- Page 1 GENERATOR MODEL NO: CP3550K PART NO: 8857740 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC11/24 -REV 1...
-
Page 2: Environmental Protection
INTRODUCTION Thank you for purchasing this CLARKE Generator. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: EXHAUST FUMES CAN BE EXTREMELY DANGEROUS IF INHALED WORK AREA • ALWAYS use in a well ventilated area. • ALWAYS position the exhaust outlet away from people. • Read these safety instructions before using the equipment. •... -
Page 4: Exhaust Gas Precautions
13. DO NOT Alter the engine settings, the voltage and frequency of the generator output is directly linked to the engine speed. These settings are factory set. Should they need re-calibration - consult your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 5: Safety Symbols
14. Connect only those appliances whose voltage (according to their data plate) corresponds to that produced by the generator. IMPORTANT!: This generator uses either a floating chassis or neutral reference to chassis earthing system. (refer to technical information sheet). Neutral reference to chassis generators MUST be connected to an earthing spike to ensure they are properly grounded. -
Page 6: Unpacking And Assembly
UNPACKING AND ASSEMBLY Unpack your generator and check the following items are present. Should there be any missing or damaged during transit contact your CLARKE dealer. BEFORE USING THE GENERATOR IMPORTANT: Generators should ALWAYS be earthed. Make sure you earth the generator. - Page 7 • DO NOT fill above the max level mark. • We recommend the use of SAE10W/30 oil in this generator. (CLARKE part number 3050845) • DO NOT tilt the generator when adding engine oil. This could result in overfilling and damage to the engine.
-
Page 8: Preparation For Use
PREPARATION FOR USE EXTENSION CABLES All extension cables from the generator set to the appliance, must be carefully selected, fitted and maintained. Cables in accordance with IEC 245-4 should be used. Cables should be inspected regularly and should be replaced, not repaired in the event of a defect. - Page 9 Some appliances draw more current on start-up than their normal running current, i.e. electric motors, and compressors. If in any doubt as to whether an appliance is compatible or not, please consult your CLARKE dealer. Additionally, please refer to the specifications sheet attached, to ensure the machine is used under the correct operating conditions.
-
Page 10: Shutting Down The Generator
3. Fill the oil reservoir with fresh oil. • DO NOT fill above the max level mark. • We recommend the use of SAE10W/30 oil in this generator. (CLARKE part number 3050845) 4. Replace the oil filler cap and maintenance panel. - Page 11 2. Remove the air filter panel and the air filter element. 3. If the air filter is damaged contact the CLARKE spare parts department for a replacement. • If the filter is dirty, wash it in a solution of warm water and mild detergent and then rinse thoroughly.
-
Page 12: Spare Parts
1. Remove the fuel tank cap. 2. Lift out the filter inside. 3. Clean the filter with solvent. If the filter is damaged, contact CLARKE Spare Parts department for a replacement. 4. Replace the filter and fuel tank cap. -
Page 13: Troubleshooting
Erratic supply Incorrect engine rpm Adjust engine speed Internal alternator problem Contact CLARKE servicing If this does not solve your problem, please contact the CLARKE service department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Specification
SPECIFICATION Item Specification Model No CP3550K Dimensions (L x W x H) 610 x 420 x 410 mm Weight 36 kg Engine type Honda GX200 Displacement 196cc Engine power 6.5HP Fuel capacity 3.6 L Fuel consumption 1.1 L/hr Running time (full tank) 3.2 Hr... -
Page 15: Declarations Of Conformity
DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
