Summary of Contents for PCE Instruments PCE-PSM 10
- Page 1 USER MANUAL ELECTROSTATIC METER PCE-PSM 10 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski) can be found via our product search on: www.pce-instruments.com...
- Page 2 USE IN FLAMMABLE AND EXPLOSIVE ENVIRONMENT Explosion-proof Static Meter Explosion-proof grade:Ex ib IIB T5 Gb This product can be used in flammable and explosive working places corresponding to IIB or lower level with this safe explosion-proof function. Can detect static electricity on the surface of any object. Application field: »...
- Page 3 DC high voltage power supply Requirements to equipment or devices as follows: Calibrated product: PCE-PSM 10 DC high voltage power supply: output range -30KV ... +30KV, continuously adjustable, or minimum step 1V measurement uncertainty less than 1/4 of the allowable error limit of the calibration table;...
- Page 4 PANEL AND DISPLAY FUNCTION LED distance light Static detection window Display backlight key: Short press to turn the back light on or off LED test distance positioning key: Short press, on or off LED distance focusing Ground wire socket: This port is used for factory calibration Test data hold key: Short press, the data remains unchanged Short press again to resume real-time display...
-
Page 5: Specification
SPECIFICATION Type Static meter Model PCE-PSM 10 Detection range (KV) 0.1 ... ±200.0 Exterior color Black shell Detection accuracy ±10% Detection distance 25mm ±1.0mm Input voltage DC3V (2 x AAA) Working current <100mA Power off Press and hold the power button for 3 seconds or 180 seconds to... -
Page 6: Product Size
PRODUCT SIZE 46.16 70.87 INSTALLATION TIPS (1) Install the battery and switch on/off: First open the battery cover on the back of the static meter and put in 2xAAA standard batteries in the package. Press switch button to open. (2) Preparation before testing: In order to ensure the normal use of the static meter, first confirm that the three-segment power display on the display screen is marked as full (or enough power) and the parameters reading on the screen are clearly visible. - Page 7 We either re-use them or give them to a recycling company which disposes of the devices in line with law. For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. PCE INSTRUMENTS CONTACT INFORMATION...
