Truflo — UltraFlo
®
Clamp-On Ultrasonic Flow Meter Sensor
Flow Range & Accuracy
Size
OD (mm)
ID (mm)
Flow Range
(Accuracy)
Wiring
Color
Brown
Green
Gray
Blue
White
Red
Pink
Yellow
Dimensions
Model Selection
Size
6.35mm | 1/4"
8.00mm | 5/16"
9.53mm | 3/8"
12.70mm | 1/2"
25-0613 © Icon Process Controls Ltd.
UF-500S
®
6.35mm | 1/4"
6.00 – 6.35
3.00 – 3.20
0-4.7 GPH
(±0.12 GPH)
4.7-103.0
(±2.0%)
Description
+24VDC
-VDC | mA-
mA+
RS485A
RS485B
OCT+
Relay 1
Relay 2
54.00
UltraFlo 500S — Clamp-On Ultrasonic Flow Meter
8.00mm | 5/16"
8
5
0-6.3 GPH
(±0.15 GPH)
6.3-145.8
( ±2.0%)
M12 Female Cable
28.30
Part Number
UF500S-A-06
UF500S-A-08
UF500S-A-09
UF500S-A-12
9.53mm | 3/8"
9.53 – 10.0
6.38 – 7.00
0-9.5 GPH
(±0.19 GPH)
9.5-218.7
(±2.0%)
100.00
Material
Aluminum
Aluminum
Aluminum
Aluminum
12.70mm | 1/2"
12.0 – 12.7
9.00 – 9.55
0-17.4 GPH
(±0.39 GPH)
17.4-317.0
(±2.0%)
DC+
Brown
DC-/4-20mA-
Green
4-20mA+
Gray
RS485 A
Blue
RS485 B
White
OCT+
Red
Relay 1
Pink
Relay 2
Yellow
