- Page 1 © 0201 GAS POWERED GENERATOR GAS POWERED GENERATOR Model CGH3500 Operating & Maintenance Instructions Product Serial/Batch No:......
- Page 2 ALWAYS BE CARRIED OUT BY A QUALIFIED ELECTRICIAN AND IN ACCORDANCE WITH CURRENT IEE REGULATIONS FOR ELECTRICAL INSTALLATIONS. FAILURE TO HEED THIS WARNING COULD RESULT IN SEVERE ELECTRIC SHOCK, FIRE AND EVEN DEATH © Copyright: Clarke International, All rights reserved. January, 2001...
-
Page 3: Table Of Contents
Electrical Diagram ......................18 Declaration of Conformity ................... 19 Thank you for purchasing this Clarke Power Generator. Before use please read these instructions. This is for your own safety and that of others around you, and also to ensure the Generator provides you with long and trouble free service. -
Page 4: For Your Own Safety
FOR YOUR OWN SAFETY WARNING: EXHAUST FUMES CAN BE EXTREMELY DANGEROUS IF INHALED • Always use in a well ventilated area . • Always position the exhaust outlet away from people. • Never use indoors or in a confined space. •... - Page 5 Positioning the Generator for use Always leave a least a 1M gap between the generator and any surrounding building or structures. Always ensure the generator is on a solid, flat surface. Always ensure the surrounding area is free from 1M (3ft) any material that could burn or be damaged by heat.
- Page 6 OVERVIEW Fig.1 A - Gas Controller - 110V and 230V Reset Buttons - Alternator G - Gas Regulator C - 110/230V Selector Switch - Starter Cord D - 230V Outlet (BLUE) - Ignition ON/OFF Switch - 110V Outlet (YELLOW) - Air Filter Box Securing Nut Fig.2...
- Page 7 Remove the dipstick, shown arrowed in Fig.3. If the level is lower than the bottom of the dipstick hole, it must be topped up so that it is level with the top of the hole. Fig.3 Use CLARKE High Performance Oil - SAE10W30, available from your Clarke dealer. 1 Litre....Part No. 3050852 5 litre....Part No. 3050855...
-
Page 8: Using Your Generator
USING YOUR GENERATOR A. Starting the Engine IMPORTANT ! Ensure the generator is not connected to any electrical equipment when starting the engine. (See ‘Connecting Electrical Devices’, page 9). Ensure you perform all maintenance tasks before attempting to start the engine. Fig.4 Turn the gas ON at the gas bottle. -
Page 9: Connecting Electrical Devices
B. Connecting Electrical devices Before connecting any appliance to the generator, it is IMPORTANT to strictly follow all safety precautions previously given, and also to take the following limitations and considerations into account when planning your installation. 1.1 General Ensure that the power rating of the connected appliance does not exceed the rating for the generator (See Specifications), and the appliance is switched OFF. - Page 10 With all the above taken into account, and only when completely satisfied that the proposed installation is perfectly safe, proceed to connect and operate the appliances as follows: Ensure the 110/230V selector switch, on top of the generator (C. Fig.1) , is in the MIDDLE (OFF) position, and the electrical appliance is switched OFF (ii) Insert the plug, from the appliance, into the respective socket outlet,...
-
Page 11: Maintenance Schedule
ALWAYS allow the engine to cool for at least 15 minutes before carrying out any maintenance tasks. Use only those parts provided by CLARKE International. The use of unapproved parts could cause damage to your generator set. - Page 12 Carefully wipe the drain hole with a clean, lint free cloth and then replace the drain plug..ensuring the washer is in place and the plug is tight. Fill the sump with new Clarke SAE30 Engine Oil. (see your Clarke dealer and Specifications for details).
-
Page 13: Air Filter
Servicing the Air Cleaner WARNING! NEVER USE PETROL OR INFLAMMABLE LIQUIDS TO CLEAN THE AIR CLEANER ELEMENTS: THIS PRACTICE COULD CAUSE FIRE WITH THE RESULTING CONSEQUENCES. Fig.8 Remove the wing nut, securing the air filter cover, and pull off the cover. Remove the wing nut securing the filter element assembly and pull off the element. -
Page 14: Troubleshooting
1. Ignition switch is OFF 2. Turn ON gas 2. Gas turned OFF 3. Renew gas bottle 3. Gas bottle empty 4. Contact your Clarke 4. Faulty gas regulator/ Dealer or Clarke Service. controller 5. Pull more sharply 5. Insufficient starting pull 6. -
Page 15: Specifications
Water Protection ..............IP21 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate... -
Page 16: Spare Parts Diagrams
SPARE PARTS DIAGRAM Gas System Engine... -
Page 17: Spare Parts List
Generator Spare Parts List No. Description Part No. No. Description Part No. Gas Controller CGH350001 Alt. End Cover CGH350020 Gas Regulator CGH350002 Alt. End Housing CGH350021 Hose CGH350003 Alt. Centre Cover CGH350022 Adapter CGH350004 Alt. Stator CGH350023 Hose Connector CGH350005 Alt. - Page 18 ALTERNATOR WIRING DIAGRAM PARTS & SERVICE CONTACTS For Spare Parts and Service,please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com...
