Summary of Contents for SunSynk SYNK-7K-SG05LP1-SM2

  • Page 1 SINGLE-PHASE HYBRID INVERTER USER MANUAL SYNK-7K-SG05LP1-SM2 SYNK-7.6K-SG05LP1-SM2 SYNK-8K-SG05LP1-SM2 www.sunsynk.com sales@sunsynk.com customerservices@sunsynk.com PLEASE RETAIN FOR v.4 (19/02/25) FUTURE REFERENCE...
  • Page 2: Table Of Contents

    Table of Contents SAFETY System Flow Page Setup Page General Safety Basic Setup Symbols/Safety Signs Set Time (Clock) Safety Instructions Set Company Name / Beeper / Auto dim Product Disposal Factory Reset and Lock Code Inverter Remote Control PRODUCT INTRODUCTION Battery Setup Page Product Overview Generator &...
  • Page 3: Safety

    SAFETY General Safety This device must be used only as specified in this manual and in compliance with local, regional, and ƒ national laws and regulations. Ensure that the installation, operation, maintenance, and repair of this device are performed by individuals who have read and fully understood this manual. Always include this manual when passing the device to a third party.
  • Page 4 Single Phase. Three Phase. Protective Conductor Terminal or Earth Rechargeable. Ground Terminal. Do not submerge the battery in water or Keep out of reach of children, animals, expose it to moisture or liquid. and insects. Do not expose the product to sunlight. Inverter DC to AC.
  • Page 5: Safety Instructions

    WARNING HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION. Sunsynk Single-Phase Hybrid Inverter can only be installed by a qualified licensed electrical contractor. This is not a DIY product. This section contains essential safety and operational guidelines. Please read carefully and retain this ƒ...
  • Page 6: Product Introduction

    PRODUCT INTRODUCTION This multifunctional inverter combines the functions of an inverter, solar charger and battery charger to offer uninterruptible power support with a portable size. Its comprehensive LCD display offers user-configurable and easily accessible button operations such as battery charging, AC/solar charging, and acceptable input voltage based on different applications.
  • Page 7: Product Size

    Product Size Inverter Size SINGLE PHASE HI 7/7.6/8kW | User Manual...
  • Page 8: Product Features

    Product Features INTERACTIVE Easy and simple to understand display ƒ Supporting Wi-Fi or GSM monitoring ƒ Visual power flow screen ƒ Smart settable 3-stage MPPT charging for optimized battery performance ƒ Auxiliary load function ƒ Parallel / multi invert function grid-tied and off-grid ƒ...
  • Page 9: Basic System Architecture

    Basic System Architecture The illustration below shows a typical configuration of this inverter. For a complete operational system, the following components are required: Generator or Utility Grid ƒ PV modules ƒ Depending on your specific requirements, consult with your system integrator to explore other possible system architectures.
  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS Model SYNK-7K-SG05LP1- SYNK-7.6K-SG05LP1- SYNK-8K-SG05LP1- Battery Input Date Battery Type Lead-acid or Li-Ion Battery Voltage Range 48Vd.c (40Vd.c ~ 60Vd.c) Max. Charging/Discharging Current 175Ad.c (max.) 190Ad.c (max.) Charging Strategy for Li-Ion Battery Self-adaption to BMS Number of Battery Input PV String Input Data Max.
  • Page 11 Efficiency Max. Efficiency 97.60% Euro Efficiency 96.50% MPPT Efficiency >99% Protection PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Integrated Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection. Surge Protection DC Type II / AC Type II Over Voltage Category DC Type II / AC Type III...
  • Page 12: Installation

    INSTALLATION Parts List Check the equipment before installation. Please make sure nothing is damaged in the package. You should have received the items in the following package: Stainless Steel Stainless Steel Mounting Anti-Collision Bolt M6*60 Hybrid Inverter Wall Mounting Bracket Screws M4*12 x4 Battery Temperature Sensor Clamp...
  • Page 13: Selecting The Mounting Area

    Selecting the Mounting Area This Hybrid Inverter is designed for outdoor use (IP65), DO NOT install the inverter in the following areas: Areas with high salt content, such as the marine environment. It will deteriorate the metal parts and ƒ possibly lead to water/dampness penetrating the unit.
  • Page 14: Installations Tools

    Install the indoor unit on the wall where the floor height is higher than 1600mm. ƒ For proper heat dissipation, allow a clearance of approximately 500mm to the side, 500mm above and ƒ below the unit, and 1000mm to the front of the unit. WARNING For proper air circulation to dissipate heat, allow a clearance of approx.
  • Page 15: Mounting The Inverter

    Mounting the Inverter Choose the recommended drill head (as shown below pic) to drill 4 holes in the wall, 62-70mm deep. 1. Use a proper hammer to fit the expansion bolt into the holes. 2. Carry and hold the inverter, ensure the hanger aims at the expansion bolt, and fix the inverter on the wall.
  • Page 16: Battery Connection

    Battery Connection For safe operation and compliance, a separate DC over-current protector or disconnect device is required between the battery and the inverter. Switching devices may not be required in some applications, but over-current protectors are still required. Refer to the typical amperage in the table below for the required fuse or circuit breaker size.
  • Page 17: Function Port Definition

    WARNING Reverse Polarity. Before making the final DC connection or closing DC breaker/disconnect, be sure positive (+) must be connected to the positive (+) and negative (-) must be connected to the negative (-). A reverse polarity connection on the battery will damage the inverter. Function Port Definition DIP Switch for Parallel Function...
  • Page 18: Installations Instructions

    Function Port Installations Instructions RSD_short signal (B,B) Wrap the wires three laps around the magnetic ring, then thread RSD_voltage signal (+,-) the end of wires through the magnetic ring. RSD_12V_out (17,18) Wrap the wires three laps around the magnetic ring, then thread CT(3,4) the end of wires through the magnetic ring.
  • Page 19: Lead-Acid Battery Temperature Sensor

    Lead-Acid Battery Temperature Sensor Inverter Temp. sensor SINGLE PHASE HI 7/7.6/8kW | User Manual...
  • Page 20: Grid Connection And Backup Load Connection

    Grid Connection and Backup Load Connection Before connecting to the grid, please install a separate AC breaker between the inverter and the grid. Also, it is recommended to install an AC breaker between the backup load and inverter. This will ensure that the inverter can be securely disconnected during maintenance and fully protected from overcurrent.
  • Page 21 GEN PORT LOAD GRID GEN PORT LOAD GRID GRID LOAD 6,7,8 Thread the 2 wires through the magnetic ring. 3. Then, insert AC output wires according to the polarities indicated on the terminal block and tighten the terminal. Make sure to connect corresponding N wires and PE wires to related terminals as well. 4.
  • Page 22: Pv Connection

    PV Connection Before connecting to PV modules, please install a separate DC circuit breaker between the inverter and PV modules. It is very important for system safety and efficient operation to use appropriate cable for PV mod- ule connection. To reduce the risk of injury, please use the proper recommended cable size as below. Model Wire Size Cable (mm...
  • Page 23 DC+ Male Connector DC- Female Connector NOTE: Please use approved DC cable for PV system. DC+ Male Connector DC- Female Connector DC+ Male Connector DC- Female Connector DC+ Male Connector DC- Female Connector The correct steps in assembling the DC connector are explained below: DC+ Male Connector DC- Female Connector 1.
  • Page 24: Installing The Ct Coil

    Installing the CT Coil The CT coil is one of the most important parts of the Sunsynk Parity inverter. This device reduces the power of the inverter to prevent feeding power to the grid. This feature is also known as “Zero Export”.
  • Page 25: Meter Connection

    If the CT coil is fitted in the wrong way then this variable will have negative instead of positive values when the power is flowing into the house/inverter. Also, the inverter export limiting function will not work properly. Meter Connection CHINT Meter Inverter Breaker...
  • Page 26: Eastron Meter

    RS485B CHNT DDSU666 CHINT meter Eastron Meter Inverter parallel_1parallel_2 BMS 485/ Breaker RS 485/METER System connection diagram for the Eastron meter Input Output RS 485 230V/2T 230V/2T Grid 1+COM 1+COM RS485A RS485B EASTRON SDM230 EASTRON meter Pass the Meter communication cable through the magnetic ring and wrap it around the magnetic ring four times.
  • Page 27: Earth Connection (Mandatory)

    Earth Connection (MANDATORY) An Earth Cable shall be connected to the earth plate on the grid side in order to prevent electric shock if the original protective conductor fails. All neutrals can be linked together to maintain the neutral bond. When a Neural Earth bond is required for an ‘Off-grid’...
  • Page 28: Wiring System For Inverter

    Wiring System for Inverter This diagram is an example for grid systems without special requirements on electrical wiring connection. Note: The back-up PE line and earthing bar must be grounded properly and DC Breaker effectively. Otherwise the back-up function may be abnormal when the grid fails. AC Breaker Load Battery...
  • Page 29: Typical Application Of Diesel Generator

    Inverter Inverter contact start/valve ① DC Breaker for battery G-start/G-valve SYNK-7K-SG05LP1-SM2: 225A DC breaker SYNK-7.6K-SG05LP1-SM2: 225A DC breaker (diesel generator startup signal) SYNK-8K-SG05LP1-SM2: 225A DC breaker AC Breaker for Gen port SYNK-7K-SG05LP1-SM2: 50A AC breaker SYNK-7.6K-SG05LP1-SM2: 50A AC breaker...
  • Page 30: Single-Phase Parallel Connection

    ④ ① DC Inverter Breaker No.2 ⑤ (slave) ①②③ DC Breaker for battery SYNK-7K-SG05LP1-SM2: 225A DC breaker SYNK-7.6K-SG05LP1-SM2: 225A DC breaker ② DC SYNK-8K-SG05LP1-SM2: 225A DC breaker Breaker ④ ⑥⑧ AC Breaker for grid port ⑥ SYNK-7K-SG05LP1-SM2: 50A AC breaker SYNK-7.6K-SG05LP1-SM2: 50A AC breaker...
  • Page 31: Single-Phase Parallel Connection In A Three-Phase Grid System

    Single-Phase Parallel Connection in a Three-Phase Grid System. SINGLE PHASE HI 7/7.6/8kW | User Manual...
  • Page 32: Operation

    OPERATION Switching ON/OFF Once the inverter has been correctly installed and the batteries have been connected, press the ON/OFF button (located on the left side of the case) to activate the system. When the system is connected without a battery but connected with either PV or grid and the ON/OFF button is switched off, the LCD will still illumi- nate (display will show off).
  • Page 33: Lcd Operation Flow Chart

    LCD Operation Flow Chart Solar Page Solar Graph Grid Page Grid Graph Inverter Page Battery Page BMS Page HOME PAGE Load Page Load Graph Basic Setting Battery Settings Grid Settings System Mode System Setup Advanced Settings Aux Load Settings Fault Codes Li BMS Settings SINGLE PHASE HI 7/7.6/8kW | User Manual...
  • Page 34: Home Page

    Home Page Press the Esc button any page to access the home page: 1. Customer name 2. Access the settings menu page 3. Access solar page 4. Access load page 5. Access battery page SOLAR/TURBINE AC load 6. Access grid page 7.
  • Page 35: System Flow Page

    What this page displays: Total solar power produced. Inverter voltage. ƒ ƒ MPPT 1 power/voltage/current. Inverter current. ƒ ƒ MPPT 2 power/voltage/current. Load power. ƒ ƒ Grid power. Load voltage. ƒ ƒ Grid frequency. Battery power charge/discharge. ƒ ƒ Grid voltage. Battery SOC.
  • Page 36: Setup Page

    What this page displays: The system flow. Battery status. ƒ ƒ MPPTs power. Power distribution to load or grid. ƒ ƒ Essential Loads Setup Page To access Settings, click on the gear icon on the right top of the navigation menu. What this page displays: Serial number.
  • Page 37: Basic Setup

    Basic Setup Set Time (Clock) To set time, click on the BASIC icon and then on ‘Time’ What this page displays: Time. ƒ Date. ƒ AM/PM. ƒ What you can do from this page: Adjust / set time. ƒ Adjust / set date. ƒ...
  • Page 38: Factory Reset And Lock Code

    Locked Inverter: This function is used to lock the inverter completely so no access can be gained. It will ƒ ask for a 5-digit code that only the Sunsynk Technical staff can assist with. Test mode (only for engineers): For engineers to conduct tests.
  • Page 39: Inverter Remote Control

    Inverter Remote Control To control the inverter remotely, tick the box that allows it. What this page displays: Remote control option. ƒ What you can do from this page: Allows remote control of the inverter. ƒ Battery Setup Page To configure battery settings, click on the BATTERY icon and then on ‘Batt type’. What this page displays: Lithium: This is BMS protocol.
  • Page 40: Generator & Battery Page

    NOTE: Recommended: AGM and Flooded: Ah battery size x 20% = Charge/Discharge amps. Lithium: Ah battery size x 50% = Charge/Discharge amps. Gel: follow manufacturer' s instructions. Generator & Battery Page To configure battery charging settings, click on the BATTERY icon and then on ‘Batt Charge’. What this page displays: Amps: Charge rate of 40A from the attached generator in Amps.
  • Page 41 1Amp 12V. Below is a simple reference circuit of an auto-start system that can auto-start generators on a boat. (Sunsynk will be releasing a new OS E406 ( Auto-Start ) for better generator control).
  • Page 42: Battery Discharge Page

    Battery Discharge Page To configure inverter’s shut-down settings, click on the BATTERY icon and then on ‘Shut Down’. SINGLE PHASE HI 7/7.6/8kW | User Manual...
  • Page 43 Activating Shutdown causes the inverter to enter standby-mode. It does not entirely shut down the inverter. Total shutdown occurs at voltages below 19V. The voltage displayed on the Sunsynk Parity Inverter will vary depending on whether the inverter is charging or discharging the batteries.
  • Page 44: Setting Up A Lithium Battery

    The batteries recommended for use with the Sunsynk systems are AGM Lead Acid or Lithium Battery Banks. At its core, an AGM is still a lead-acid battery. AGM stands for Absorbent Glass Mat, which refers to the tech- nology these devices use to create power. This fiberglass mat sits between the positive and negative lead plates of your battery.
  • Page 45 NOTE: With some types of lithium batteries, the BMS cannot be controlled by the Sunsynk inverter. In this case, treat the battery as a lead-acid type and set the charging and discharging protocol following the battery manufacturer's specifications.
  • Page 46 Inverter Brand Model Storage Notes or CAN Setup Inverter SS4074 SS4037 To be used with V2 Logger SS202 http://solarmd.co.za/invert- SolarMD  er-compatibility-solarmd/ SS4143 sunsynk-and-solar-md/ SS4083 SS214 US2000B RS485 US3000 RS485 US2000C RS485 US3000C RS485 PYLON  UP5000 RS485 US5000 RS485...
  • Page 47 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter M4856-P Alpha Ess  SMILE BAT BYD Battery-Box LV Flex  Lite AU5500(UP3686) AU7500(UP5000) Greenrich AU9000(UP6100)  AW7500(WM5000) SSRE-EU10K TB51100F-T110 TOPBAND  TB51120-T110 4K4 LV Weco  5K3 LV GSL051100A-B-GBP2 GSL051200A-B-GBP2 GSL051280A-B-GBP2 GSL ENERGY...
  • Page 48 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter BALANCELL  PTN-BAT-05K-WM-LFP CANH = Pin 4 Photon  (5KWh / 100Ah) CANL = Pin 5 ZR-FC48100-1630J1 ZR-FS4850-16OSJ1 ZRGP  ZR-FS48100-16OSJ1 ZR-PBX1 U-P48200-7 U-P48100-7  U-P48150-1 L01-48100 DMEGC  L02-48200 LR48100 Robuste ...
  • Page 49 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter LM-JW-51.2V100Ah LEMAX  LM-JW-51.2V200Ah CLR5KWH CLW5KWH CLR10KWH COOLI  CLW10KWH CLH10KWH ESS10240 VOLTA STAGE1 VOLTA STAGE2 VOLTA  VOLTA STAGE3 VOLTA STAGE4 EVO 5.7KWH 48V-120Ah  Yoshopo BB-LFP-100Ah-P  51.2V 100Ah ...
  • Page 50 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter Can be used with or with- BN52V-280-14.5K HC out BMAC https://www.bluenova. co.za/wp-content/up- BN52V-560-29K HC loads/2015/11/BN-User- Blue Nova HC  Manual-HC_v102.pdf BN52V-840-43.6K HC BN52V-1120-58.2K HC CANH = Pin 7 BN52V-1400-72.8K HC CANL = Pin 8 BN52V-840-43.6K BR Blue Nova...
  • Page 51: Charge & Discharge Times Program

    Charge & Discharge Times Program To set ‘Charge’ and ‘Discharge’ times, click on the ‘System Mode’ icon after clicking on the gear icon. What this page displays: 1. Zero Export: Tick this box to not export power back to the grid (the CT coil will detect power flowing back to the grid and will reduce the power of the inverter only to supply the local load).
  • Page 52 What you can do from this page: Set a real time to start and stop charging or discharging the battery. ƒ Choose to charge the battery from the grid or generator. ƒ Limit export power to the grid. ƒ Set the unit to charge the battery from the grid or generator ticking ‘Grid’ or ‘Gen’ and set what times this ƒ...
  • Page 53 Solar Backup Load On-Grid Home Load Grid Battery Example: From 8 a.m. to 11 a.m., the battery is charged to 100% using both solar PV and grid power. After reaching full charge, the system supplies up to 4 kW of power to essential loads via the Load Port until the battery’s state of charge (SOC) drops to 50%.
  • Page 54: Grid Supply Page

    8000 8000 8000 8000 8000 8000 Example: From 1:00 a.m. to 5:00 a.m., if the battery SOC falls below 80%, the system charges the battery from the grid until SOC reaches 80%. From 5:00 a.m. to 10:00 a.m., if the battery SOC is above 40%, the system discharges the battery until SOC reaches 40%.
  • Page 55 What this page displays: Normal connect: The allowed grid voltage/frequency range when the inverter first time connects to the ƒ grid. Normal Ramp rate: It is the startup power ramp. ƒ Reconnect after trip: The allowed grid voltage/frequency range for the inverter connects the grid after ƒ...
  • Page 56 What this page displays: FW: This series inverter is able to adjust inverter output power according to grid frequency. ƒ Droop f: The percentage of nominal power per Hz. ƒ For example: “Start freq f>50.2Hz, Stop freq f<50.2, Droop f=40%PE/Hz” when the grid frequency reaches 50.2Hz, the inverter will decrease its active power at Droop f of 40%.
  • Page 57 What this page displays: P(Q): It adjusts the inverter reactive power according to the set active power. ƒ P(PF): It adjusts the inverter PF according to the set active power. ƒ Lock-in/Pn 50%: When the inverter output active power is less than 50% rated power, it won't enter the ƒ...
  • Page 58: Paralleling Inverters Advanced Settings

    Select the corresponding meter type according to the meter installed in the system. ƒ The Sunsynk parity inverter can be wired standalone or where more power is required it can be connected in parallel either single or 3 phase configuration. The maximum number of inverters that can be paral- leled in a single phase utility grid is 16 and the maximum number that can be paralleled in a three phase utility grid is 15.
  • Page 59 Each inverter will require a fuse isolator with surge protection and each group circuit will require an RCD. If the batteries as supplying power to the main load during the outage, then a change over switch will also be required or a split load can be used. The CT coils used to limit export power must only be connected to the master.
  • Page 60 If you need further help please refer to the Sunsynk website where you will find training videos and Fre- quently Asked Questions www.sunsynk.com. Firmware prior installation is important to be updated and all inverters in parallel or three phase system must be the same.
  • Page 61: Connecting The Drm's

    Connecting the DRM’s This can be selected under advance settings. 8000W This can be selected under advance settings. 1. DRM 1/5 5. Ref 0 2. DRM 2/6 6. D Ground 3. DRM 3/7 7. Net J 4-7 4. DRM 4/8 8.
  • Page 62: Advanced Function Setup

    Advanced Function Setup Inverter Inverter load port shell 8000W Ground cable 230V external relay External relay coil open contact Grid peak shaving: When this is selected, the grid output power will be limited within the set value. If ƒ the load power exceeds the allowed value, it will take PV energy and stored battery energy to supple- ment.
  • Page 63: Grid Power

    Grid Power This page shows the Daily / Monthly / Yearly and total grid power export or consumed. Access this page by clicking on the ‘Solar/Turbine’ icon on the home page. Advanced Settings for Wind Turbines To configure wind turbine settings, click on the ADVANCE icon. This is for Wind Turbine 16.5 What this page displays:...
  • Page 64: Advanced Settings For Auxiliary Load

    Advanced Settings for Auxiliary Load To configure Auxiliary Load (previously known as “smart load”) settings, click on the AUX LOAD icon. What this page displays: Use of the Gen (Aux) input or output. ƒ Generator peak shaving is ON or OFF. ƒ...
  • Page 65 Aux Load Output: This mode utilizes the Gen input connection as an output which only receives power ƒ when the battery SOC and PV power is above a user programmable threshold. For Example: Power=500W, ON: 100%, OFF=95%. When the PV power exceeds 500W, and battery bank SOC reaches 100%, Smart Load Port will switch on automatically and power the load connected.
  • Page 66: Operation Modes

    OPERATION MODES Mode I: Basic AC Cable DC Cable COM Cable AC Cable DC Cable COM Cable Backup Load Backup Load Solar On-Grid Home Load Solar On-Grid Home Load Grid Battery Grid Battery Mode II: Generator AC Cable DC Cable AC Cable DC Cable Solar...
  • Page 67: Mode Iii: With Aux-Load

    Mode III: With Aux-Load AC Cable DC Cable COM Cable Backup Load Solar On-Grid Home Load Grid Battery Mode IV: AC Couple AC Cable DC Cable On-Gen+AC couple AC Cable DC Cable Cable Solar On-Grid Home Load Backup Load Solar Backup Load On-Grid Grid...
  • Page 68 Inverter able On-Load+AC couple AC Cable DC Cable On-Grid Inverter Backup Load Solar On-Grid Home Load Grid Battery Smart Load On-Grid+AC couple AC Cable DC Cable able Backup Load Solar Grid-Connected On-Grid Grid Inverter Home Load Battery Smart Load AC Cable DC Cable COM Cable WARNING...
  • Page 69: Mode V: Grid-Tied

    Battery Smart Load mart Load Mode V: Grid-Tied AC Cable DC Cable COM Cable Backup Load Solar On-Grid Home Load Grid FAULT CODES To check the fault codes click on the FAULT CODES icon on the settings menu. If any of the fault messages listed in the following table appear on your inverter and the fault has not been removed after re-starting, please contact your local vendor or service centre.
  • Page 70 2. If the fault still exists, please get in touch with us for help. Inverter work mode changed Working Mode Change 1. Reset the inverter. 2. Seek help from Sunsynk. AC Slide over current fault. AC over current fault or 1. Check if the backup load power is within the range of the hardware inverter.
  • Page 71 Error Code Description Solutions No utility 1. Please confirm grid is lost or not; No AC grid 2. Check the grid connection; 3. Check the switch between inverter and grid in on or not; 4. If the fault still exists, please contact up for help. 1.
  • Page 72: Fault Information

    Chapter ‘Technical Specifications’. If you need further help please refer to the Sunsynk website where you will find training videos and frequent- ly asked questions www.sunsynk.com.
  • Page 73: Commissioning

    COMMISSIONING Start-Up / Shutdown Procedure The inverter must be installed by a qualified / licensed electrical engineer in accordance with the country's wiring regulations. Before switching on, the installation engineer must have completed the Earth Bond, RCD and earth leakage tests, checked that the solar panel Voc voltage does not exceed 480V and checked the battery voltage.
  • Page 74: Gdfi Fault

    Ensure you are familiar This is the heart of the with this, if you fully under- See section ‘Program system, this controls stand the controller you Charge / Discharge Times’ everything will fully appreciate the ca- pabilities of there inverter If paralleling inverters in 3 Phase check you phase If using a wind turbine...
  • Page 75 APPENDIX A The following table is the connection on battery side of SSLB1: Protocol Description Pin 1: CAN-H Pin 5: CAN-L Pin 2, 3, 4, 6, 7, 8: NC Pin 1: RS485B Pin 2: RS485A Pin 3, 6: GND RS485 Pin 7: RS485A Pin 8: RS485B Pin 4, 5: NC...
  • Page 76 Instantaneous APPENDIX E The Sunsynk inverter can be connected to the internet, but you need to add a data logger to do this. The inverter is compatible with Sunsynk Connect data-logger, which you can obtain from us with your distrib- utor.
  • Page 77 Room 702-704, 7/F Texwood Plaza, 6 How Ming Street, Kwun Tong, Kowloon, Hong Kong Sunsynk UK Ltd, 17 Turnstone Business Park, Mulberry Avenue, Widnes, Cheshire, WA8 0WN Unit 2, 3 & 4, 80 Highview Blvd, Ferndale, Randburg, 2160, South Africa...
