- Page 1 Technical Specifications ® DECTRIS PILATUS 4 XE 4M Document Version v1.0.2 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
- Page 2 Document Version v1.0.2 © Copyright 2025 DECTRIS Ltd.
-
Page 3: Table Of Contents
PILATUS4 XE 4M Detector ........ - Page 4 TROUBLESHOOTING ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 ii | 28...
-
Page 5: General Information
1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. DECTRIS USA Inc. DECTRIS Japan K.K. Taefernweg 1 1500 Walnut Street, Suite 1630 Mitsuwa Building 1F 5405 Baden-Daettwil Philadelphia, PA 19102 Minamimachi 63, Himeji-shi Switzerland Hyogo 670-0912, Japan Phone: +41 56 500 21 02... -
Page 6: Warranty Information
(in particular information, ® images or materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means. -
Page 7: Usage Of The Pilatus4 Xe 4M
2. USAGE OF THE PILATUS4 XE 4M The PILATUS4 XE 4M hybrid-photon-counting (HPC) detector system has been designed for the detection of X-rays produced by synchrotrons or laboratory sources. It is intended for indoor use only. For other applica- ®... -
Page 8: Technical Specifications
For photon energy ≥13 keV and energy threshold at 50 % of the photon energy. For single threshold. Using two thresholds halves the frame rate. Using three or four thresholds quarters it. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2... -
Page 9: Ratings
External trigger input impedance 47 kΩ High level: 2.3 V to 3.3 V Detector trigger output Low level: 0.0 V to 0.6 V Max. current: 24 mA ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 5 | 28... -
Page 10: Detector Control Unit
3.2.4. Thermal Stabilization Unit Information Please consult the user documentation of the SMC HRS-012A thermal stabilization unit for de- tails. Caution The maximum allowable coolant pressure is 3 bar. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 6 | 28... -
Page 11: Ambient Conditions
The PILATUS4 XE 4M detector is designed for indoor use only. The ambient conditions shown in table 3.6 must be satisfied. The stated values are for the ambient conditions. -
Page 12: Detector Components And Connectors
3D step files of the PILATUS4 XE 4M detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the PILATUS4 XE 4M Detector (also printed separately in the user documentation folder) ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2... -
Page 13: Front Side Of The Detector
Do not apply any force on the screws, the screws do not need to be tightened to hold the cover in place and excessive force can damage the housing. Figure 4.2: The PILATUS4 XE 4M Detector with the Cover Removed (front view) ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2... -
Page 14: Back Side Of The Detector
4.1.3. Back Side of the Detector Figure 4.3: The PILATUS4 XE 4M Detector (back view) ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 10 | 28... -
Page 15: Status Leds
Detector and detector control unit are equipped with 10GBASE-LR Single Mode SFP+ optical transceivers. Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed other- wise. Please contact support@dectris.com if you need replacement transceivers. POWER AC power connector (see table 3.2) EXT IN External trigger input (see table 3.2) -
Page 16: Detector Control Unit
4.6. The detector control unit is optimized for performance and stability of operation. In order to achieve these goals we deliver the detector control unit with fixed firmware (BIOS etc.) and software ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2... - Page 17 Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. Figure 4.5: Back view of detector control unit with labeled network interfaces. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 13 | 28...
-
Page 18: Connectors
4.3. Switch For the PILATUS4 XE 4M, a switch is used for the connection between the detector and the detector control unit. The switch is connected to the detector control unit using 2 x 3 m direct attach 100 Gb cables. The connection between the switch and the detector is done via 4 x 30 m fiber optics cables. - Page 19 Connection to detector DATA ports 1-16 (the order of the connections does not matter) Slots 19 & 20 Connection to DCU as indicated in figure 4.4 Figure 4.7: Connection schematics. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 15 | 28...
-
Page 20: Thermal Stabilization Unit
4.4. Thermal Stabilization Unit A thermal stabilization unit is required for the operation of the PILATUS4 XE 4M detector system. The hoses and the detector are equipped with self-sealing quick connect fittings to avoid dripping when con- necting or disconnecting the tubes. -
Page 21: Installing The Detector System Transport Considerations
It is strictly forbidden to add any threads to the detector base plate or to the detector housing. The detector should be mounted using the four internal M6x1 threads as shown in figure 5.1 (indicated with yellow circles). ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 17 | 28... -
Page 22: Mounting From Above
Figure 5.1: Drawing of the PILATUS4 XE 4M detector base plate. Caution The four M6 screws must not intrude into the detector more than 10 mm. 5.2.2. Mounting from Above Use the mounting brackets as depicted in figure 5.2. These mounting brackets have to be mounted on the base plate of the detector. -
Page 23: Grounding Of The Detector
Figure 5.2: Drawing of the PILATUS4 XE 4M Detector Base Plate with Mounting Brackets (bottom view) 5.3. Grounding of the Detector Although the detector might be already grounded via the mounting bolts, the detector should be grounded additionally via the functional ground connector at the back in order to establish a defined grounding. -
Page 24: Fiber Optic Cable Installation
The PILATUS4 XE 4M detector has to be connected to a dry air (or nitrogen) source to avoid humidity and con- densation damage when it is outside of the storage box. For information on system connections, refer to the section 4.1.5 and for storage of the detector system refer to the section 7.4. -
Page 25: Cleaning The Connectors
• Do not add any component other than those supplied by DECTRIS to the cooling circuit. The PILATUS4 XE 4M detector is water-cooled and must be connected to a dedicated thermal stabilization unit. The detector is supplied with quick coupling connectors to connect the cooling tubes to the thermal stabiliza- tion unit. -
Page 26: Mounting The Detector Control Unit
The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2... -
Page 27: Temperature And Humidity Control
6. TEMPERATURE AND HUMIDITY CONTROL The PILATUS4 XE 4M detector has a combined temperature and humidity sensor. The temperature and humidity control shuts down the detector when the humidity or the temperature of the sensor exceeds the following limits: Table 6.1: Temperature and Humidity Limits... -
Page 28: Operation Procedure
• Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.4. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 24 | 28... -
Page 29: Storing The Detector
If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The PILATUS4 XE 4M detector does not require any maintenance. The coolant liquid has to be replaced every 12 months. For information on the coolant liquid, see section 4.4. -
Page 30: Troubleshooting
If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. The LEDs at the back of the detector can provide valuable information for troubleshooting. Check section 4.1.4 for further information. - Page 31 Shut down the detector imme- tector exceeds the operating con- diately and check the humidity. ditions. Power up the detector only when the ambient humidity has been reduced. ® DECTRIS PILATUS 4 XE 4M Technical Specifications v1.0.2 27 | 28...
-
Page 32: Trademarks And Patents
Trademarks ® Registered trademarks ”DECTRIS”: AU, AUS, CH, CN, DE, FR, IT, JP, KR, USA, UK, ”DETECTING THE FUTURE”: AUS, CH, CN, EU, JP, KR, USA, UK, ”DECTRIS INSTANT RETRIGGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS EIGER”: AUS, CH, CN, EU, JP, KR, USA, UK ”DECTRIS PILATUS”: AUS, CH, CN, EU, JP, KR, USA...
