Clarity
3 IN 1 WATER FILTER TAP
Product Code: CTY001BS
Installation and User Guide
Technical Specification
Working Pressure:
Min:
0.5 Bar
Max:
5.0 Bar
Operating Temperature:
Hot:
65⁰C
Cold:
5⁰C
Features:
· Tilt and turn lever for temperature and
flow control
· Separate lever for filtered water
· Comes with carbon filter cartridge and
filter housing
· Pull out spout, for greater sink access
Please read these instructions fully before commencing the installation.
Advertisement
Table of Contents
Related Manuals for METHVEN Deva Clarity CTY001BS
Summary of Contents for METHVEN Deva Clarity CTY001BS
- Page 1 Clarity 3 IN 1 WATER FILTER TAP Product Code: CTY001BS Installation and User Guide Technical Specification Working Pressure: Min: 0.5 Bar Max: 5.0 Bar Operating Temperature: Hot: 65⁰C Cold: 5⁰C Features: · Tilt and turn lever for temperature and flow control ·...
-
Page 2: Table Of Contents
Please read all of the instructions before installation. Methven recommends this product is installed by a competent person in compliance with all relevant regional regulations. Remove all packaging and check the components for damage before starting installation. -
Page 3: Pre-Installation
Pre-Installation Before beginning the installation of this product, ensure all parts are present. Compare parts with the Parts Breakdown section. If any part is missing or damaged, do not attempt to install the product. Verify that the hole size in the counter top is correct. A surface depth of at least 30mm is recommended Recommended Installation Hole 1-3/8 Inch Diameter... -
Page 4: Parts Breakdown
Parts Breakdown 1. Tap Body 2. Washer 3. Threaded Connection 4. Washer 5. Washer 6. Locking Nut 7. 2 x Flexi Tails 8. Purifier Outlet Hose 9. Purifier Inlet Hose 10. Filter Housing 11. Filter Cartridge 12. Tee valve 13. Screws... -
Page 5: Product Installation
Product Installation ● Before commencing installation of the new product, ensure that the system has been flushed to remove any debris which could cause damage to the valves and invalidate the warranty. Installation ● Isolate the water supply. ● Place the washer (2) into the recess within the base of the tap body. - Page 6 Product Installation ● Secure the filter housing (10) in position using the screws provided (13). ● Unscrew the filter holder from the filter housing. ● Remove the protective wrapper from the filter cartridge and insert into the filter holder. Re-screw the filter holder onto the housing.
-
Page 7: How To Use
How To Use Your Tap REGULAR HOT & COLD FILTERED WATER • Pull small lever handle forward for • Pull mixer lever away from the tap for Cold Water. Filtered Water • Filtered water will dispense from the • Pull handle forward for Hot Water. outlet on the fixed bar spout. -
Page 8: Replacing Filter Cartridge
Replacing the Filter Cartridge ● The tap is supplied with a filter housing and carbon filter cartridge. ● Carbon filtration helps to: o Remove impurities whilst maintaining minerals o Improve taste o Improve odour ● Capacity: 2000L ● Replacement cycle: Recommended replacement every 3-6 months. More frequent replacement may be required in hard water areas. -
Page 9: Troubleshooting
Troubleshooting... -
Page 10: Warranty
Do not use products containing chlorine, bleach or hydrochloric acid as these can damage the product. We have a policy of continuous improvement and reserve the right to change specifications without notice. METHVEN UK LIMITED METHVEN EXPERIENCE CENTRE 3/3A STONE CROSS COURT TEL: 0800 195 1602...
