- Page 1 MISURA MONITOR 27″ CURVED USER MANUAL ENGLISH Model: P24MM27DQIO1B – 165 Hz 178° 1 ms QHD resolution 165 Hz refresh High Dynamic Ultra Wide VA Curved Response Time FreeSync & G-Sync Low Blue Eyes 2560×1440 frequency Range Viewing Angle panel...
-
Page 2: General Information
GENERAL INFORMATION Dear Customer, Thank you for having purchased this product. This document describes how to install and use the LED backlit LCD color monitor. Read this manual which contains information for correct, safe use. Keep this manual at hand so that you can refer to it when needed. -
Page 3: Installation Precautions
WARNINGS Power Use only the provided power unit to plug in the device. Verify the power supply rating before connecting the power unit. Do not pull the cable to unplug the device without turning the device off first. Safety precautions Keep the device away from rain and humidity to prevent risk of fire and ... - Page 4 Do not place heavy or heat generating objects on top of the device: this could damage the casing and/or increase internal temperature causing damage. Do not cover the device with a cloth while it is running to prevent deforming of the external casing and overheating of the internal parts: risk of fire, electrocution and mechanical failure.
-
Page 5: Monitor Inputs
MONITOR INPUTS 4 | DP 1 | DC 2 | HDMI 5 | DP 3 | HDMI 6 | AUDIO OUT... -
Page 6: Monitor Control Buttons
MONITOR CONTROL BUTTONS Monitor Button Action Used for exiting OSD (moving to the left). Auto Out of OSD its used to auto-adjust the picture Button for entering the main menu and confirming Menu your selection (moving to the right) Move up in the menu Move down in the menu Down Turning on and off the power supply. -
Page 7: Input Source
OSD MENU Input Source Resolution: 2560 × 1440 @ 165 hz Input source Setting HDMI2 Setting HDMI1 Switch the signal input to DP2, DP1, HDMI2, HDMI1, or have the monitor Auto Select the source. Brightness/Contrast Resolution: 2560 × 1440 @ 165 hz Brightness Brightness/Contrast Contrast... - Page 8 Color Setting Resolution: 2560 × 1440 @ 165 hz Color Setting Gamma Change the display Gamma value to: 2.0,2.2,2.4. Pirture Mode Change the pre-set mode to: Standard, Photo, Game, Movie, RTS or FPS. Color Change the color temperature to: Temperature Normal, Warm, Cool, User.
-
Page 9: Picture Quality Setting
Picture Quality Setting Resolution: 2560 × 1440 @ 165 hz Picture Quality Setting Sharpness Change the display Sharpness value from 0 to 100. Response Time Select the Response Time Value from, Low, Middle, High or turn it Off. Noise Select the Noise Reduction Value from, Low, Middle, Reduction High or turn it Off. - Page 10 Resolution: 2560 × 1440 @ 165 hz Language Change the OSD Menu display language. OSD H Position Change the horizontal position of the OSD Menu. OSD V Position Change the vertical position of the OSD Menu. OSD Transparency Change the transparency value of the OSD Menu from 0 to 100.
-
Page 11: Setting Of Display Mode
SAFEGUARD When the video signal from your computer exceeds the monitor’s supported frequency range (refer to product specifications), the monitor’s micro-computer will disable the horizontal and vertical sync signals to protect the monitor. Please refer to the illustration below. After a few seconds, the monitor will enter power-saving mode, and the power indicator will turn red. -
Page 12: Technical Specification
TECHNICAL SPECIFICATION Model P24MM27DQIO1B Screen Size 27" Panel type CURVED Backlight type Aspect Ratio 16:9 Brightness 250cd/m ² Contrast ratio (typical) 4000:1 Resolution 2560 × 1440 Response time 1 ms with OD Viewing Angle 178 º/178 º (CR>10) Color Support 16.7 Million Colors (8bit) Refresh rate 165 Hz... -
Page 13: Troubleshooting
TROUBLESHOOTING If your monitor cannot work normally, please refer to the following methods for solving common problems quickly. If you need assistance, please refer to manufacturer‘s customer service contact. A. There is no Screen Image/LED no light Please check to see whether the power cord is securely connected to the monitor and wall outlet, and whether the display is in power-saving mode. - Page 14 Thank you for your purchase. If you need anything, please contact us at: Producer / Importer MISURA Store s.r.o., ID: CZ264 03 714 www.misura.shop info@misura.shop @SHOPMisura @misura_shop @MISURA We are not responsible for any typographical errors.
