Owner's Manual
BDW-Series
This Owner's Manual provides assembly,
install and user guidance. It applies to all BDW
Series Truck Box sold by Ranger Design. For
a list of compatible models, visit our website at
rangerdesign.com.
Contents
Warnings ....................2
Parts Included ............3
Hardware....................4
Included) ....................4
Installation ..................5
by
This Owner's Manual must remain in vehicle at all times.
BDW-2055
Scan the QR code for the
latest Installation Guide.
For more information,
visit rangerdesign.com.
shown
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ranger design TRAZER BDW Series
Summary of Contents for Ranger design TRAZER BDW Series
-
Page 1: Table Of Contents
Owner’s Manual BDW-Series This Owner’s Manual provides assembly, install and user guidance. It applies to all BDW Series Truck Box sold by Ranger Design. For a list of compatible models, visit our website at rangerdesign.com. Contents Warnings ....2 Parts Included ....3 Hardware....4... -
Page 2: Warnings
FR: Si vous avez besoin de ces instructions en français, s'il vous plait contacter notre service à la clientèle. +1-800-565-5321 ES: Si necesita estas instrucciones en español, comuníquese con el Servicio de atención al cliente de Ranger Design. +1-800-565-5321 Page 2 |BDW-Series Installation Guide | REV. A... -
Page 3: Parts Included
Parts Included Truck Box Rear Short Bed – Qty. 1 P/N BDW-2055 Truck Box Standard Bed – Qty. 1 P/N BDW-2065 For technical support, contact us at 1-800-565-5321 BDW-Series Installation Guide | REV. A | Page 3... -
Page 4: Hardware
Hardware Assembly Fastener Kit Content P/N & P/N 96-2003 Part Description Qty. P/N 90-491 Carriage Bolt 5/16"-18 × 1" SS 304 P/N 94-111 Nut Lock 5/16"-18 P/N 98-117 Flat Washer 5/16"O.D 3/4" Tools Required (Not Included) Measuring tape 1/2" Socket ... -
Page 5: Installation
Installation BEFORE STARTING Verify that you have complete parts before starting. Skip STEP 1 and STEP 2 proceed directly to STEP 3 if installing to a new truck rack. STEP 1 Remove gussets. a. Uninstall the rear cross plate and set aside for later. b. - Page 6 Installation STEP 2 Remove rear cross brace and loosen uprights. a. Loosen the bolts in the slots at the bottom of the rear upright. b. Remove the bolts from the front upright until they are no longer protruding from the extrusion to allow for proper box installation.
- Page 7 Installation STEP 3 Insert the (3) carriage bolts into the channel in the transverse beam. HARDWARE Carriage Bolt Qty: 3 For technical support, contact us at 1-800-565-5321 BDW-Series Installation Guide | REV. A | Page 7...
- Page 8 Installation WARNING: A minimum of 2 people are required for installing the box safely. STEP 4 Insert box into rack opening. Page 8 |BDW-Series Installation Guide | REV. A For technical support, contact us at 1-800-565-5321...
- Page 9 Installation NOTE: Use Anti-seize provided with the rack when fastening bolt. The hardware used in this step is provided in the rack box and was removed and set asside in step 1 and 2. STEP 5 Open the door, bolt side panels to rack uprights and reattach the rear cross plate.
- Page 10 Installation NOTE: Use Anti-seize provided with the rack when fastening bolt. STEP 6 Install the top of truck box. a. Install washer and nut lock with to hold in place while you place the rest of the hardware. b. Tighten them all in place. HARDWARE Nut Lock 5/16"-18 Qty: 3...
- Page 11 Installation STEP 7 Re-tighten the rear uprights bolts in the slots. TOOLS Ratchet 1/2" Socket 1/2" wrench Torque to 11 ft-lbs. For technical support, contact us at 1-800-565-5321 BDW-Series Installation Guide | REV. A | Page 11...
- Page 12 For any feedback or suggestions you may have, please contact cs@rangerdesign.com. Copyright © 2024 All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Ranger Design, Inc.
