Technical Data
Battery Voltage Max* ............................................................. 24V D.C.
Battery Capacity .............................................................................. 2.0A
Charging Time Max .............................................................1 hr 20 min
Telescoping Pole Length ................................................3.7 ft to 5.3 ft
.........................................................................................
Auxiliary Handle Angles ............................................ -45° | 0° | 45°
Charger Input ............................................100 – 240 V 50 – 60 Hz
Charger Output .......................................................... 25.2V DC 1.4A
Pole Hedge Trimmer
Motor .............................................................................................. 250 W
Blade Length ............................................................ 17.7 inch (45 cm)
Cutting Diameter ....................................................... 0.6 inch (1.5 cm)
Head Angles ........................................................................ -45° to 90°
Net weight ......................................................................7.7 lbs (3.5 kg)
Grass Trimmer + Edger
Motor ...............................................................................................200 W
Cutting Diameter ..........................................................10 inch (25 cm)
Spool Length ...................................................................... 16.5 ft (5 m)
Spool Advance ........................................................................ Auto-feed
Line diameter ........................................................ 0.055 inch (1.4 mm)
Head Angles ............................................................................ 0° to 60°
Net weight ...................................................................... 6.2 lbs (2.8 kg)
Pole Chain Saw
Motor ...............................................................................................350 W
Bar/Chain Length .......................................................8 inch (20.3 cm)
Cutting Thickness ........................................... Max: 7.5 inch (19 cm)
.................................................................
Oil Tank Capacity ........................................................ 2.7 fl oz (80 ml)
Overhead Reach Max ...................................................... 14 ft (4.3 m)
Head Angles ............................................................................ 0° to 30°
Net weight ...................................................................... 7.7 lbs (3.5 kg)
(1.1 m to 1.6 m)
Recommended: 6.5 in. (16.5 cm)
Unpacking
Carton Contents
• Telescoping pole with auxiliary handle
• Chain saw head with chain and bar pre-mounted
• Chain saw bar sheath
• Hex key wrench
• Hedge trimmer head with blade
• Hedge trimmer blade sheath
• Grass trimmer + edger head
• Grass trimmer + edger safety guard
• Pre-wound spool (x2)
• 24V* IONMAX TM lithium-ion battery
• 24V* IONMAX TM lithium-ion charger
• Manual with registration card
• 3.4 fl oz (100 ml) bar + chain lubricant oil
1. Carefully remove the multi-tool system and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe + Sun Joe
®
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless multi-
tool system. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suffocation
risk!
Battery + Charger
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read off the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is flat. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery's service life will be greatly shortened.
9
customer service center at
®
