Truflo — UltraFlo
®
Clamp-On Ultrasonic Flow Meter Sensor
M12
Connection
Signal
Strength
Flow Total
Keypad
CS | SS | PVC | Copper
| PVDF | PFA | PTFE |
Aluminum
Specifications
Pipe Size Range (OD)
Temperature Range
Ambient Humidity
Repeatability
Output
Relay Output
Alarm Output
Communication
Viscosity Range
Sensor Body
Display
Power Supply
Connection
Accuracy
Units
Protection Class
Standards
25-0613 © Icon Process Controls Ltd.
UF-500S
®
Aluminum
Time
Flow Rate
Full Pipe
Indication
1/4" ~ 1/2" | 6mm ~ 12.7mm
RH 0~95%, No Condensation
4-20mA, Max. Load:600Ω
30VDC @ 1A | Switching Freq. < 2Hz*
OCT Upper & Lower Limit Alarm Function
GPM | LPM | m3/h | ml/min | LPH
CE | FCC | RoHS Compliant
Features
High Accuracy | ± 2.0% of Full Scale
?
Ultra Low Flow Ranges
?
Simple Installation - No Cutting of Pipe
?
Works on Carbon Steel | Stainless Steel |
?
PVC | Copper | PVDF | PFA | PTFE |
PU | Aluminum
Excellent Corrosion Resistance
?
No Moving Parts
?
4-20mA | RS485 Outputs
?
Flow Direction
14 – 122ºF | -10 – 50 C
o
±0.8%
MODBUS RS485
<300Cst Max.
Aluminum
2.4' 320*240 IPS LCD
24VDC, 3W
M12
±2.0% (0.3m/s ~ 5.0m/s)
IP65
Clamp-On
Transducer
AL
