 ARB 鍵 面板操作 2. 按 F2 (Edit) Edit 3. 按 F1 (Point) Point 4. 按 F1 (Address) Address 5. Address 參數呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入位址 7. 按 F5 (Enter)保存設置 Enter 8. 按 F6 (Return)返回上級選單...
  • Page 156: 增加一條線

    AFG-3000 系列使用手冊 10. Value 參數呈現亮紅色 11. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 Data 值 12. 按 F5 (Enter)保存設置 Enter 13. 按 F6 (Return)返回上級選單 Return 14. 再按 F6 (Return)返回 ARB Return 選單 如下圖,編輯區域顯示紅色: Address 40,Data 30,000 增加一條線 AFG-3000 提供強大的編輯功能,用戶可以在波形的 背景 任何位置建立點或線 1. 按 ARB 鍵...
  • Page 157 任意波形 2. 按 F2 (Edit) Edit 3. 按 F2 (Line) Line 4. 按 F1 (Start ADD) Start ADD 5. Start Address 參數呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 7. 按 F5 (Enter)保存設置 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步,完成 Start Data (F2), Stop Address (F3)和...
  • Page 158: 複製波形

    AFG-3000 系列使用手冊 複製波形 1. 按 ARB 鍵 面板操作 2. 按 F2 (Edit) Edit 3. 按 F3 (Copy) Copy 4. 按 F1 (Start) Start 5. Copy From 呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入複製波形的位址 7. 按 F5 (Enter)保存設置 Enter 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 159: 清除波形

    任意波形 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F2)和 Paste To (F3) 10. 按 F5 (Done)確定選擇 Done 11. 按 F6 (Return)返回上級選單 Return 將點 50~80 內的波形複製到點 100~130: Copy From: 50 Length: 30 To: 100 清除波形 1. 按 ARB 鍵 面板操作...
  • Page 160 AFG-3000 系列使用手冊 4. 按 F1 (Start) Start 5. Clear From 呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入清除波形的位址 7. 按 F5 (Enter)保存設置 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F2) Length 設置 10. 按 F3 (Done)清除部分任意波 Done 形 11. 按 F6 (Return)返回上級選單...
  • Page 161: Arb 保護

    任意波形 Start: 100, Length: 50. 清除部分波形後: 刪除整個波形後: ARB 保護 保護任意波形的某個區域不被改變。 1. 按 ARB 鍵 面板操作 2. 按 F2 (Edit) Edit 3. 按 F5 (Protect) Protect 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 162 AFG-3000 系列使用手冊 4. 按 F2 (Start) Start 5. Protect Start 呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入 Protect Start 位 址 7. 按 F5 (Enter)保存設置 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F3) Length 設置 10. 按 F5 (Done)確認保護區域...
  • Page 163 任意波形 16. 按 F5 (Unprotect)解除保護 解除保護 Unprotect 波形 17. 按 F6 (Done)確認 Done 18. 按 F6 (Return)返回上級選單 Return 19. 波形背景變回黑色。“Unprotected”呈灰色 波形保護區域以橘色背景顯示,如下圖: Start:0, Length: 200000 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 164: 輸出任意波形

    AFG-3000 系列使用手冊 輸出任意波形 訊號產生器能夠輸出高達 1 M(0~1048575)的任意波形,迴圈數可以指 定也可以無限次迴圈。 輸出任意波形 1. 按 ARB 鍵 面板操作 2. 按 F6 (Output) Output 3. 按 F1 (Start) Start 4. Start 參數呈現亮紅色 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 6. 按 F5 (Enter)確認起始點 Enter 7. 按 F6 (Return)返回上級選單 Return 8. 重複 4~7 步完成 Length (F2) Length 設置...
  • Page 165: 輸出 N 次迴圈的任意波形

    任意波形 前面板端子輸出如下波形: position 0,length 100 輸出 N 次迴圈的任意波形 以指定迴圈次數重複輸出任意波形。N Cycle 功能 背景 使用軟體觸發輸出。 1~1048575 次迴圈 範圍 1. 按 ARB 鍵 面板操作 2. 按 F6 (Output) Output 3. 定義任意波形輸出的 Start 和 Length 注意: 改變長度將改變脈衝波的占空比/頻率。 4. 按 F4 (N Cycle) N Cycle 5.
  • Page 166 AFG-3000 系列使用手冊 7. 使用方向鍵和可調旋鈕或數 位鍵盤輸入迴圈數 8. 按 F5 (Enter)確認迴圈數 Enter 9. 按 F6 (Return)返回上級選單 Return 10. 按 Trigger (F5)內部觸發輸出 Trigger (1 次) 注意: 按 F5 (Trigger)之前,請確保已經按下輸出鍵並 點亮 OUTPUT 指示燈。 11. 按 F6 (Return)返回上級選單 Return 前面板端子輸出 5 次迴圈的脈衝波,如下圖所示: 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 167: 輸出任意波形 - 無限迴圈

    任意波形 輸出任意波形 – 無限迴圈 背景 無限次重複輸出任意波形,建立一個迴圈波。 1. 按 ARB 鍵 面板操作 2. 按 F6 (Output) Output 3. 定義任意波輸出的 Start 和 Length 注意: 改變長度將改變脈衝波的占空比/頻率 4. 按 F5 (Infinite)無限次輸出任 Infinite 意波形 5. 按 F6 (Return)返回上級選單 Return 從前面板端子輸出無限次脈衝波,如下圖所示: 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 168: 輸出標記

    AFG-3000 系列使用手冊 輸出標記 1. 按 ARB 鍵 面板操作 2. 按 F6 (Output) Output 3. 按 F3 (Marker) Marker 4. 按 F1 (Start) Start 5. Start 參數呈現亮紅色 6. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 7. 按 F5 (Enter)確認起始點 Enter 8. 按 F6 (Return)返回上級選單 Return 9. 重複 4~8 步完成 Length (F2) Length 設置...
  • Page 169 任意波形 點 30~80 間的標記輸出如下圖所示: (Start 30, Length 50) 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 170: 存儲/調取任意波形

    AFG-3000 系列使用手冊 存儲/調取任意波形 AFG-3000 系列訊號產生器可以建立一些常見波形,包括正弦波、方 波、斜波、sinc、指數上升、指數下降和 DC 波形。 將波形保存至內部記憶體 1. 按 ARB 鍵 面板操作 2. 按 F4 (Save) Save 3. 按 F1 (Start) Start 4. Start 參數呈現亮紅色 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 6. 按 F5 (Enter)確認起始點 Enter 7. 按 F6 (Return)返回上級選單 Return 8.
  • Page 171: 將檔保存至 Usb 記憶體

    任意波形 11. 按 F1 (Select)將波形保存至 Select 所選檔 12. 按 F6 (Return)返回上級選單 Return 使用可調旋鈕選擇 ARB1 檔,如下圖所示: 將檔保存至 USB 記憶體 1. 按 ARB 鍵 面板操作 2. 按 F4 (Save) Save 3. 按 F1 (Start) Start 4. Start 參數呈現亮紅色 5. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始位址 6. 按 F5 (Enter)確認起始點 Enter 北京海洋兴业科技股份有限公司...
  • Page 172 AFG-3000 系列使用手冊 7. 按 F6 (Return)返回上級選單 Return 8. 重複 4~8 步完成 Length (F2) Length 設置 1. 按 F4 (USB) 2. 使用可調旋鈕查找檔案系統 3. 按 Select 選擇目錄或檔案名 Select 4. 按 F2 (New Folder) 建立資料夾 New Folder 5. 顯示預設資料夾名稱“NEW_FOL” New Folder: NEW_FOL 6. 使用可調旋鈕移動游標...
  • Page 173 任意波形 8. 按 F5 (Save)保存 Save 9. 按 F3 (New File) 建立新文件 New File 10. 顯示預設檔案名“NEW_FIL” New File(CSV): NEW_FIL 11. 使用可調旋鈕移動游標 12. 使用 F1 (Enter Char)或 F2 Enter Char Backspace (Backspace)建立檔案名 13. 按 F5 (Save)保存 Save 在根目錄下建立 ABC 資料夾和 AFG.CSV 文件,如圖 所示:...
  • Page 174: 從內部記憶體調取波形

    AFG-3000 系列使用手冊 從內部記憶體調取波形 1. 按 ARB 鍵 面板操作 2. 按 F5 (Load) Load 3. 按 F1 (Memory) Memory 4. 使用可調旋鈕查找檔案系統 5. 按 Select 選擇目錄或檔案名 Select 6. 按 F3 (To)選擇已調取波形的 起始點 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 175 任意波形 7. “Load To”呈現亮紅色 8. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始點 9. 按 F5 (Enter)確認起始點 Enter 10. 按 F6 (Return)返回上級選單 Return 11. 按 F5 (Done) Done 使用可調旋鈕選擇 ARB1 檔,調取波形的起始點為 0,如下圖所示: 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 176 AFG-3000 系列使用手冊 從 USB 調取波形 1. 按 ARB 鍵 面板操作 2. 按 F5 (Load) Load 3. 按 F2 (USB) 4. 使用可調旋鈕選擇檔案名 5. 按 F1 (Select)選擇檔 Select 6. 按 F3 (To)選擇已調取波形的 起始點 7. “Load To”呈現亮紅色 8. 使用方向鍵和可調旋鈕或數 位鍵盤輸入起始點 9. 按 F5 (Enter)確認起始點...
  • Page 177 任意波形 使用可調旋鈕選擇 AFG.CSV 文件,調取波形的起始 點為 0,如下圖所示: 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 178 Query Errors ............... 282 Arbitrary Waveform Errors ..........282 SCPI 狀態寄存器 .............. 284 Register types ..............284 AFG-3000 Status System ........... 285 Questionable Status Register ..........286 Standard Event Status Registers ........286 The Status Byte Register ............ 288 Output Queue ..............289 Error Queue................
  • Page 179: 確立遠端連接

    遠端介面 確立遠端連接 The AFG-3000 supports USB, RS232 and GPIB remote connections. Configure USB interface PC side connector Type A, host configuration Type B, slave AFG-3000 side connector 1.1/2.0 (full speed) Speed 1. Press the Utility key Panel Operation Interface UTIL followed by Interface (F2) and USB (F3).
  • Page 180: Configure Rs232 Interface

    AFG-3000 系列使用手冊 Configure RS232 interface DB-9, Male RS-232C Connector configuration 9600, 19200, 38400, 57600, Baud rate 115200 None/8Bits, Odd/7Bits, Parity Even/7Bits 1 (fixed) Stop bits 2: RxD (Receive data) Pin assignment 1 2 3 4 5 3: TxD (Transmit data)
  • Page 181: Configure Gpib Interface

    遠端介面 4. Press Parity/Bits (F2) and Parity/Bits choose a parity (F1)~(F3). None/8Bits Even/7bits Press return. Return Configure GPIB interface 24 pin Female GPIB Connector configuration 1-30 GPIB address Maximum 15 devices altogether, 20m cable GPIB constraints  length, 2m between each device Unique address assigned to each device ...
  • Page 182: Remote Control Terminal Connection

    This should return the Manufacturer, Model number, Serial number, and Firmware version in the following format. GW INSTEK, AFG-3081, SN:XXXXXXXX,Vm.mm Note: ^j or ^m can be used as the terminal character when using a terminal program. The proprietary PC software, downloadable from PC Software GWInstek website, can be used for remote control.
  • Page 183 遠端介面 When a remote connection is established all panel Display keys are locked bar F6. 1. Press REM/LOCK (F6) to REM/LOCK return the function generator to local mode. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 184: 指令語法

    AFG-3000 系列使用手冊 指令語法 IEEE488.2, 1992 (fully compatible) Compatible  standard SCPI, 1994 (partially compatible)  The SCPI standard is an ASCII based standard that Command Tree defines the command syntax and structure for programmable instruments. Commands are based on a hierarchical tree structure.
  • Page 185 遠端介面 A query is a simple or compound Query command followed by a question mark (?). A parameter (data) is returned. The maximum or minimum value for a parameter can also be queried where applicable. SOURce1:FREQuency? Example SOURce1:FREQuency? MIN Command forms Commands and queries have two different forms, long and short.
  • Page 186 AFG-3000 系列使用手冊 1: command header Command offset SOURce1:DCOffset < >LF Format 2: single space 3: parameter 4: message terminator Square Brackets [] Commands that contain squares brackets indicate that the contents are optional. The function of the command is the same with or without the square bracketed items.
  • Page 187 遠端介面 NRf type with a 1, 1.5, 4.5e-1 <NRf+> <Numeric> suffix including MAX, MIN, MINimum, MAXimum or DEFault parameters. Arbitrary ASCII <aard> characters. Discrete ASCII IMM, EXT, <discrete> character parameters NRf+ type 1 KHZ, 1.0 HZ, <frequency> including ΜHZ <peak deviation frequency unit in Hz>...
  • Page 188 AFG-3000 系列使用手冊 A space is used to separate a Command Space Separators parameter from a keyword/command header. A colon is used to separate Colon (:) keywords on each node. A semi colon is used to separate Semicolon (;) subcommands that have the same node level.
  • Page 189: 指令清單

    遠端介面 指令清單 系統指令 ................. 192 SYSTem:ERRor?..............192 *IDN? ................. 192 *RST..................193 *TST? .................. 193 SYSTem:VERSion? .............. 193 *OPC .................. 194 *OPC? ................. 194 *WAI ................... 194 SYSTem:LANGuage ............195 狀態寄存器指令 ............... 196 *CLS ..................196 *ESE ..................196 *ESR? .................. 197 *STB? ..................
  • Page 190 AFG-3000 系列使用手冊 脈衝設置指令 ..............216 SOURce[1]:PULSe:PERiod ..........216 SOURce[1]:PULSe:WIDTh..........217 幅值調製(AM)指令 ............218 AM 介紹 ................218 SOURce[1]:AM:STATe ............219 SOURce[1]:AM:SOURce ............ 219 SOURce[1]:AM:INTernal:FUNCtion ........220 SOURce[1]:AM:INTernal:FREQuency ........ 220 SOURce[1]:AM:DEPTh ............221 頻率調製(FM)指令 ............223 FM 介紹 ................223 SOURce[1]:FM:STATe ............224 SOURce[1]:FM:SOURce .............
  • Page 191 遠端介面 SOURce[1]:MARKer ............244 脈衝串模式指令 ............... 245 脈衝串模式介紹 ..............245 SOURce[1]:BURSt:STATe ........... 247 SOURce[1]:BURSt:MODE ..........247 SOURce[1]:BURSt:NCYCles ..........248 SOURce[1]:BURSt:INTernal:PERiod ........249 SOURce[1]:BURSt:PHASe ..........250 SOURce[1]:BURSt:TRIGger:SOURce ......... 250 SOURce[1]:BURSt:TRIGger:DELay ........251 SOURce[1]:BURSt:TRIGger:SLOPe ........252 SOURce[1]:BURSt:GATE:POLarity ........253 SOURce[1]:BURSt:OUTPut:TRIGger:SLOPe ..... 253 OUTPut:TRIGger ..............
  • Page 192: 系統指令

    AFG-3000 系列使用手冊 系統指令 SYSTem:ERRor? System Query Reads an error from the error queue. Description Query Syntax SYSTem:ERRor? Return parameter <string> Returns an error string, <256 ASCII characters. Example SYSTem:ERRor? -138 Suffix not allowed Returns an error string. *IDN? System Query...
  • Page 193: Rst

    The function generator passed the self-test. SYSTem:VERSion? System Query Performs a system version query. Returns a string Description with the instrument, firmware version, FPGA revision and bootloader. Query Syntax SYSTem:VERSion? Return parameter <string> Example SYST:VERS? AFG-3000 VX.XXX_XXXX FPGA:XXXX BootLoad:XXXX 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 194: Opc

    Description (bit 0) of the Standard Event Status Register after the function generator has completed all pending operations. For the AFG-3000, the *OPC command is used to indicate when a sweep or burst has completed. Before the OPC bit is set, other commands may be Note executed.
  • Page 195: System:language

    遠端介面 This command is only used for triggered sweep Note and burst modes. Syntax *WAI SYSTem:LANGuage System Command Sets or queries the display language. Select the Description language shown on the function generator front- panel display. Only one language can be enabled at a time.
  • Page 196: 狀態寄存器指令

    AFG-3000 系列使用手冊 狀態寄存器指令 *CLS System Command The *CLS command clears all the event registers, Description the error queue and cancels an *OPC command. Syntax *CLS *ESE System Command The Standard Event Status Enable command Description determines which events in the Standard Event Status Event register can set the Event Summary Bit (ESB) of the Status Byte register.
  • Page 197: Esr

    遠端介面 Bit 2 is set. *ESR? System Command Reads and clears the Standard Event Status Description Register. The bit weight of the standard event status register is returned. The *CLS will also clear the standard event status Note register. Query Syntax *ESR? Return Parameter Bit Register...
  • Page 198 AFG-3000 系列使用手冊 The *CLS command clears the status byte event Note register, but not the enable register. Syntax *SRE <enable value> <enable value> 0~255 Parameter Example *SRE 12 Sets a bit weight of 12 (bits 2 and 3) for the service request enable register.
  • Page 199: 介面設置指令

    遠端介面 介面設置指令 SYSTem:INTerface System Command Selects the remote interface. RS-232 is the factory Description default. There is no interface query. Note Syntax SYSTem:INTerface {GPIB|RS232|USB} Example SYST:INT USB Sets the interface to USB. SYSTem:LOCal System Command Sets the function generator to local mode. In local Description mode, all front panel keys are operational.
  • Page 200: 應用指令

    AFG-3000 系列使用手冊 應用指令 The APPLy command has 8 different types of outputs (Sine, Square, Ramp, Pulse, Noise, Triangle, DC, User). The command is the quickest, easiest way to output waveforms remotely. Frequency, amplitude and offset can be specified for each function.
  • Page 201 遠端介面 When setting the amplitude, MINimum, Output MAXimum and DEFault can be used. The range Amplitude depends on the function being used and the output termination (50Ω or high impedance). The default amplitude for all functions is 100 mVpp (50Ω). If the amplitude has been set and the output termination is changed from 50Ω...
  • Page 202: Source[1]:Apply:sinusoid

    AFG-3000 系列使用手冊 The offset is also determined by the output termination (50Ω or high impedance). If the offset has been set and the output termination has changed from 50Ω to high impedance, the offset will double. Changing the output termination from high impedance to 50Ω...
  • Page 203: Source[1]:Apply:ramp

    遠端介面 amplitude < > 10mV~10V (50Ω) <offset> 0~4.99V (50Ω) Example SOUR1:APPL:SQU 2KHZ,MAX,MAX Sets frequency to 2kHz and sets the amplitude and offset to the maximum. Source Specific SOURce[1]:APPLy:RAMP Command Outputs a ramp wave from the selected channel Description when the command has executed. Frequency, amplitude and offset can also be set.
  • Page 204: Source[1]:Apply:noise

    AFG-3000 系列使用手冊 The PW settings from the SOURce[1]:PULS: WIDT Note command are preserved. Edge and pulse width may be adjusted to supported levels. Repetition rates will be approximated from the frequency. For accurate repetition rates, the period should be adjusted using the...
  • Page 205: Source[1]:Apply:triangle

    遠端介面 Sets the amplitude to 3 volts with an offset of 1 volt. Source Specific SOURce[1]:APPLy:TRIangle Command Outputs a triangle wave from the selected channel Description when the command has executed. Frequency, amplitude and offset can also be set. Syntax SOURce[1]:APPLy:TRIangle [<frequency>...
  • Page 206: Source[1]:Apply:user

    AFG-3000 系列使用手冊 Sets the DC offset to 1 volt. Source Specific SOURce[1]:APPLy:USER Command Outputs an arbitrary waveform from the selected Description channel. The output is that specified from the FUNC:USER command. Frequency and amplitude cannot be used with the Note DC function;...
  • Page 207: 輸出指令

    遠端介面 輸出指令 Unlike the Apply commands, the Output commands are low level commands to program the function generator. This section describes the low-level commands used to program the function generator. Although the APPLy command provides the most straightforward method to program the function generator, the low-level commands give you more flexibility to change individual parameters.
  • Page 208: Source[1]:Frequency

    AFG-3000 系列使用手冊 Sine Squ Ramp Pulse Noise ARB                             SWEEP   ...
  • Page 209: Source[1]:Amplitude

    遠端介面 User 1μHz~100MHz If the function mode is changed and the current frequency setting is not supported by the new mode, the frequency setting will be altered to next highest value. The duty cycle of square waveforms depends on the frequency settings.
  • Page 210 AFG-3000 系列使用手冊 The maximum and minimum amplitude depends Note on the output termination. The default amplitude for all functions is 100 mVpp (50Ω). If the amplitude has been set and the output termination is changed from 50Ω to high impedance, the amplitude will double.
  • Page 211: Source[1]:Dcoffset

    遠端介面 +5.0000E+00 The maximum amplitude that can be set for the current function is 5 volts. Source Specific SOURce[1]:DCOffset Command Sets or queries the DC offset for the current mode. Description Note The offset parameter can be set to MINimum, MAXimum or DEFault.
  • Page 212: Source[1]:Square:dcycle

    AFG-3000 系列使用手冊 +3.0000E+00 The offset for the current mode is set to +3 volts. Source Specific SOURce[1]:SQUare:DCYCle Command Sets or queries the duty cycle for square waves Description only. The setting is remembered if the function mode is changed. The default duty cycle is 50%.
  • Page 213: Source[1]:Ramp:symmetry

    遠端介面 Source Specific SOURce[1]:RAMP:SYMMetry Command Sets or queries the symmetry for ramp waves only. Description The setting is remembered if the function mode is changed. The default symmetry is 50%. For ramp waveforms, the Apply command and Note AM/FM modulation modes ignore the current symmetry settings.
  • Page 214: Output:load

    AFG-3000 系列使用手冊 Example OUTP ON Turns the output on. Query Syntax OUTPut? Return Parameter 1 Example OUTP? The output is currently on. Source Specific OUTPut:LOAD Command Sets or queries the output termination. Two Description impedance settings can be chosen, DEFault (50Ω) and INFinity (high impedance >10 kΩ).
  • Page 215: Source[1]:Voltage:unit

    遠端介面 Example OUTP:LOAD? The output is set to the default of 50Ω. Source Specific SOURce[1]:VOLTage:UNIT Command Sets or queries the output amplitude units. There Description are three types of units: VPP, VRMS and DBM. The units set with the VOLTage:UNIT command Note will be used as the default unit for all amplitude units unless a different unit is specifically used for...
  • Page 216: 脈衝設置指令

    AFG-3000 系列使用手冊 脈衝設置指令 The pulse chapter is used to control and output pulse waveforms. Unlike the APPLy command, low level control is possible including setting the rise time, fall time, period and pulse width. Period Pulse Width Rise time Fall time...
  • Page 217: Source[1]:Pulse:width

    遠端介面 Return Parameter <seconds> 20 ns ~ 2000 seconds Example SOUR1:PULS:PER? +1.0000E+01 The period is set to 10 seconds. Source Specific SOURce[1]:PULSe:WIDTh Command Sets or queries the pulse width. The default pulse Description width is 100us. The minimum pulse width is affected by the period time.
  • Page 218: 幅值調製(Am)指令

    AFG-3000 系列使用手冊 幅值調製(AM)指令 AM 介紹 To successfully create an AM waveform, the following commands must be executed in order. 1. Turn on AM modulation using the Enable AM Modulation SOURce[1]: AM:STAT ON command Configure Carrier 2. Use the APPLy command to select a carrier waveform.
  • Page 219: Source[1]:Am:state

    遠端介面 Source Specific SOURce[1]:AM:STATe Command Sets or disables AM modulation. By default AM Description modulation is disabled. AM modulation must be enabled before setting other parameters. Burst or sweep mode will be disabled if AM Note modulation is enabled. As only one modulation is allowed at any one time, other modulation modes will be disabled when AM modulation is enabled.
  • Page 220: Source[1]:Am:internal:function

    AFG-3000 系列使用手冊 Sets the modulation source to external. Query Syntax SOURce[1]:AM:SOURce? Return Parameter INT Internal External Example SOUR1:AM:SOUR? The modulation source is set to internal. Source Specific SOURce[1]:AM:INTernal:FUNCtion Command Sets the shape of the modulating waveform from Description sine, square, triangle, upramp and dnramp. The default shape is sine.
  • Page 221: Source[1]:Am:depth

    遠端介面 Syntax SOURce[1]:AM:INTernal:FREQuency {<frequency>|MINimum|MAXimum} Parameter <frequency> 2 mHz~ 20 kHz Example SOUR1:AM:INT:FREQ +1.0000E+02 Sets the modulating frequency to 100Hz. Query Syntax SOURce[1]:AM:INTernal:FREQuency? [MINimum|MAXimum] Return Parameter <NR3> Returns the frequency in Example SOUR1:AM:INT:FREQ? MIN +1.0000E+02 Returns the minimum frequency allowed. Source Specific SOURce[1]:AM:DEPTh Command Sets or queries the modulation depth for internal...
  • Page 222 AFG-3000 系列使用手冊 Example SOUR1:AM:DEPT? +1.0000E+02 The modulation depth is 100%. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 223: 頻率調製(Fm)指令

    遠端介面 頻率調製(FM)指令 FM 介紹 The following is an overview of the steps required to generate an FM waveform. 1. Turn on FM modulation using the SOURce[1]: Enable FM Modulation FM:STAT ON command. 2. Use the APPLy command to select a carrier Configure Carrier waveform.
  • Page 224: Source[1]:Fm:state

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:FM:STATe Command Sets or disables FM modulation. By default FM Description modulation is disabled. FM modulation must be enabled before setting other parameters. Burst or sweep mode will be disabled if FM Note modulation is enabled. As only one modulation is allowed at any one time, other modulation modes will be disabled when FM modulation is enabled.
  • Page 225: Source[1]:Fm:internal:function

    遠端介面 Example SOUR1:FM:SOUR EXT Sets the modulation source to external. Query Syntax SOURce[1]:FM:SOURce? Return Parameter INT Internal External Example SOUR1:FM:SOUR? The modulation source is set to internal. Source Specific SOURce[1]:FM:INTernal:FUNCtion Command Sets the shape of the modulating waveform from Description sine, square, triangle, upramp and dnramp.
  • Page 226: Source[1]:Fm:internal:frequency

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:FM:INTernal:FREQuency Command Sets the frequency of the internal modulating Description waveform only. The default frequency is 10Hz. Syntax SOURce[1]:FM:INTernal:FREQuency {<frequency>|MINimum|MAXimum} Parameter <frequency> 2 mHz~ 20 kHz Example SOUR1:FM:INT:FREQ +1.0000E+02 Sets the modulating frequency to 100Hz. Query Syntax...
  • Page 227 遠端介面 equal to the peak deviation frequency. The sum of the deviation and carrier frequency must not exceed the maximum frequency for a specific carrier shape. If an out of range deviation is set for any of the above conditions, the deviation will be automatically adjusted to the maximum value allowed and an “out of range”...
  • Page 228: 頻移鍵控(Fsk)指令

    AFG-3000 系列使用手冊 頻移鍵控(FSK)指令 FSK 介紹 The following is an overview of the steps required to generate an FSK modulated waveform. 1. Turn on FSK modulation using the Enable FSK SOURce[1]: FSK:STAT ON command. Modulation Configure Carrier 2. Use the APPLy command to select a carrier waveform.
  • Page 229: Source[1]:Fskey:source

    遠端介面 Example SOUR1:FSK:STAT ON Enables FSK modulation Query Syntax SOURce[1]:FSKey:STATe? Return Parameter 0 Disabled (OFF) Enabled (ON) Example SOUR1:FSK:STAT? FSK modulation is currently enabled. Source Specific SOURce[1]:FSKey:SOURce Command Sets or queries the FSK source as internal or Description external. Internal is the default source. If an external FSK source is selected, FSK rate is Note controlled by the Trigger INPUT terminal on the...
  • Page 230: Source[1]:Fskey:internal:rate

    AFG-3000 系列使用手冊 For FSK, the modulating waveform is a square Note wave with a duty cycle of 50%. Syntax SOURce[1]:FSKey:FREQuency {<frequency>|MINimum|MAXimum} 1 μHz~ 80 MHz(3081)/ Parameter <frequency> 50MHz(3051) Example SOUR1:FSK:FREQ +1.0000E+02 Sets the FSK hop frequency to to 100Hz. SOURce[1]:FSKey:FREQuency?
  • Page 231: 脈寬調製(Pwm)指令

    遠端介面 脈寬調製(PWM)指令 PWM 介紹 The following is an overview of the steps required to generate a PWM modulated waveform. 1. Turn on PWM modulation using the Enable PWM Modulation SOURce[1]: PWM:STATe ON command. 2. Use the APPLy command to select a pulse Configure Carrier waveform.
  • Page 232: Source[1]:Pwm:source

    AFG-3000 系列使用手冊 Burst or sweep mode will be disabled if PWM Note modulation is enabled. As only one modulation is allowed at any one time, other modulation modes will be disabled when FSK modulation is enabled. Syntax SOURce[1]:PWM:STATe {OFF|ON} Example...
  • Page 233: Source[1]:Pwm:internal:function

    遠端介面 Source Specific SOURce[1]:PWM:INTernal:FUNction Command Sets the shape of the modulating waveform from Description sine, square, triangle, upramp and dnramp. The default shape is sine. Square and triangle waveforms have a 50% duty Note cycle. Upramp and dnramp have a symmetry to 100% and 0%, respectively.
  • Page 234: Source[1]:Pwm:duty

    AFG-3000 系列使用手冊 Query Syntax SOURce[1]:PWM:INTernal:FREQuency? Return Parameter <NR3> Returns the frequency in Example SOUR1:PWM:INT:FREQ? MAX +2.0000E+04 Returns the modulating frequency. (20kHz) Source Specific SOURce[1]:PWM:DUTY Command Sets or queries the duty cycle deviation. The Description default duty cycle is 50%. The duty cycle is limited by period, edge time and Note minimum pulse width.
  • Page 235: 頻率掃描指令

    遠端介面 頻率掃描指令 掃描介紹 Below shows the order in which commands must be executed to perform a sweep. 1. Turn on Sweep mode modulation using the Enable Sweep Mode SOURce[1]: SWE:STAT ON command. 2. Use the APPLy command to select the Select waveform waveform shape.
  • Page 236: Source[1]:Sweep:state

    AFG-3000 系列使用手冊 5. Choose the sweep time using the Select Sweep SOURce[1]:SWE:TIME command. Time 6. Select an internal or external sweep trigger Select the sweep source using the SOURce[1]:SOUR command. trigger source 7. To output a marker frequency from the SYNC...
  • Page 237: Source[1]:Frequency:start

    遠端介面 Source Specific SOURce[1]:FREQuency:STARt Command Sets the start frequency of the sweep. 100Hz is the Description default start frequency. To sweep up or down, set the stop frequency Note higher or lower than the start frequency. Syntax SOURce[1]:FREQuency:STARt {<frequency>|MINimum|MAXimum} Parameter <frequency>...
  • Page 238: Source[1]:Frequency:center

    AFG-3000 系列使用手冊 Example SOUR1:FREQ:STOP +2.0000E+03 Sets the stop frequency to 2kHz. Query Syntax SOURce[1]:FREQuency:STOP? [MINimum| MAXimum] Return Parameter <NR3> Returns the stop frequency in Hz. Example SOUR1:FREQ:STOP? MAX +8.0000E+07 Returns the maximum stop frequency allowed. Source Specific SOURce[1]:FREQuency:CENTer Command Sets and queries the center frequency of the sweep.
  • Page 239: Source[1]:Frequency:span

    遠端介面 Source Specific SOURce[1]:FREQuency:SPAN Command Sets and queries the frequency span of the sweep. Description 900 Hz is the default frequency span. The span frequency is equal to the stop-start frequencies. To sweep up or down, set the span as positive or Note negative.
  • Page 240: Source[1]:Sweep:time

    AFG-3000 系列使用手冊 Query Syntax SOURce[1]:SWEep:SPACing? Return Parameter LIN Linear spacing Logarithmic spacing Example SOUR1:SWE:SPAC? The spacing is currently set as linear. Source Specific SOURce[1]:SWEep:TIME Command Sets or queries the sweep time. The default sweep Description time is 1 second. The function generator automatically determines...
  • Page 241: Source[1]:Sweep:source

    遠端介面 Source Specific SOURce[1]:SWEep:SOURce Command Sets or queries the trigger source as immediate Description (internal), external or manual. Immediate (internal) is the default trigger source. IMMediate will constantly output a swept waveform. EXTernal will output a swept waveform after each external trigger pulse.
  • Page 242: Output[1]:Trigger

    AFG-3000 系列使用手冊 The Trig out signal depends on the selected trigger Note source. Trigger Source Description Immediate A square wave is output from the Trig out terminal with a 50% duty cycle at the start of every sweep. External Trigger Output is disconnected.
  • Page 243: Source[1]:Marker:frequency

    遠端介面 Example OUTP1:TRIG? The Trig out signal is enabled. Source Specific SOURce[1]:MARKer:FREQuency Command Sets or queries the marker frequency. The default Description marker frequency is 500 Hz. The marker frequency is used to output a SYNC signal from the SYNC terminal on the front panel.
  • Page 244: Source[1]:Marker

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:MARKer Command Turns the marker frequency on or off. The default Description is off. MARKer ON The SYNC signal goes logically Note high at the start of each sweep and goes low at the marker frequency.
  • Page 245: 脈衝串模式指令

    遠端介面 脈衝串模式指令 脈衝串模式介紹 Burst mode can be configured to use an internal trigger (N Cycle mode) or an external trigger (Gate mode) using the Trigger INPUT terminal on the rear panel. Using N Cycle mode, each time the function generator receives a trigger, the function generator will output a specified number of waveform cycles (burst).
  • Page 246 AFG-3000 系列使用手冊 The following is an overview of the steps required to generate a burst waveform. 1. Turn on Burst mode using the Enable Burst SOURce[1]:BURS:STAT ON command. Mode Configuration 2. Use the APPLy command to select a sine, square, ramp, pulse or triangle burst waveform*.
  • Page 247: Source[1]:Burst:state

    遠端介面 Source Specific SOURce[1]:BURSt:STATe Command Turns burst mode on or off. By default burst mode Description is turned off. When burst mode is turned on, sweep and any Note modulation modes are disabled. Syntax SOURce[1]:BURSt:STATe {OFF|ON} Example SOUR1:BURS:STAT OFF Turns burst mode on. Query Syntax SOURce[1]:BURSt:STATe? Return Parameter 0...
  • Page 248: Source[1]:Burst:ncycles

    AFG-3000 系列使用手冊 Example SOUR1:BURS:MODE? TRIG The current burst mode is triggered. Source Specific SOURce[1]:BURSt:NCYCles Command Sets or queries the number of cycles (burst count) Description in triggered burst mode. The default number of cycles is 1. The burst count is ignored in gated mode.
  • Page 249: Source[1]:Burst:internal:period

    遠端介面 Example SOUR1:BURS:NCYC? +1.0000E+02 The burst cycles are set to 100. Source Specific SOURce[1]:BURSt:INTernal:PERiod Command Sets or queries the burst period. Burst period Description settings are only applicable when the trigger is set to immediate. The default burst period is 10 ms. During manual triggering, external triggering or Gate burst mode, the burst period settings are ignored.
  • Page 250: Source[1]:Burst:phase

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:BURSt:PHASe Command Sets or queries the starting phase for the burst. The Description default phase is 0 degrees. At 0 degrees, sine square and ramp waveforms are at 0 volts. In gated burst mode, waveforms are continuously output (burst) when the Trig signal is true.
  • Page 251: Source[1]:Burst:trigger:delay

    遠端介面 A burst is output at a set Immediate frequency determined by the burst period. External EXTernal will output a burst waveform after each external trigger pulse. Any additional trigger pulse signals before the end of the burst are ignored. Manual Manual triggering will output a burst waveform after the trigger...
  • Page 252: Source[1]:Burst:trigger:slope

    AFG-3000 系列使用手冊 Syntax SOURce[1]: BURSt:TRIGger:DELay {<seconds>|MINimum|MAXimum} Parameter <seconds> 0~85 seconds Example SOUR1:BURS:TRIG:DEL +1.0000E+01 Sets the trigger delay to 10 seconds. Query Syntax SOURce[1]:BURSt:TRIGger:DELay? [MINimum|MAXimum] Return Parameter <NRf> Delay in seconds Example SOUR1:BURS:TRIG:DEL +1.0000E+01 The trigger delay is 10 seconds. Source Specific...
  • Page 253: Source[1]:Burst:gate:polarity

    遠端介面 Source Specific SOURce[1]:BURSt:GATE:POLarity Command In gated mode, the function generator will output Description a waveform continuously while the external trigger receives logically true signal from the Trigger INPUT terminal. Normally a signal is logically true when it is high. The logical level can be inverted so that a low signal is considered true.
  • Page 254: Output:trigger

    AFG-3000 系列使用手冊 50% duty cycle square wave is Immediate output at the start of each burst. External Trigger output disabled. Gated mode Trigger output disabled. A >1 ms pulse is output at the Manual start of each burst. Syntax SOURce[1]:BURSt:OUTPut:TRIGger:SLOPe...
  • Page 255 遠端介面 Query Syntax OUTPut[1]:TRIGger? Return Parameter 0 Disabled Enabled Query Example OUTP1:TRIG? The trigger output is enabled. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 256: 任意波形指令

    AFG-3000 系列使用手冊 任意波形指令 任意波形介紹 Use the steps below to output an arbitrary waveform over the remote interface. 1. Use the SOURce[1]:FUNCtion USER Output Arbitrary Waveform command to output the arbitrary waveform currently selected in memory. 2. Use the APPLy command to select frequency, Select Waveform amplitude and DC offset.
  • Page 257: Source[1]:Function User

    遠端介面 Source Specific SOURce[1]:FUNCtion USER Command Use the SOURce[1]:FUNCtion USER command to Description output the arbitrary waveform currently selected in memory. The waveform is output with the current frequency, amplitude and offset settings. Syntax SOURce[1]:FUNCtion USER Example SOUR1:FUNC USER Selects and outputs the current waveform in memory.
  • Page 258: Source[1]:Arb:edit:copy

    AFG-3000 系列使用手冊 Syntax DATA:DAC VOLATILE, <start>,{<binary block>|<value>, <value>, . . . } Parameter <start> Start address of the arbitrary waveform <binary block> <value> Decimal or integer values ±32767 Example DATA:DAC VOLATILE, #216 Binary Data The command above downloads 5 data values (stored in 16 bytes) using the binary block format.
  • Page 259: Source[1]:Arb:edit:delete:all

    遠端介面 A waveform/waveform segment cannot be Note deleted when output. Syntax SOURce[1]:ARB:EDIT:DELete [<STARt>[,<LENGth>]] Parameter <STARt> Start address: 0~1048,576 <LENGth> 0 ~ 1048,576 Example SOURce1:ARB:EDIT:DEL 1000, 256 Deletes a section of 256 data points from the waveform starting at address 1000. Source Specific SOURce[1]:ARB:EDIT:DELete:ALL Command...
  • Page 260: Source[1]:Arb:edit:line

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:ARB:EDIT:LINE Command Edit a line on the arbitrary waveform. The line is Description created with a starting address and data point and a finishing address and data point. A waveform/waveform segment cannot be Note deleted when output.
  • Page 261: Source[1]:Arb:edit:protect:all

    遠端介面 Source Specific SOURce[1]:ARB:EDIT:PROTect:ALL Command Protects the arbitrary waveform currently in non- Description volatile memory/ currently being output. Syntax SOURce[1]:ARB:EDIT:PROTect:ALL Example SOUR1:ARB:EDIT:PROT:ALL Source Specific SOURce[1]:ARB:EDIT:UNProtect Command Uprotects the arbitrary waveform currently in non- Description volatile memory/currently being output. Syntax SOURce[1]:ARB:EDIT:UNProtect Example SOUR1:ARB:EDIT:UNP Source Specific...
  • Page 262: Source[1]:Arb:built:pulse

    AFG-3000 系列使用手冊 Syntax SOURce[1]:ARB:BUILt:SQUare [<STARt>[,<LENGth>[,<SCALe>]]] Parameter <STARt> Start address*: 0~1048,576 <LENGth> Length*: 0 ~ 1048,576 <SCALe> Scale: ±32767 * Start + Length ≤ 1,048,576 Example SOUR1:ARB:BUIL:SQU 1000, 1000, 100 Creates a square wave 1000 points in length with a scale of 100 and a start address of 1000.
  • Page 263: Source[1]:Arb:built:ramp

    遠端介面 Source Specific SOURce[1]:ARB:BUILt:RAMP Command Creates a ramp wave with a specified start Description address, length and scale. Syntax SOURce[1]:ARB:BUILt:RAMP[<STARt>[,<LENGth>[,<S CALe>]]] Parameter <STARt> Start address*: 0~1048,576 <LENGth> Length*: 0 ~ 1048,576 <SCALe> Scale: ±32767 * Start + Length ≤ 1,048,576 Example SOUR1:ARB:BUIL:RAMP 1000, 1000, 100 Creates a ramp wave 1000 points in length with a...
  • Page 264: Source[1]:Arb:built:exprise

    AFG-3000 系列使用手冊 Source Specific SOURce[1]:ARB:BUILt:EXPRise Command Creates an exponential rise wave with a specified Description start address, length and scale. Syntax SOURce[1]:ARB:BUILt:EXPRise [<STARt>[,<LENGth>[,<SCALe>]]] Parameter <STARt> Start address*: 0~1048,576 <LENGth> Length*: 0 ~ 1048,576 <SCALe> Scale: ±32767 * Start + Length ≤ 1,048,576...
  • Page 265: Source[1]:Arb:built:dc

    遠端介面 Source Specific SOURce[1]:ARB:BUILt:DC Command Creates an exponential fall wave with a specified Description start address, length and scale. Syntax SOURce[1]:ARB:BUILt:DC [<STARt>[,<LENGth>[,<SCALe>]]] Parameter <STARt> Start address*: 0~1048,576 <LENGth> Length*: 0 ~ 1048,576 <SCALe> Scale: ±32767 * Start + Length ≤ 1,048,576 Example SOUR1:ARB:BUIL:DC 1000, 1000, 100 Creates an exponential fall wave 1000 points in...
  • Page 266: Source[1]:Arb:output:marker

    AFG-3000 系列使用手冊 Return Parameter <NR3> Returns the number of cycles. INF is returned if the number of cycles is continuous. Example SOUR1:ARB:NCYC? +1.0000E+02 The number of ARB waveform output cycles is returned (100). Source Specific SOURce[1]:ARB:OUTPut:MARKer Command Define a section of the arbitrary waveform for Description marker output.
  • Page 267 遠端介面 Example SOUR1:ARB:OUTP 20 200 Outputs the current arbitrary waveform in memory. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 268: 存儲和調取指令

    AFG-3000 系列使用手冊 存儲和調取指令 Up to 10 different instrument states can be stored to non-volatile memory (memory locations 0~9). Instrument *SAV Command Saves the current instrument state to a specified Description save slot. When a state is saved, all the current instrument settings, functions and waveforms are also saved.
  • Page 269: Memory:state:delete All

    遠端介面 Delete instrument state from memory location 0. Instrument MEMory:STATe:DELete ALL Command Delete memory from all memory locations, 0~9. Description Syntax MEMory:STATe:DELete ALL Example MEM:STAT:DEL ALL Deletes all the instrument states from memory locations 0~9. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 270: 錯誤資訊

    AFG-3000 系列使用手冊 錯誤資訊 The AFG-3000 has a number of specific error codes. Use the SYSTem:ERRor command to recall the error codes. Command Error Codes -101 Invalid character An invalid character was used in the command string. Example: #, $, %.
  • Page 271 遠端介面 A command header contains more than 12 characters: OUTP:SYNCHRONIZATION ON -113 Undefined header An undefined header was encountered. The header is syntactically correct. Example: the header contains a character mistake. SOUR1:AMM:DEPT MIN -123 Exponent too large Numeric exponent exceeds 32,000. Example: SOURce[1]:BURSt:NCYCles 1E34000 -124 Too many digits The mantissa (excluding leading 0’s) contains more...
  • Page 272: Execution Errors

    AFG-3000 系列使用手冊 An unexpected character string was used where none were expected. Example: A character string is used instead of a valid parameter. SOURce1:SWEep:SPACing ’TEN’ -161 Invalid block data Invalid block data was received. Example: The number of bytes sent with the DATA:DAC command doesn’t correlate to the number of bytes...
  • Page 273 遠端介面 -221 Settings conflict; infinite burst changed trigger source to MANual Example: The trigger source is changed to immediate from manual when infinite burst mode is selected. -221 Settings conflict; burst period increased to fit entire burst Example: The function generator automatically increases the burst period to allow for the burst count or frequency.
  • Page 274 AFG-3000 系列使用手冊 -221 Settings conflict;trigger output connector used by trigger external Example: The trigger output connector is disabled when the trigger source is set to external. -221 Settings conflict;frequency reduced for pulse function Example: When the function is changed to pulse, the output frequency is automatically reduced if over range.
  • Page 275 遠端介面 -221 Settings conflict;AM turned off by selection of other mode or modulation Example: AM mode is disabled when burst, sweep or a modulation mode is enabled. -221 Settings conflict; sweep turned off by selection of other mode or modulation Example: Sweep mode is disabled when burst or a modulation mode is enabled.
  • Page 276 AFG-3000 系列使用手冊 -221 Settings conflict;not able to burst dc, burst turned off Example: The burst function cannot be used with the dc voltage function. -221 Settings conflict;not able to sweep noise, sweep turned off Example: A waveform cannot be swept using the noise function.
  • Page 277 遠端介面 -221 Settings conflict;offset changed due to amplitude Example: The offset is not a valid offset value, it is automatically adjusted, considering the amplitude. |offset|≤ max amplitude – Vpp/2 -221 Settings conflict;amplitude changed due to offset Example: The amplitude is not a valid value, it is automatically adjusted, considering the offset.
  • Page 278 AFG-3000 系列使用手冊 -222 Data out of range;frequency; value clipped to ... Example: If the frequency was set to a value out of range, it is automatically set to an upper or lower limit. -222 Data out of range;user frequency; value clipped to upper limit...
  • Page 279 遠端介面 -222 Data out of range; burst period limited by length of burst; value clipped to upper limit Example: The burst period must be greater than burst count divided by the frequency + 200 ns. The burst period is adjusted to satisfy these conditions. burst period >...
  • Page 280 AFG-3000 系列使用手冊 -222 Data out of range;marker confined to sweep span; value clipped to ... Example: The marker frequency is set to a value outside the start or stop frequencies. The marker frequency is automatically adjusted to either the start or stop frequency (whichever is closer to the set value).
  • Page 281 遠端介面 -313 Calibration memory lost;memory corruption detected Indicates that a fault (check sum error) has occurred with the non-volatile memory that stores the calibration data. -314 Save/recall memory lost;memory corruption detected Indicates that a fault (check sum error) has occurred with the non-volatile memory that stores the save/recall files.
  • Page 282: Query Errors

    AFG-3000 系列使用手冊 Query Errors -410 Query INTERRUPTED Indicates that a command was received but the data in the output buffer from a previous command was lost. -420 Query UNTERMINATED The function generator is ready to return data, however there was no data in the output buffer. For example: Using the APPLy command.
  • Page 283 遠端介面 800 Block length must be even Example: As block data (DATA:DAC VOLATILE) uses two bytes to store each data point, there must be an even number or bytes for a data block. 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 284: Scpi 狀態寄存器

    AFG-3000 系列使用手冊 SCPI 狀態寄存器 The status registers are used to record and determine the status of the function generator. The function generator has a number of register groups: Questionable Status Registers Standard Event Status Registers Status Byte Register As well as the output and error queues.
  • Page 285: Afg-3000 Status System

    遠端介面 AFG-3000 Status System Questionable Status Register Condition Event Enable 0 Volt Ovld <1> <2> <4> <8> 4 Over Temp <16> 5 Loop Unlock <32> Error Queue <64> 7 Ext Mod Ovld <128> 8 Cal Error <256> 9 External Ref <512>...
  • Page 286: Questionable Status Register

    AFG-3000 系列使用手冊 Questionable Status Register The Questionable Status Registers will show if any Description faults or errors have occurred. Bit Summary Register Bit Weight Voltage overload Over temperature Loop unlock Ext Mod Overload Cal Error External Reference Standard Event Status Registers...
  • Page 287 遠端介面 Bit Summary Register Bit Weight Operation complete bit Query Error Device Error Execution Error Command Error Power On Operation The operation complete bit is set Error Bits complete when all selected pending operations are complete. This bit is set in response to the *OPC command.
  • Page 288: The Status Byte Register

    AFG-3000 系列使用手冊 The Status Byte Register The Status Byte register consolidates the status Description events of all the status registers. The Status Byte register can be read with the *STB? query or a serial poll and can be cleared with the *CLS command.
  • Page 289: Output Queue

    遠端介面 Standard Event The Event Status bit is set if an “enabled” event in the Standard Event Status Event Register has occurred. Master The Master Summary Status is Summary/ used with the *STB? query. When Service the *STB? query is read the MSS Request bit bit is not cleared.
  • Page 290 AFG-3000 系列使用手冊 附 錄 保險絲更換 1. 拔去電源線並使用螺絲刀取出保險絲座 步驟 2. 更換保險絲 T0.63A, 250V 額定值 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
  • Page 291 附錄 AFG-3000 系列規格 此規格適用條件:+20°C~+30°C,開機 30 分鐘以上。 波形 AFG-3051 AFG-3081 正弦波, 方波, 斜波, 脈衝波, 雜訊波, DC, Sin(x)/x, 指數上升, 指數下降, 負斜波 任意波形 ARB 功能 內置 取樣速率 200 MSa/s 重建率 100MHz 1M 點 波形長度 幅度解析度 16 位 非易失性記憶體 10 組 1M 波形(1) 從 2~1M 點任選...
  • Page 292 AFG-3000 系列使用手冊 單位 Vpp, Vrms, dBm, ±5 Vpk ac +dc (接 50Ω) 偏移 範圍 ±10Vpk ac +dc (開路) 1%設置值 + 2 mV + 0.5%幅值 精確度 50Ω 典型值(固定) 波形輸出 阻抗 > 10MΩ (輸出關閉) 保護 短路保護 超載繼電器自動禁用主輸出 TTL-compatible into>1kΩ 同步輸出 範圍 50Ω 正常值...
  • Page 293 附錄 脈衝寬度 8ns~ 1999.9s 最小脈衝寬度: FREQ≦50MHz:8nS FREQ≦6.5MHz:5%週期值 解析度: FREQ≦50MHz:1nS FREQ≦6.5MHz:1%週期值 <5% 過激訊號 100 ppm +50 ps 抖動 AM 調製 載波波形 正弦波, 方波, 三角波, 斜波, 脈衝波, 任 意波 調製波形 正弦波, 方波, 三角波, 正/負斜波 2 mHz~20 kHz 調製頻率 0%~120.0% 深度 源 內部/外部 FM 調製...
  • Page 294 AFG-3000 系列使用手冊 標記 標記訊號的下降沿 (可程式設計) 源 內部/外部 脈衝串 波形 正弦波, 方波, 三角波, 斜波 1 μHz~50 MHz(4) 1 μHz~80 MHz(4) 頻率 1~1000000 次迴圈或無限 脈衝串計數 起始/停止相位 -360.0∘~+360.0∘ 內部週期 1 ms~500 s 門電路源 外部觸發 觸發源 單次, 外部或內部 觸發延遲 N 次迴圈, 無限 0s~85 s 外部調製輸入...
  • Page 295 附錄 準位 TTL Compatible into 50Ω 扇出 ≥4 TTL load 阻抗 50Ω 典型值 存儲/調取 10 組設置存儲 GPIB, RS232, USB 介面 4.3’’ TFT LCD 顯示 480 × 3 (RGB) × 272 系統特性 配置時間 函數改變: (典型值) 標準---->102ms 脈衝-------->660ms 內置任意波形->240ms 頻率改變: 24ms 幅值改變: 50ms 偏移改變: 50ms 選擇用戶定義的任意波形: <...
  • Page 296 AFG-3000 系列使用手冊 操作環境 適合溫度: 18 ~ 28˚C 操作溫度: 0 ~ 40˚C 相對濕度: ≤ 80%, 0 ~ 40˚C ≤ 70%, 35 ~ 40˚C 安裝等級:CAT Ⅱ 2000m 海拔 污染程度 IEC 61010 2 級, 室內使用 存儲溫度 -10~70˚C, 濕度: ≤70% 265 (W) x 107 (H) x 374 (D) 尺寸(WxHxD)
  • Page 297 附錄 EC 符合性聲明書 我們 固緯電子實業股份有限公司 臺灣臺北縣土城市中興路 7-1 號 固緯電子(蘇州)有限公司 中國江蘇省蘇州市高新區鹿山路 69 號 聲明如下涉及的產品 AFG-3081, AFG-3051 符合理事會設立的關於成員國電磁相容性(2004/108/EEC)和低電壓指令 (2006/95/EEC)的法律法規要求。對於評估有關電磁相容性和低電壓指 令,適用下列標準: ◎ EMC 用於測量、控制和實驗室使用的電子設備 EN 61326-1 : EN 61326-2-1: –– EMC 要求(2006) 傳導&輻射排放 靜電釋放 EN 55011: 2007+A2: 2007 EN 61000-4-2: 2009 電流諧波 抗輻射度 EN 61000-3-2: 2006+A1: 2009+A2: 2009 EN 61000-4-3: 2006+A1: 2008 電壓波動...
  • Page 298 AFG-3000 系列使用手冊 索 引 Pulse width ........59 Arbitrary waveforms ....133 Ramp ..........60 Built-In ......... 135 Square..........57 display ......... 148 Triangle ......... 58 editing .......... 155 Operation keys inserting ........135 saving........... 170 key overview ........ 12 Beeper ........
  • Page 299 索引 remote control interface .... 179 北京海洋兴业科技股份有限公司 电话:010-62176775 网址:www.hyxyyq.com...
