Summary of Contents for Dectris PILATUS4 R 1M

  • Page 1 Technical Specifications ® DECTRIS PILATUS 4 R 1M Document Version v1.0.2 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
  • Page 2 Document Version v1.0.2 © Copyright 2025 DECTRIS Ltd.
  • Page 3: Table Of Contents

    PILATUS4 R 1M Detector ........
  • Page 4 Cleaning and Maintenance ......... 25 TROUBLESHOOTING ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2...
  • Page 5: General Information

    1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. DECTRIS USA Inc. DECTRIS Japan K.K. Taefernweg 1 1500 Walnut Street, Suite 1630 Mitsuwa Building 1F 5405 Baden-Daettwil Philadelphia, PA 19102 Minamimachi 63, Himeji-shi Switzerland Hyogo 670-0912, Japan Phone: +41 56 500 21 02...
  • Page 6: Warranty Information

    (in particular information, ® images or materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means.
  • Page 7: Usage Of The Pilatus4 R 1M

    2. USAGE OF THE PILATUS4 R 1M The PILATUS4 R 1M hybrid-photon-counting (HPC) detector system has been designed for the detection of X- rays produced by synchrotrons or laboratory sources. It is intended for indoor use only. For other applications, ®...
  • Page 8: Technical Specifications

    Means of protection I (power supply) Values are for Cu radiation For single threshold. Using two thresholds halves the frame rate. Using three or four thresholds quarters it. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 4 | 28...
  • Page 9: Ratings

    Please consult the user documentation of the DTMF300-48SX-F-W6 power supply unit for de- tails. Caution Only use the power supply delivered with the PILATUS4 R 1M. Table 3.3: Power Supply Unit Ratings Power supply unit power input 90 VAC to 264 VAC, 47 Hz to 63 Hz, 3 A max.
  • Page 10: Detector Control Unit

    Dimensions (W x H x D) 300 mm x 290 mm x 455 mm Weight 27.5 kg −1 Typical flow 3 L min Maximum operation pressure 3 bar ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 6 | 28...
  • Page 11: Ambient Conditions

    The PILATUS4 R 1M detector is designed for indoor use only. The ambient conditions shown in table 3.6 must be satisfied. The stated values are for the ambient conditions.
  • Page 12: Detector Components And Connectors

    3D step files of the PILATUS4 R 1M detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the PILATUS4 R 1M Detector (also printed separately in the user documentation folder) ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2...
  • Page 13: Front Side Of The Detector

    Do not apply any force on the screws, the screws do not need to be tightened to hold the cover in place and excessive force can damage the housing. Figure 4.2: The PILATUS4 R 1M Detector with the Cover Removed (front view) ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2...
  • Page 14: Back Side Of The Detector

    4.1.3. Back Side of the Detector Figure 4.3: The PILATUS4 R 1M Detector (back view) ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 10 | 28...
  • Page 15: Status Leds

    10GBASE-LR Single Mode SFP+ optical transceivers. Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed other- wise. Please contact support@dectris.com if you need replacement transceivers. Caution There must be a 2 x LC/UPC duplex fiber optic connectors point-to-point connection between detector and detector control unit.
  • Page 16 Plug dry-break double shut-off. Caution For in-vacuum operation do not use the stan- dard connectors. A specific vacuum feedthrough set containing all required parts is available from ® DECTRIS ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 12 | 28...
  • Page 17: Detector Control Unit

    Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. Figure 4.5: Back view of detector control unit with network interfaces. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 13 | 28...
  • Page 18: Connectors

    See DELL owner’s manual for further details. 4.3. Thermal Stabilization Unit A thermal stabilization unit is required for the operation of the PILATUS4 R 1M detector system. The hoses and the detector are equipped with self-sealing quick connect fittings to avoid dripping when con- necting or disconnecting the tubes.
  • Page 19: In-Vacuum Usage

    Prior to powering up and operating the detector in- vacuum the thermal stabilization unit has to be set to a temperature of 17 °C for at least 30 min. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 15 | 28...
  • Page 20: Installing The Detector System Transport Considerations

    • Make sure the power supply has enough space for proper ventilation (minimum wall dis- tance: 100 mm). • Do not operate the power supply in a closed environment. The detector can be mounted in the ways which are described below. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 16 | 28...
  • Page 21: Mounting From Below

    The detector should be mounted using the four internal M6x1 threads as shown in figure 5.1 (indicated with yellow circles). Figure 5.1: Drawing of the PILATUS4 R 1M detector base plate. Caution The four M6 screws must not intrude into the detector more than 10 mm.
  • Page 22: Grounding Of The Detector

    Figure 5.2: Drawing of the PILATUS4 R 1M Detector Base Plate with Mounting Brackets (bottom view) 5.3. Grounding of the Detector Caution The mains plug of the power supply has to be connected to a grounded power outlet. Although the detector might be already grounded via the mounting bolts, the detector should be grounded additionally via the functional ground connector at the back in order to establish a defined grounding.
  • Page 23: In-Vacuum Usage

    The PILATUS4 R 1M detector has to be connected to a dry air (or nitrogen) source to avoid humidity and con- densation damage when it is outside of the storage box. For information on system connections, refer to the section 4.1.5 and for storage of the detector system refer to the section 7.5.
  • Page 24: Checking The Connection

    • Do not add any component other than those supplied by DECTRIS to the cooling circuit. The PILATUS4 R 1M detector is water-cooled and must be connected to a dedicated thermal stabilization unit. The detector is supplied with quick coupling connectors to connect the cooling tubes to the thermal stabiliza- tion unit.
  • Page 25: Mounting The Detector Control Unit

    The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2...
  • Page 26: Temperature And Humidity Control

    6. TEMPERATURE AND HUMIDITY CONTROL The PILATUS4 R 1M detector has a combined temperature and humidity sensor. The temperature and humidity control shuts down the detector when the humidity or the temperature of the sensor exceeds the following limits: Table 6.1: Temperature and Humidity Limits...
  • Page 27: Operation Procedure

    • Turn OFF the detector control unit. • Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.4. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 23 | 28...
  • Page 28: Vacuum Operation

    To see if a detector is vacuum compatible, check whether the vacuum compatibility option is included in the ® order confirmation received from DECTRIS 7.4.1. Ambient Conditions for In-Vacuum Use For in-vacuum operation of the detector following conditions must be fulfilled: Table 7.1: In-Vacuum Operating Conditions...
  • Page 29: Storing The Detector

    If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The PILATUS4 R 1M detector does not require any maintenance. The coolant liquid has to be replaced every 12 months. For information on the coolant liquid, see section 4.3.
  • Page 30: Troubleshooting

    If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. The LEDs at the back of the detector can provide valuable information for troubleshooting. Check section 4.1.4 for further information.
  • Page 31 Shut down the detector imme- tector exceeds the operating con- diately and check the humidity. ditions. Power up the detector only when the ambient humidity has been reduced. ® DECTRIS PILATUS 4 R 1M Technical Specifications v1.0.2 27 | 28...
  • Page 32: Trademarks And Patents

    Trademarks ® Registered trademarks ”DECTRIS”: AU, AUS, CH, CN, DE, FR, IT, JP, KR, USA, UK, ”DETECTING THE FUTURE”: AUS, CH, CN, EU, JP, KR, USA, UK, ”DECTRIS INSTANT RETRIGGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS EIGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS PILATUS”: AUS, CH, CN, EU, JP, KR, USA...
