Owner's Manual
SNF-Series
This Owner's Manual provides assembly, install and
user guidance. It applies to all SNF Shelf Kit sold by
Ranger Design. For a list of compatible models, visit our
website at rangerdesign.com.
Contents
Warnings ....................2
Parts Included ............3
Included) ....................4
Assembly ...................5
Installation ..................6
by
This Owner's Manual must remain in vehicle at all times.
SNF-55 or 65
Scan the QR code for the
latest Installation Guide.
For more information,
visit rangerdesign.com.
as shown

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRAZER SNF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ranger design TRAZER SNF Series

  • Page 1: Table Of Contents

    Owner’s Manual SNF-Series This Owner’s Manual provides assembly, install and user guidance. It applies to all SNF Shelf Kit sold by Ranger Design. For a list of compatible models, visit our website at rangerdesign.com. Contents Warnings ....2 Parts Included ....3...
  • Page 2: Warnings

    FR: Si vous avez besoin de ces instructions en français, s'il vous plait contacter notre service à la clientèle. +1-800-565-5321 ES: Si necesita estas instrucciones en español, comuníquese con el Servicio de atención al cliente de Ranger Design. +1-800-565-5321 Page 2 | SNF-Series Installation Guide | REV. A...
  • Page 3: Parts Included

    Parts Included Shelf End Plate – Qty. 2 P/N 21-047 Plywood Shelf Tray – Qty. 1 P/N 60- 11.875x54 For SNF-55 shelf only. Plywood Shelf Tray – Qty. 1 P/N 60- 11.875x63 For SNF-65 shelf only. Support Brackets – Qty. 2 P/N 21-046 For technical support, contact us at 1-800-565-5321 SNF-Series Installation Guide | REV.
  • Page 4: Tools Required (Not Included)

    Parts Included P/N & Fastener Kit P/N 96-2100 Part Description Qty. P/N & P/N 96-2100 Part Description Qty. P/N 90-012 Hex Screw 1/4"-10 × 3/4" ZINC P/N 90-484 Carriage Bolt 5/16-18 x 5/8" ZINC P/N 92-102 Hex Screw 14x1" ZINC P/N 94-116 Serrated Nut 5/16-18...
  • Page 5: Assembly

    Assembly STEP 1 Accessory shelf assembly. NOTE: It is important that STEP A must be done FIRST before installing the end panels to the shelf.  a. Before installing the end panels to the shelf place carriage bolt into both ends of the end panels. b.
  • Page 6: Installation

    Installation STEP 2 Shelf bracket installation. NOTE: Tighten with torque wrench ONLY do not use impact when installing.  TOOLS  3/8 Hex Bit  Torque Wrench Hex Screw Torque to 8 ft-lbs. Page 6 | SNF-Series Installation Guide | REV. A For technical support, contact us at 1-800-565-5321...
  • Page 7: Front View

    Installation STEP 3 Shelf installation to brackets. TOOLS  Rubber Mallet Serrated Nuts FRONT VIEW NOTE: Before tightening the bolts pull the shelf foward just to ensure a gap is made at the back end. Torque to 12 ft-lbs. For technical support, contact us at 1-800-565-5321 SNF-Series Installation Guide | REV.
  • Page 8 For any feedback or suggestions you may have, please contact cs@rangerdesign.com. Copyright © 2024 All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Ranger Design, Inc.

This manual is also suitable for:

Trazer snf-65Trazer snf-55
