Prestige Solo PA 80-110-155-175-250-299-399
Prestige Excellence PA 110
Spark Ignition Kit - Installation Instructions
Installation shall be performed by a qualified installer, service agency, or the gas supplier.
CONTENTS
.....................................................
.......................................................
7.1
Igniter and Spark Generator Installation .....................................4

1 - Definitions

The following terms and symbols are used throughout
this manual to bring attention to the presence of potential
hazards or to important information concerning the product.
Indicates the presence of a hazardous situation
which, if ignored, will result in substantial property
damage, serious injury, or death.
Indicates a potentially hazardous situation
which, if ignored, can result in substantial
property damage, serious injury, or death.
Indicates special instructions on installation,
operation or maintenance, which are important
to the equipment but not related to personal
—
This symbol indicates that you need to make a
picture (with your phone or other) for later reporting.
™
This symbol indicates that an instructional
"HOW TO" video is available from Triangle
Tube's website. A direct link to the library is
available at the top left corner of the front cover.
Pub. date: 02/26/2025
..................................................
..........................................
...............................................
..........................
.........................................
• DANGER
• WARNING
NOTICE
injury hazards.
These instructions shall be kept with the appliance literature for future reference.
• WARNING
7.2
Control Module Replacement .........................................................6
7.3
Display Module Replacement ......................................................... 7
7.4
Configuration Updates ......................................................................9
1
1
8.1
Inspect Condensate Drain Assembly ......................................... 10
1
8.2
Setup ....................................................................................................... 10
8.3
Altitude Setting ................................................................................... 12
3
8.4
Starting Up .......................................................................................... 12
8.5
Condensate Pan Leak Test ............................................................ 13
4
8.6
Starting the Boiler .............................................................................. 13
4
4
9.1
Combustion Setting ........................................................................... 14
9.2
Record and Report ............................................................................ 15

2 - Purpose

This kit (see Fig. 1 for details) replaces the existing igniter
and its wiring, the 2-in-1 insulation, as well as the Control
module, the display module and front cover of the
control box, on PA-prefixed Prestige Solo and Excellence
boilers.
Please also refer to the "How To" video in our
Video library (QR code access available in the top left
corner of this page).
This modification disables the Alarm Relay
function which is used in several system
configurations. Therefore, to allow the heating
system configuration to be operational, some
wire connections must be modified and some
Controller settings changed, as required.

3 - Applicability

Prestige Solo PA 80-110-155-175-250-299*-399*
Prestige Excellence PA 110.
* For 299 and 399 models, please refer to Section 4 on page 3
A1011317 - 664A0730 • B
Triangle Tube
1240 Forest Parkway, Suite 100,
West Deptford NJ 08066
Tel: (856) 228 8881 - Fax: (856) 228 3584
E-mail:
techsupport@triangletube.com
...............................................
............................................
NOTICE
PARKIT243 (PA 155)
10
14
1
