Seav LR 2035 Green Series Manual

ELECTRONIC PANEL LRX 2035 Green
Single-phase electronic control unit, for the automation of
sliding gates, doors and barriers with built-in radio receiver for
the implementation of commands given via pushbutton panel
and radio control.
- Mod. LG 2035 Green
- Mod. LRS 2035 Green
- Mod. LRH 2035 Green
I
MPORTANT FOR THE USER
- The device can be used by children over 8 years of age
or by people with reduced psycho-physical abilities or
with little knowledge and experience only if supervised or
instructed on its operation and methods of use in a safe
manner to also understand the dangers involved in its
use.
- these instructions are also available on the website
www.seav.com
- Do not allow children to play with the device and keep
radio controls out of their reach.
- Examine the system frequently to detect any signs of
damage. Do not use the device if repair work is
necessary.
-Always remember to turn off the power before carrying
out cleaning or maintenance operations.
- Cleaning and maintenance operations must not be
carried out by children without supervision.
ATTENTION: keep this instruction manual and comply
with the important safety instructions contained therein.
Failure to comply with the instructions could cause
damage and serious accidents.
I
MPORTANT FOR THE INSTALLER
1) Before automating the window it is necessary to
check its good condition, in compliance with the
machinery directive
2) Check that the location in which the installation is
located allows compliance
temperature limits
3) The safety of the final installation and compliance
with all regulatory requirements (EN 12453 - EN 12445)
is the responsibility of those who assemble the various
parts to construct
4) Use safety devices capable of monitoring the status
of their connection
5) Once the installation has been completed, it is
advisable to carry out all the necessary checks
(appropriate programming of the control unit and correct
installation of the safety devices) to ensure that a
compliant installation
6) Fix the control unit to a wall, using, for assembly, the
special support with which the casing is equipped, so as
to leave this support downwards and insert the fixing
screws in the
7) The control unit does not have any type of
disconnecting device for the 100-240 Vac electrical line,
it is therefore the installer's responsibility to provide a
disconnecting device in the system. It is necessary to
install an omnipolar switch with overvoltage category III.
It must be positioned so as to be protected against
accidental closures in accordance with the provisions of
point 5.2.9
: Without radio receiver
: 433,92 Mhz
: 868,30 Mhz
and EN 12604 compliance.
with the operating
indicated for the
a complete
to the power
has been carried
appropriate
of EN
GB
8) The power supply and motor connection cables
suitable for insertion into the pg9 cable glands supplied
must have an external diameter between 4.5 and 7 mm.
The internal conductive wires must have a nominal
section equal to 0.75mm2. If a conduit is not used, it is
recommended to use cables made of H05RR-F material.
Pay attention to fixing the cables so that they are
anchored
Furthermore, when drilling holes in the external casing to
pass power and connection cables, and assembling the
cable glands, be careful to install everything in such a
way as to keep the IP grade characteristics of the box
unchanged
9) The gearmotor used to move the window must
comply with the provisions of point 5.2.7 of EN 12453.
10) In accordance with 5.4.2 of EN 12453, it is
advisable
electromechanical release device, to allow the window to
be
11) In accordance with 5.4.3. of EN 12453 use
electromechanical release systems or similar devices
that allow the window to stop safely in its end position
12) The wiring of the various electrical components
external to the control unit must be carried out in
accordance with the provisions of the EN 60204-1
standard and the amendments made to it by point 5.2.7
of the EN 12453. The fixing of the power supply and
connection cables must be guaranteed by assembling
the cable glands supplied.
13) Any installation of a pushbutton panel for manual
control must be done by positioning the pushbutton
panel so that the user does not find himself in a
dangerous
14) The safety function guaranteed by the control unit is
active only during closing; therefore opening protection
must be ensured during installation with measures
(guards or safety distances) independent of the control
circuit.
15) For correct operation of the radio receiving part, if
two or more control units are used, we recommend
installing them at a distance of at least 3 meters from
each other.
device.
closure.
LG
2035 Green
plant.
comply with the specifications of the Directives
RED 2014/53/EU, EMC 2014/30/EU, LVD 2014/35/EU.
EU Regulation 2023_826 Eco-friendly Design.
out.
spaces.
Further information, the full text of the EU declaration of conformity
is available at the following Internet address:
http://www.seav.it
12453.
1
in a
as much
to use gearmotors
moved manually
The Electronic Central:
- LRS
2035 Green
rev. 1.0 31/01/2025
stable manner.
as possible.
equipped with an
if necessary.
position.
- LRH
2035 Green
