  • Page 1 Technical Specifications ® DECTRIS PILATUS 4 X CdTe 4M Document Version v1.0.2 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
  • Page 2 Document Version v1.0.2 © Copyright 2025 DECTRIS Ltd.
  • Page 3: Table Of Contents

    PILATUS4 X CdTe 4M Detector ........
  • Page 4 TROUBLESHOOTING ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 ii | 28...
  • Page 5: General Information

    1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. DECTRIS USA Inc. DECTRIS Japan K.K. Taefernweg 1 1500 Walnut Street, Suite 1630 Mitsuwa Building 1F 5405 Baden-Daettwil Philadelphia, PA 19102 Minamimachi 63, Himeji-shi Switzerland Hyogo 670-0912, Japan Phone: +41 56 500 21 02...
  • Page 6: Warranty Information

    (in particular information, ® images or materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means.
  • Page 7: Usage Of The Pilatus4 X Cdte 4M

    2. USAGE OF THE PILATUS4 X CdTe 4M The PILATUS4 X CdTe 4M hybrid-photon-counting (HPC) detector system has been designed for the detection of X-rays produced by synchrotrons or laboratory sources. It is intended for indoor use only. For other appli- ®...
  • Page 8: Technical Specifications

    For photon energy ≥13 keV and energy threshold at 50 % of the photon energy. For single threshold. Using two thresholds halves the frame rate. Using three or four thresholds quarters it. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2...
  • Page 9: Ratings

    External trigger input impedance 47 kΩ High level: 2.3 V to 3.3 V Detector trigger output Low level: 0.0 V to 0.6 V Max. current: 24 mA ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 5 | 28...
  • Page 10: Detector Control Unit

    377 mm x 615 mm x 500 mm Weight 115 V version: 40.0 kg 230 V version: 43.0 kg −1 Typical flow 3 L min Maximum operation pressure 3 bar ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 6 | 28...
  • Page 11: Ambient Conditions

    The PILATUS4 X CdTe 4M detector is designed for indoor use only. The ambient conditions shown in table 3.5 must be satisfied. The stated values are for the ambient conditions.
  • Page 12: Detector Components And Connectors

    3D step files of the PILATUS4 X CdTe 4M detector are available on request. Please contact ® DECTRIS technical support for more information. Figure 4.1: Drawing of the PILATUS4 X CdTe 4M Detector (also printed separately in the user documentation folder) ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2...
  • Page 13: Front Side Of The Detector

    Figure 4.2: The PILATUS4 X CdTe 4M Detector with the Cover Removed (front view) ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2...
  • Page 14: Back Side Of The Detector

    4.1.3. Back Side of the Detector Figure 4.3: The PILATUS4 X CdTe 4M Detector (back view) ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 10 | 28...
  • Page 15: Status Leds

    10GBASE-LR Single Mode SFP+ optical transceivers. Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed other- wise. Please contact support@dectris.com if you need replacement transceivers. Caution There must be a 4 x LC/UPC duplex fiber optic connectors point-to-point connection between detector and detector control unit.
  • Page 16 To release the tube press and hold the blue ring before pulling at the tube. Table 4.4: Coolant Connectors (see section 5.6) Connector Description Coolant inlet. Quick coupling dry-break double shut-off. Coolant outlet. Plug dry-break double shut-off. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 12 | 28...
  • Page 17: Detector Control Unit

    All image data on the detector control unit will be permanently lost. Information Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 13 | 28...
  • Page 18: Connectors

    The unused data ports are closed with an EMI plug. Do not remove the plugs. 2 x Power AC Connector (redundant power supply) See DELL owner’s manual for further details. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 14 | 28...
  • Page 19: Thermal Stabilization Unit

    4.3. Thermal Stabilization Unit A thermal stabilization unit is required for the operation of the PILATUS4 X CdTe 4M detector system. The hoses and the detector are equipped with self-sealing quick connect fittings to avoid dripping when con- necting or disconnecting the tubes.
  • Page 20: Installing The Detector System Transport Considerations

    It is strictly forbidden to add any threads to the detector base plate or to the detector housing. The detector should be mounted using the four internal M6x1 threads as shown in figure 5.1 (indicated with yellow circles). ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 16 | 28...
  • Page 21: Mounting From Above

    Figure 5.1: Drawing of the PILATUS4 X CdTe 4M detector base plate. Caution The four M6 screws must not intrude into the detector more than 10 mm. 5.2.2. Mounting from Above Use the mounting brackets as depicted in figure 5.2. These mounting brackets have to be mounted on the base plate of the detector.
  • Page 22: Grounding Of The Detector

    Figure 5.2: Drawing of the PILATUS4 X CdTe 4M Detector Base Plate with Mounting Brackets (bottom view) 5.3. Grounding of the Detector Although the detector might be already grounded via the mounting bolts, the detector should be grounded additionally via the functional ground connector at the back in order to establish a defined grounding.
  • Page 23: Fiber Optic Cable Installation

    The PILATUS4 X CdTe 4M detector has to be connected to a dry air (or nitrogen) source to avoid humidity and condensation damage when it is outside of the storage box. For information on system connections, refer to the section 4.1.5 and for storage of the detector system refer to the section 7.4.
  • Page 24: Cleaning The Connectors

    • Do not add any component other than those supplied by DECTRIS to the cooling circuit. The PILATUS4 X CdTe 4M detector is water-cooled and must be connected to a dedicated thermal stabilization unit. The detector is supplied with quick coupling connectors to connect the cooling tubes to the thermal sta- bilization unit.
  • Page 25: Mounting The Detector Control Unit

    The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2...
  • Page 26: Temperature And Humidity Control

    6. TEMPERATURE AND HUMIDITY CONTROL The PILATUS4 X CdTe 4M detector has a combined temperature and humidity sensor. The temperature and humidity control shuts down the detector when the humidity or the temperature of the sensor exceeds the following limits: Table 6.1: Temperature and Humidity Limits...
  • Page 27: Operation Procedure

    • Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.4. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 23 | 28...
  • Page 28: Storing The Detector

    If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The PILATUS4 X CdTe 4M detector does not require any maintenance. The coolant liquid has to be replaced every 12 months. For information on the coolant liquid, see section 4.3.
  • Page 29: Safety Instructions For Cdte Sensors

    • Do not inhale Cadmium Telluride (CdTe) dust when sensor is broken or burnt. • Do not ingest Cadmium Telluride (CdTe). • Avoid skin contact. For recycling, see section 2.1. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 25 | 28...
  • Page 30: Troubleshooting

    If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. The LEDs at the back of the detector can provide valuable information for troubleshooting. Check section 4.1.4 for further information.
  • Page 31 Shut down the detector imme- tector exceeds the operating con- diately and check the humidity. ditions. Power up the detector only when the ambient humidity has been reduced. ® DECTRIS PILATUS 4 X CdTe 4M Technical Specifications v1.0.2 27 | 28...
  • Page 32: Trademarks And Patents

    Trademarks ® Registered trademarks ”DECTRIS”: AU, AUS, CH, CN, DE, FR, IT, JP, KR, USA, UK, ”DETECTING THE FUTURE”: AUS, CH, CN, EU, JP, KR, USA, UK, ”DECTRIS INSTANT RETRIGGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS EIGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS PILATUS”: AUS, CH, CN, EU, JP, KR, USA...
