Lights Light Indicators
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
NOTE: If the charge level button does not appear to be working,
insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge level
button may display a lower charge than it will if checked a few
minutes later. The battery cells "recover" some of their charge
after resting.
Charger Operation
m
WARNING!
Charge only 24V* lithium-ion battery packs
with its compatible 24V* lithium-ion charger. Other types of
batteries may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to flow
into the charger's AC/DC plug.
When to Charge the IONMAX
LTE Lithium-iON Battery
NOTE: The IONMAX 24VBAT-LTE lithium-ion battery packs
TM
do not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the battery
pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your IONMAX 24VBAT-LTE lithium-ion battery pack.
TM
• You can "top-off" your battery pack's charge before starting a
big job or after a long day of use.
Charging the Battery
1. Push the push lock button on the battery to pull the battery
Fig. 1
2. Check that the mains voltage is the same as that marked
24VBAT-
TM
3. The battery will take approximately 80 minutes to charge.
m
charger from the battery, be sure to unplug the charger from the
outlet first, then disconnect the charger from the battery
m
off when the battery is fully charged. Please take care not
to leave the battery plugged into the charger. Switch off or
unplug the charger at the mains when charging is complete.
4. Timely recharging of the battery will help prolong the
10
pack out from the battery compartment (Fig. 1).
on the rating plate of the battery charger. Then, plug the
charger adaptor into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 2).
Fig. 2
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
CAUTION!
FIRE HAZARD. When disconnecting the
WARNING!
This charger does not automatically turn
battery's life. You must recharge the battery pack when you
notice a drop in the equipment's power.
R
Push button
Battery
indicators
