Akytec MK210-302 Short Manual

Digital I/O module
Short guide
1. Overview
MK210-302/312 is an extension module with 12 inputs and 4 digital
outputs (relays).
The module has two Ethernet ports for connection within the daisy chain
scheme. If the module fails or the power is turned off, the data
transmission will be fed directly from port 1 to port 2 without
disconnecting.
The full User Guide is available on the device page at www.akytec.de .
2. Environmental conditions
Table 1 Operating conditions
Permissible range
Condition
Ambient temperature
Transportation and storage
Relative humidity up to 95 % (at +35 °C, non-condencing)
Attitude up to 2000 m ASL
IP code
Vibration / shock resistance conforms to IEC 61131-2
EMC emission / immunity
conforms to IEC 61131-2
3. Specifications
Table 2 General specifications
Parameter
Electrical
Power supply 24 (10 ... 48) V DC
Power consumption
6 W at 24 V DC
Polarity protection
Appliance class
Interfaces
Data transfer Double Ethernet 10/100 Mbps
Protocols Modbus TCP, MQTT, SNMP, NTP
USB 2.0 (MicroUSB)
Configuration interface
Ethernet 10/100 Mbps
Digital inputs
Inputs number
contact sensor
Input signal
NPN and PNP transistor
logical level detection
high frequency pulse counter (DI1-DI8)
Functions
frequency measurement (DI1-DI8)
encoder signal processing
Pulse length, min, (DI1-8) 5 µs (up to 100 kHz)
Pulse length, min, (DI9-12) 1 ms (up to 400 Hz)
LOW level (current), max.
HIGH level (current). max.
LOW level (voltage range).
HIGH level (voltage range)
MK210-302/312_3-EN-43887-2.1
© All rights reserved. Subject to technical changes and misprints.
Parameter
Outputs number
Output type
Control
Switching
capacity
Switching current, min.
Switching time
PWM frequency, max.
PWM pulse length, min.
Optional functions
Service life,
electrical
Service life, mechanical
-40...+55 °C
File size, max.
Number of log files, ,max.
IP20 Logging interval, min.
Accuracy
Backup battery
Dimensions
Value
Weight
4. Installation and connection
Before installation make sure there is enough free space for connecting
Yes
the module and placing the wires. The module is mounted on a DIN rail
II
or on a vertical surface using screws.
Installation of external connections is carried out by a wire with a cross
section of not more than 0.75 mm
For stranded wires, use end sleeves.
After installation, put the wires into the cable channel of the module
housing and close the cover.
If necessary, in order to remove the terminal blocks of the module, loosen
12
the two screws at the corners of the terminal blocks.
CAUTION
Connection and maintenance is performed only when the
module power and the power to all devices connected to it is
turned off.
Table 3 Network parameters
Parameter
IP address
1.2 mA
Subnet mask
5.5 mA
0.0...6.1 V
Gateway
8.8...30.0 V
DNS server 1
DNS server 2
MK210-302/312
Digital I/O module
Value
Digital outputs
4
Relay, NO
On-Off or PWM
5 A, 250 VAC, resistive load
AC
DC 3 A, 30 VDC
10 mA at 5 VDC
15 ms
1 Hz with 0.05 duty cycle
50 ms
Safe state
Output diagnostics (only MK210-312)
35,000 switching cycles
3 A, 30 VDC
50,000 switching cycles
5 A, 250 VAC
5,000,000 switching cycles
Flash-memory (log file storage)
2 kB
1000
10 s
Real time clock
±3 s/day at +25 °С
±10 s/day at -40 °С
CR2032
Mechanical
42 × 124 × 83 mm
approx. 260 g
2 .
Description
Default value
IPv4 Internet Protocol address 192.168.1.99
IP address recognition area in the
255.255.255.0
subnet
IP address of the gateway
192.168.1.1
Primary DNS server
77.88.8.8
Secondary DNS server
5. Connection diagrams
Fig. 1 Terminal block layout
Table 4 Terminal assignments
Marking
DI1...DI12 Input terminals
SS Common input power supply point
NC Not connected
DO1A...DO4A, Output terminal
DO1B...DO4B
The service button performs the following functions:
• Factory settings restore
• IP-address assignment
Fig. 2 Device connectors
8.88.8.8
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany
Description
Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
