THREE-PHASE
HYBRID INVERTER
INSTALLER MANUAL
SYNK-8K-SG04LP3 / SYNK-10K-SG04LP3 /
SYNK-12K-SG04LP3
Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.
171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong.
Tel: +852 2884 4318 Fax: +8522884 4816
www.sunsynk.com / sales@sunsynk.com
PLEASE RETAIN FOR
v.26 (03/09/23)
FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYNK-8K-SG04LP3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SunSynk SYNK-8K-SG04LP3

Summary of Contents for SunSynk SYNK-8K-SG04LP3

  • Page 1 THREE-PHASE HYBRID INVERTER INSTALLER MANUAL SYNK-8K-SG04LP3 / SYNK-10K-SG04LP3 / SYNK-12K-SG04LP3 Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building. 171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong. Tel: +852 2884 4318 Fax: +8522884 4816 www.sunsynk.com / sales@sunsynk.com PLEASE RETAIN FOR v.26 (03/09/23)
  • Page 2 The manufacturer's warranty does not cover any damage resulting from the neglect of these instructions. Sunsynk assumes no liability for damage caused by the operation contrary to what is specified in this operating manual.

  • Page 3: Table Of Contents

    Table of Contents 1. SAFETY 1.1. General Safety 1.2. Symbols 1.3. Safety Instructions 1.4. Disposal Remarks 2. PRODUCT INTRODUCTION 2.1. System Overview 2.2. Product Size 2.3. Features 2.4. Basic System Architecture 3. TECHNICAL SPECIFICATIONS 4. INSTALLATION 4.1. Parts List 4.2. Selecting the Mounting Area 4.3. Mounting the Inverter 4.4. Function Port Definition 4.5. Battery Connection 4.5.1. Temperature Sensor Connection for Lead-Acid Battery 4.5.2. Connecting the AC and Backup Load Connection 4.6. Connecting the CT Coil 4.8. Meter Connection...
  • Page 4 5. OPERATION 5.1. Display 5.2. Switching ON/OFF 5.3. Home Page 5.4. Status Page 5.5. System Flow Page 5.6. Setup Page 5.7. Set Time (Clock) 5.8. Set Company Name / Beeper / Auto dim 5.9. Factory Reset and Lock Code 5.10. Battery Setup Page 5.11. Generator & Battery Page 5.12. Battery Discharge Page 5.13. Setting Up a Lithium Battery 5.14. Program Charge &...
  • Page 5 APPENDIX B APPENDIX C APPENDIX D APPENDIX E THREE PHASE HI 8~12kW | Installer Manual...

  • Page 6: Safety

    1. SAFETY 1.1. General Safety This device should only be used in accordance with the instructions within this manual and in ƒ compliance with local, regional, and national laws and regulations. Only allow this device to be installed, operated, maintained, and repaired by other person(s) who have read and understood this manual. Ensure the manual is included with this device should it be passed to a third party.

  • Page 7: Safety Instructions

    1.3. Safety Instructions WARNING HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION. Sunsynk Three-Phase Hybrid Inverter can only be installed by a qualified licensed electrical contractor. This is not a DIY product. Be sure to read this manual thoroughly before installation.

  • Page 8: Product Introduction

    2. PRODUCT INTRODUCTION The Sunsynk Three-Phase Hybrid Inverter is a highly efficient power management tool that allows the user to hit those ‘parity’ targets by managing power-flow from multiple sources such as solar, mains power (grid) and generators, and then effectively storing and releasing power as and when utilities require.

  • Page 9: Product Size

    2.2. Product Size THREE PHASE HI 8~12kW | Installer Manual...

  • Page 10: Features

    2.3. Features INTERACTIVE Easy and straightforward to understand LCD display; ƒ Supporting Wi-Fi or GSM monitoring; ƒ Visual power flow screen; ƒ Built-in 2 strings for 1 MPP tracker and 1 string for 1 MPP tracker; ƒ Smart settable 3-stage MPPT charging for optimised battery performance; ƒ...

  • Page 11: Basic System Architecture

    2.4. Basic System Architecture The following diagram explains the basic application and architecture of this 3-Phase Inverter. It also includes the following devices to have a Complete running system. Generator or Utility ƒ PV modules ƒ Batteries ƒ Normal and smart loads ƒ...

  • Page 12: Technical Specifications

    3. TECHNICAL SPECIFICATIONS Model SYNK-8K-SG04LP3 Product Type Hybrid Inverter Enclosure IP65 Ambient Temperature -45ºC ~ 60ºC (>45ºC derating) Protection Level Class I Charge Mode Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c) Battery Current 190Ad.c (max.) AC Input Voltage 3L/N/PE 220/380Va.c, 230/400Va.c AC Input Frequency...
  • Page 13 Model SYNK-10K-SG04LP3 Product Type Hybrid Inverter Enclosure IP65 Ambient Temperature -45ºC ~ 60ºC (>45ºC derating) Protection Level Class I Charge Mode Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c) Battery Current 210Ad.c (max.) AC Input Voltage 3L/N/PE 220/380Va.c, 400Va.c AC Input Frequency 50/60Hz AC Input Rated Current 15.2Aa.c...
  • Page 14 Model SYNK-12K-SG04LP3 Product Type Hybrid Inverter Enclosure IP65 Ambient Temperature -45ºC ~ 60ºC (>45ºC derating) Protection Level Class I Charge Mode Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c) Battery Current 240Ad.c (max.) AC Input Voltage 3L/N/PE 220/380Va.c, 400Va.c AC Input Frequency 50/60Hz AC Input Rated Current 18.2Aa.c...

  • Page 15: Installation

    4. INSTALLATION 4.1. Parts List Check the equipment before installation. Please make sure nothing is damaged in the package. You should have received the items in the following package: Stainless steel anti-collision bolt M8x80 Hybrid Inverter Wall Mounting Bracket Parallel communication L-type Hexagon wrench Battery Temperature Sensor cable x1 User manual x1...

  • Page 16: Selecting The Mounting Area

    4.2. Selecting the Mounting Area For proper heat dissipation, allow a clearance of approximately 500mm to the side, 500mm above and below the unit, and 1000mm to the front of the unit. DO NOT install the inverter in the following areas: Areas with high salt content, such as the marine environment.

  • Page 17: Mounting The Inverter

    Wi-Fi or GSM monitoring. If children under 10 years old may approach the unit, take preventive measures so they cannot reach ƒ and touch the unit. Install the indoor unit on the wall where the floor height is higher than 1600mm. ƒ...
  • Page 18 THREE PHASE HI 8~12kW | Installer Manual...

  • Page 19: Function Port Definition

    4.4. Function Port Definition THREE PHASE HI 8~12kW | Installer Manual...

  • Page 20: Battery Connection

    4.5. Battery Connection For safe operation and compliance, an individual DC overcurrent protector or disconnection device is required to connect the battery and the inverter. Users are recommended to utilise a suitable fuse and DC isolator (see next page). Switching devices may not be required in some applications, but overcurrent pro- tectors must be used.

  • Page 21: Temperature Sensor Connection For Lead-Acid Battery

    4.5.1. Temperature Sensor Connection for Lead-Acid Battery Without a remote temperature sensor, lead-acid batteries may undercharge or overcharge depending on the ambient temperature of the installation environment. This may result in a fire hazard. PLEASE NOTE Depending on the battery type, the inverter should be capable of controlling the battery BMS. Therefore, you need to set the protocol of the BMS on both the battery and the inverter.

  • Page 22: Connecting The Ac And Backup Load Connection

    4.5.2. Connecting the AC and Backup Load Connection Before connecting to the main grid, please install a separate AC Breaker (MCB) between the inverter and the grid. In addition, it is recommended the installation of an AC Breaker between the backup load and inverter. This will ensure the inverter can be disconnected safely during maintenance and fully protect the system from over-current.
  • Page 23 5. Check that the AC power source is isolated before attempting to connect it to the inverter. Insert AC output wires according to the polarities indicated on the terminal block and tighten the terminal screws. Be sure to connect the corresponding N wires and PE wires to the correct terminals and ensure the wires are securely connected.

  • Page 24: Connecting The Ct Coil

    4.6. Connecting the CT Coil The CT coil is one of the most important parts of the Sunsynk inverter. This device reduces the power of the inverter to prevent feeding power to the grid. This feature is also known as “Zero Export”.

  • Page 25: Meter Connection

    4.8. Meter Connection 4.8.1. System Connection for the CHNT Meter CHNT meter 4.7. Earth Connection (MANDATORY) An Earth Cable shall be connected to the earth plate on the grid size in order to prevent electric shock if the original protective conductor fails. THREE PHASE HI 8~12kW | Installer Manual...
  • Page 26 Since the inverter is a true hybrid, then the bond must only be made when the inverter is operating in Island- ing Mode. To accommodate this, Sunsynk provides an AC output, which is connected to the A/T/S connec- tions whenever the inverter is running on Island Mode. Therefore, you can simply connect the coil of an AC relay to the ATS 240 connections.

  • Page 27: Pv Connection

    4.9. PV Connection Before connecting to PV panels, install a separate DC circuit breaker between the inverter and PV modules. In addition, we request users install PV junction boxes with surge protection to protect the system from a lightning strike. To avoid any malfunction, do not connect any PV modules with possible current leakage to the inverter. For example, grounded PV modules will cause current leakage to the inverter.
  • Page 28 CAUTION Before connection, please ensure the polarity of the output voltage of the PV array matches the DC+ and DC- symbols. WARNING Please do not connect the PV array's positive and negative poles to the ground. This can seriously damage the inverter. Before connecting the inverter, please make sure the PV array open-circuit voltage is within the maximum limit of the inverter.

  • Page 29: Wiring System For The Inverter

    4. Finally, insert the DC connector into the positive and negative input of the inverter. PLEASE NOTE When sunlight falls on the solar panel, it will generate a voltage. A high voltage generated by panels in a series configuration may cause danger to life. Therefore, before connecting the DC-Input line, the solar panel’s surface should be shielded from the sun’s rays by some opaque material, and the DC switch should be off.
  • Page 30 THREE PHASE HI 8~12kW | Installer Manual...
  • Page 31 THREE PHASE HI 8~12kW | Installer Manual...

  • Page 32: Wiring Diagram

    4.11. Wiring Diagram THREE PHASE HI 8~12kW | Installer Manual...

  • Page 33: Typical Application Diagram Of Diesel Generator

    4.12. Typical Application Diagram of Diesel Generator THREE PHASE HI 8~12kW | Installer Manual...

  • Page 34: Three Phase Parallel Connection Diagram

    4.13. Three Phase Parallel Connection Diagram THREE PHASE HI 8~12kW | Installer Manual...

  • Page 35: Operation

    5. OPERATION 5.1. Display LED indicator Meaning Green LED solid light PV connection normal Green LED solid light Grid connection normal Normal Green LED solid light Inverter functioning normally Alarm Red LED solid light Fault Function Key Description To exit the previous mode Increase the value of a setting Down Decrease the value of a setting...

  • Page 36: Home Page

    5.3. Home Page Press the Esc button any page to access the home page: 1. Customer name 2. Access the settings menu page 3. Access solar history 4. Access system status page SOLAR/TURBINE AC load 5. Access system status page 6. Access grid history 7.

  • Page 37: System Flow Page

    What this page displays: Total solar power produced. Inverter voltage. ƒ ƒ MPPT 1 power/voltage/current. Inverter current. ƒ ƒ MPPT 2 power/voltage/current. Load power. ƒ ƒ Grid power. Load voltage. ƒ ƒ Grid frequency. Battery power charge/discharge. ƒ ƒ Grid voltage. Battery SOC.

  • Page 38: Setup Page

    What this page displays: The system flow. Battery status. ƒ ƒ MPPTs power. Power distribution to load or grid. ƒ ƒ 5.6. Setup Page To access Settings, click on the gear icon on the right top of the navigation menu. What this page displays: Serial number.

  • Page 39: Set Time (Clock)

    Access the Grid Setup Page (press the GRID icon). ƒ Access the real-time programmable timer/system mode (press the SYSTEM MODE icon). ƒ Access the advanced settings such as Paralleling and Wind Turbine (press the ADVANCE icon). ƒ Access the auxiliary load/smart load settings (press the AUX LOAD icon) ƒ...

  • Page 40: Factory Reset And Lock Code

    How to change the name: Change the letters in each box by moving the arrows up and down and then select OK. This will change the name on the home screen. SOLAR/TURBINE AC load BATTERY IN/OUT MPPT. GRID. Battery Grid How to set the auto dim: Set a number in the auto dim box to dim the LCD after a number of seconds.

  • Page 41: Battery Setup Page

    System self-check: Allows the user to conduct a system diagnosis. Test mode (only for engineers): For engineers to conduct tests. 5.10. Battery Setup Page To configure battery settings, click on the BATTERY icon and then on ‘Batt type’. What this page displays: Battery capacity in (Ah) –...

  • Page 42: Generator & Battery Page

    BMS setting. ƒ Active battery - This feature will help recover a battery that is 100% discharged by slowly changing from ƒ the solar array. Until the battery reaches a point where it can change normally. 5.11. Generator & Battery Page To configure battery charging settings, click on the BATTERY icon and then on ‘Batt Charge’.
  • Page 43 1Amp 12V. Below is a simple reference circuit of an auto-start system that can autostart generators on a boat. (Sunsynk will be releasing a new OS E406 ( Auto-Start ) for better generator control).

  • Page 44: Battery Discharge Page

    Generator Auto Start 5.12. Battery Discharge Page To configure inverter’s shutdown settings, click on the BATTERY icon and then on ‘Shut Down’. THREE PHASE HI 8~12kW | Installer Manual...
  • Page 45 Activating Shutdown causes the inverter to enter standby-mode. It does not entirely shut down the inverter. Total shutdown occurs at voltages below 19V. The voltage displayed on the Sunsynk Parity Inverter will vary depending on whether the inverter is charging or discharging the batteries.

  • Page 46: Setting Up A Lithium Battery

    The batteries recommended for use with the Sunsynk systems are AGM Lead Acid or Lithium Battery Banks. (‘AGM’ means Absorbed Glass Matt construction that allows the electrolyte to be suspended new the plate’s active material. In theory, this enhances both the discharge and recharging efficiency. AGM batteries are very heavy as a result).
  • Page 47 PLEASE NOTE With some types of lithium batteries, the BMS cannot be controlled by the Sunsynk inverter. In this case, treat the battery as a lead-acid type and set the charging and discharging protocol following the battery manufacturer's specifications.
  • Page 48 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter US2000B RS485 US3000 RS485 US2000C RS485 US3000C  RS485 PYLON UP5000 RS485 US5000 RS485 Force L1 RS485 Force L2 RS485 HUBBLE AM-2 5.5KW  SSIF2P15S48100C RS485 SACRED SUN FCIFP48100A RS485 Cut Line 3, 6, 8 ...
  • Page 49 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter GSL051100A-B-GBP2 GSL051200A-B-GBP2 GSL051280A-B-GBP2 GSL ENERGY  ZnP48100ESA1 GSL-51-100 GSL-51-200 TB51100F-T110 TOPBAND  TB51120-T110 4K4 LV Weco  5K3 LV IPACK C3.3 DOWELL IPACK C6.5  IPACK C10 G2500-48V Giter  G5040-48V CFE2400 CF Energy...
  • Page 50 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter Highstart HSD4870  LFP48V200AH Rosen Solar  Energy LFP51.2V200AH ZR-FC48100-1630J1 ZR-FS4850-16OSJ1 ZRGP  ZR-FS48100-16OSJ1 ZR-PBX1 BALANCELL  U-P48200-7 U-P48100-7  U-P48150-1 L01-48100 DMEGC  L02-48200 LR48100 Robuste  LR48200 4K Pack Soluna 5K Pack ...
  • Page 51 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter CLR5KWH CLW5KWH CLR10KWH COOLI  CLW10KWH CLH10KWH ESS10240 Far East Bat- FEB LV Series  tery VOLTA STAGE1 VOLTA STAGE2 VOLTA  VOLTA STAGE3 VOLTA STAGE4 LM-JW-51.2V100Ah LEMAX  LM-JW-51.2V200Ah EVO 5.7KWH 48V-120Ah ...
  • Page 52 RS485 Inverter Brand Model Storage Notes or CAN Setup Inverter Can be used with or with- BN52V-280-14.5K HC  out BMAC https://www.bluenova. co.za/wp-content/up- BN52V-560-29K HC  loads/2015/11/BN-User- Blue Nova HC Manual-HC_v102.pdf BN52V-840-43.6K HC  BN52V-1120-58.2K HC CANH = Pin 7 ...

  • Page 53: Program Charge & Discharge Times

    5.14. Program Charge & Discharge Times To set ‘Charge’ and ‘Discharge’ times, click on the ‘System Mode’ icon after clicking on the gear icon. What this page displays: A setting to prevent the inverter exporting power to the grid - ‘Zero Export’. ƒ...
  • Page 54 Example: This example shows the battery being charged up to 100% by both the Grid and Solar PV from 8 a.m. to 11 a.m. and then being able to supply up to 4kW of battery-power to the ‘essential’ loads from the ‘Load’ Port until the battery SOC drops to 50%.

  • Page 55: Grid Supply Page

    Example: The power produced is supplying the ‘Non-Essential Load’ while the inverter is set at a maximum power of 8kW (Max Sell Power). The inverter is connected to the grid, but no export is performed. The unit allows small amounts of power to flow from the Grid (100W Zero Export Power) to prevent any back-flow. In this example, the solar PV is prioritised to supply the Load first and then subsequently, charge the battery.

  • Page 56: Advanced Settings For Paralleling Inverters

    Set the Modbus SN for paralleling. ƒ The Sunsynk inverter can be wired standalone, or it can be connected in parallel when more power is required. The maximum number of inverters that can be paralleled in a three-phase utility grid is 10. In the case where 10 inverters are operating in parallel, one will operate as the Master and the other ones as Slaves.
  • Page 57 Each phase must only have one Master and the others set to slave. ƒ Each inverter must have a unique Modbus number. ƒ The maximum length of the communication cables is 2 meters (do not exceed this value) ƒ All batteries must be connected in parallel, and the MPPTs must be kept separate. ƒ...
  • Page 58 It can damage the inverter and fault F46 will be indicated on the display. If you need further help please refer to the Sunsynk website where you will find training videos and Fre- quently Asked Questions www.sunsynk.com. Firmware prior installation is important to be updated and all inverters in parallel or three phase system must be the same.

  • Page 59: Solar Power Generated

    5.17. Solar Power Generated This page shows the daily, monthly, yearly, and total solar power produced. Access this page by clicking on the ‘Solar/Turbine’ icon on the Home Page. 5.18. Grid Power This page shows the Daily / Monthly / Yearly and total grid power export or consumed. Access this page by clicking on the ‘Solar/Turbine’...

  • Page 60: Advanced Settings For Wind Turbines

    5.19. Advanced Settings for Wind Turbines To configure wind turbine settings, click on the ADVANCE icon. What this page displays: If one or both of the MPPTs are connected to a wind turbine. ƒ What you can do from this page: Select the MPPT to be used as a turbine input.

  • Page 61: Advanced Settings For Auxiliary Load

    Most wind turbines are three-phase PM type. Therefore, either a wind turbine controller or a direct connec- tion to the MPPT via a simple protection circuit will be required. Dump Load or Diversion Load is an important part of an off-grid power system. When the battery ( Battery Bank ) is fully charged, and the water turbine / wind turbine / solar PV module is still generating, a dump load is a useful device to send spare electricity to.
  • Page 62 Aux Load off Battery % or Voltage Battery level when the Aux load switches off Aux Load on Battery % or Voltage Battery level when the Aux load switches on. Solar Power Power limiter to the maximum power allowed to the Aux load. Gen Input Tick this box if using a Generator.

  • Page 63: Advanced Settings For Peak Shaving

    5.21. Advanced Settings for Peak Shaving To configure Peak Power Shaving function, click on the AUX LOAD icon.icon. What this page displays: Generator peak shaving is ON or OFF. ƒ Peak Power Shaving value. ƒ What you can do from this page: Switch on the generator and/or grid peak ƒ...
  • Page 64 Description Solutions Inverter work mode changed Working Mode Change 1.Reset the inverter. 2.Seek help from Sunsynk. AC Slide over current fault. AC over current fault or 1.Check if the backup load power is within the range of the inverter. hardware 2.Restart, and check if it is normal.
  • Page 65 Error Code Description Solutions Battery low voltage 1. Check if the battery voltage is too low. 2. If the battery voltage is too low use the PV or grid to charge the battery. DC bus bar voltage is too low 3.

  • Page 66: Operation Modes

    Before leaving the factory, all inverters undergo rigorous testing to ensure the inverter can operate reliably, as presented in Chapter 3, ‘Technical Specifications’. If you need further help please refer to the Sunsynk website where you will find training videos and frequent- ly asked questions www.sunsynk.com.

  • Page 67: Mode Iii: With Smart-Load

    5.23.3. MODE III: With Smart-Load 5.23.4. MODE IV: AC Couple THREE PHASE HI 8~12kW | Installer Manual...

  • Page 68: Commissioning

    6. COMMISSIONING 6.1. Start-Up / Shutdown Procedure The inverter must be installed by a qualified / licensed electrical engineer in accordance with the country's wiring regulations. Before switching on, the installation engineer must have completed the Earth Bond, RCD and earth leakage tests, checked that the solar panel Voc voltage does not exceed 480V and checked the battery voltage.

  • Page 69: Gdfi Fault

    Check each bond on the Check the VOC does not Ensure both MPPTs are solar panels exceed 480V balanced Measure the supply volt- If it falls out of the setting age check it matches the range it will cause the in- See Grid Setup page settings of the inverter verse shut down and alarm...
  • Page 70 APPENDIX B Inverters sold in Australia will be set to the Default Australian standards. APPENDIX C The Sunsynk Single-Phase Hybrid Inverter inverter is compatible with the SolarMan app, via a Wi-Fi or GSM data logger (See SolarMan instruction manual). APPENDIX D If an external Residual Current Device (RCD) is used it should be of Type A/AC with a tripping current of 30mA or higher.
  • Page 71 Instantaneous APPENDIX E The Sunsynk inverter can be connected to the internet, but you need to add a data logger to do this. The inverter is compatible with Solar Man data-loggers, which you can obtain from us with your distributor 1.
  • Page 72 wered by...

This manual is also suitable for:

Synk-10k-sg04lp3Synk-12k-sg04lp3

Table of Contents
