Truflo
— TKP | TK3P Series (V1)
®
In-Line Paddle Wheel Flow Meter Sensor
Read the user's manual carefully before starting to use the unit.
Producer reserves the right to implement changes without prior notice.
24-0597
© Icon Process Controls Ltd.
Quick Start Manual
1
1
Advertisement
Related Manuals for Icon Process Controls truflo TKP Series
Summary of Contents for Icon Process Controls truflo TKP Series
- Page 1 — TKP | TK3P Series (V1) ® In-Line Paddle Wheel Flow Meter Sensor Quick Start Manual Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. 24-0597 © Icon Process Controls Ltd.
- Page 2 10% Particle Size - Not to Exceed .5mm Cross Section or Length. Please do not flush the pipe after the Flow Meter is installed with compressed air this may damage the ceramic shaft and will void warranty. 24-0597 © Icon Process Controls Ltd.
- Page 3 ShearPro Through-Pin Design ® vs. Flat Paddle Eliminates Finger Spread No Lost Paddles Increased Temp. Rating 360° Housing Protects Rotor Finger Spread = LOST Unprotected Rotor Thermal Plastic TK3P 316 SS vs. Competitor ‘A’ 24-0597 © Icon Process Controls Ltd.
- Page 4 -40°F to 300°F -40°C to 148°C Outputs NPN Pulse RS485 Display Flow Rate + Flow Totalizer Standards and Approvals RoHS Compliant *Optional See Temperature and Pressure Graphs for more information ** ¼” - ⅜” SS Only 24-0597 © Icon Process Controls Ltd.
- Page 5 +10 - 30 VDC Brown RS485A Yellow Black Pulse (NPN) Load Flow White Pulse (NPN) Load -VDC RS485B Blue Grey Meter Yellow Output RS-485 Special Option Pulse Output Grey Circuit Pulse Output NPN White Black Blue 24-0597 © Icon Process Controls Ltd.
- Page 6 Enter K Factor Value Refer to Page 9 for K-Factor Values Totalizer Reset STEPS DISPLAY OPERATION Home Screen ▶ Home Screen �� 3 Sec . Totalizer Reset ▶ Totalizer Value will Reset to Zero 24-0597 © Icon Process Controls Ltd.
- Page 7 Refer Pulse Control Programmming, Page 8 Brown + 10~30VDC Note: Refer to 'Relay Mode Selection' on Page 8 to Black Pulse Output (1 Pulse/Gal) configure the relay output as needed. White SSR (Flow Rate) Blue -VDC 24-0597 © Icon Process Controls Ltd.
- Page 8 [SV - Hys] — ▶ Relay OFF: CV > [SV + Hys] or CV < [SV - HyS] — ▶ Relay ON Hys = Hysteresis — Acts like a buffer ± around (OP1) pulse output CV: Current Value (Flow Rate) | SV = Set Value 24-0597 © Icon Process Controls Ltd.
- Page 9 ½” TKP-15-PP ½” TK3P-15-SS ¾” ¾” TKP-20-PP TK3P-20-SS 1” TKP-25-PP 1” TK3P-25-SS 1 ½” TKP-40-PP 1 ½” TK3P-40-SS 2” 2” TKP-50-PP TK3P-50-SS 3” Flanged TKP-80-PP 3” TK3P-80-SS 316SS PVDF 4” Flanged TKP-100-PP 4” TK3P-100-SS 24-0597 © Icon Process Controls Ltd.
- Page 10 Using an allen key loosen the 2 screws Pull the Screws | Do Not Remove! located on either side of the display. Lift the Display. Tighten Allen Screws | Snug Tight Rotate Display 90°. Lower Display. Do Not Over-Tighten! 24-0597 © Icon Process Controls Ltd.
- Page 11 fibers - max 10% Particle Size - Not to Exceed .5mm Cross Section or Length. Please do not flush the pipe after the Flow Meter is installed with Compressed Air this may damage the ceramic shaft and will Void Warranty. 24-0597 © Icon Process Controls Ltd.
- Page 12 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
