User Guide
EC-BDC1200
Installation
©
30 | Danfoss | March 2025
•
The electric device must be mounted on a flat, heat- and flame-resistant mounting place (for example
on a bracket).
•
It is recommended to install the electric device vertically with connectors pointing left or right. All
other installation directions should be evaluated on a case-by-case basis. See Figure Recommended
mounting position below.
Note that it is not allowed to install the electric device upside down (the top of the device downward)
horizontally.
Recommended mounting position
Location of the mounting points
M10 holes, 3 pcs per side.
