Icon Process Controls ProCon TB550 Series Quick Start Manual

Turbidity sensor
Hide thumbs

Advertisement

Quick Links

Download this manual
ProCon
— TB550 Series
®
Turbidity Sensor
Read the user's manual carefully before starting to use the unit.
Producer reserves the right to implement changes without prior notice.
24-0321 © Icon Process Controls Ltd.
Quick Start Manual
SS316
POM
RoHS
Compliant
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProCon TB550 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Icon Process Controls ProCon TB550 Series

Summary of Contents for Icon Process Controls ProCon TB550 Series

  • Page 1 ProCon — TB550 Series ® Turbidity Sensor Quick Start Manual SS316 RoHS Compliant Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. 24-0321 © Icon Process Controls Ltd.

  • Page 2: Product Introduction

    0.001 | 0.01 | 0.1 | 1 , When Matching the Controller Response Time 6s < 90s < 300s (Adjustable) Waterproof Grade IP68 | NEMA6P Housing Material SS316L, POM Connection 3/4" NPT Cable Length Installation Immersed 24-0321 © Icon Process Controls Ltd.

  • Page 3: Installation

    25 ± 1°C incubator or constant temperature water bath. Let stand for 24 hours to make 4000NTU standard solution. Turbidity Standard Solution The total preparation volume was 200ml. Concentration (NTU) 400NTU Absorb Quantity (ml) 4000NTU Absorb Quantity (ml) – – – 17.5 1000 – 24-0321 © Icon Process Controls Ltd.

  • Page 4: Sensor Calibration

    2. Manual Start Brush As shown in the figure below, after connecting the turbidity sensor, select 06 function code in the communication software, Address input: 20, Value input 66, click Send, to observe the sensor brush start. 24-0321 © Icon Process Controls Ltd.
  • Page 5 As shown in the figure below, after connecting the turbidity sensor, select Display in the communication software and select Signed (integer), and the communication address 11 displays 30, indicating that the sensor starts the scraping every 30 minutes. 24-0321 © Icon Process Controls Ltd.
  • Page 6 "Send", a popup shows "Response OK", indicating the sensor address modification is completed. Without knowing the sensor communication address, the sensor can be read using the broadcast address 255. 24-0321 © Icon Process Controls Ltd.

  • Page 7: Restore Factory Calibration

    8. Restore Factory Calibration If the digital turbidity sensor calibration is wrong during the calibration process, select "06" function code, enter "200" in "Address" , "60" in "Value" , click "Send". A pop-up display "Response OK" appears. 24-0321 © Icon Process Controls Ltd.

  • Page 8: Sensor Wiring

    1 - 10080 | Brush Time Read-Write Integer Unit : Min Address Read-Write Integer 1 - 254 Manual Brush Write-Only Signed Send 66 1 - 10080 | Automatic Brush Write-Only Signed Unit : Min 24-0321 © Icon Process Controls Ltd.
  • Page 9 Third Voltage Read-Write Single Float Fourth Voltage Read-Write Single Float Sixth Voltage Read-Write Single Float Seventh Voltage Read-Write Single Float Ninth Voltage Read-Write Single Float Only Calibration Factory Calibration Write-Only Integer Values are Restored 24-0321 © Icon Process Controls Ltd.

  • Page 10: Warranty

    Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
