FOREWORD

Dear Customer, we wish you a great deal of enjoyment and every success with your new Leica product.
Please read this manual to familiarize yourself with the full scope of functions your product has to offer.
Please use this product only as described in this manual. Only then can safe and easy operation be guaranteed.
The device uses an invisible laser beam. Please read the chapters "Safety Remarks" and "Important Information" before using the product for the first time. Knowledge of the content will prevent inadvertent damage to the product, possible injuries and other risks.

SCOPE OF DELIVERY

The standard scope of delivery* contains the following:

Binoculars
Carry strap
Eyepiece cover
2x protective lens caps
Carry case
Lens cleaning cloth
Quick Start Guide
Test certificate
3 V lithium cell (type CR2)

REPLACEMENT PARTS / ACCESSORIES

Contact Leica Customer Care or your specialist Leica retailer for details on the latest replacement parts / accessory range: https://en.leica-camera.com/Stores-Dealers/Leica-dealer-locator
*The actual scope of delivery may vary depending on model.

PART DESIGNATIONS

Menu Selection Button
(meter/yard display), (equivalent horizontal range)
Main switch
Switching the device ON/OFF
Strap lugs

Eyecups (rotating)
Use without eye glasses: turn in counter-clockwise direction
Focusing wheel
Adjusting the focus
Eyepiece cap
Diopter setting wheel
1. Scale
Diopter setting wheel for digital display
1. Scale
Center hinge
Battery compartment cover
Use a coin to turn in anti-clockwise direction to open
Lens caps
Laser transmission lens
Lens
Battery compartment
3 V lithium cell (type CR2)

Target mark
Display
(value)

PREPARATION

ATTACHING THE CARRY STRAP

ATTACHING THE CARRY STRAP
The eyepiece caps can be attached to the carry strap. at the same time as the carry strap is attached to the binoculars.

Attach and tighten the carry strap as shown in the illustration

Check the correct attachment of the carry strap by pulling at it with some force. The length of the carry strap must not change.

ATTACHING THE PROTECTIVE LENS CAP

Note

When positioned correctly, the protective lens cap will flip open downwards.

INSERTING/CHANGING THE BATTERY

A cylindrical 3 V lithium cell (type CR2) is required for power supply.
INSERTING/CHANGING THE BATTERY

Turn the lid over the battery compartment in anti-clockwise direction
Use e.g. a small coin.
Remove the lid
Insert the battery with the plus contact first
Attach the lid
Tighten the lid by turning it in clock-wise direction

SETTING THE EYECUPS

The position of the eyecups will depend on whether you wear eyeglasses or not. Contact lens wearers can make the settings just like anyone not wearing any eyeglasses.

FOR USE WITHOUT EYE GLASSES

Rotate the eyecup out half way or fully (Fig. A )

FOR USE WITH EYE GLASSES

Rotate the eyecup fully inward (Fig. B )

DIOPTER SETTINGS

A diopter compensation function for up to ±4 diopter is provided to allow users with diminished vision the use of this product and the fine-tuning of the target mark without eye glasses.
DIOPTER SETTINGS

Return both diopter compensation rings to their zero position.
Look through the binoculars
Aim at a distant object
Adjust the focusing wheel until you can see the target object with optimum sharpness
Press the main switch
- The reticule appears.
Adjust the diopter setting wheel on the right until the target mark appears with optimum focus in the right-hand binocular tube
Close your left eye or cover the left-hand lens
Turn the focusing wheel until you can see the target object with optimum focus in the right-hand binocular tube
Close your right eye or cover the right-hand lens
Adjust the focusing wheel so that you can see the target object with optimum focus in the left-hand binocular tube

SETTING THE INTEROCULAR DISTANCE

SETTING THE INTEROCULAR DISTANCE
Adjust the interocular distance by moving the hinged joint to match your personal requirements. When the interocular distance is set correctly, the right and left fields of view merge into a circular image.

Move the two halves of the binoculars via the central joint until no distracting shadows remain in your view

SETTINGS AND OPERATION

SETTING THE IMAGE SHARPNESS

Look through the binoculars
Aim at the target object
Adjust the focusing wheel until you can see the target object with optimum sharpness

ACTIVATING THE RANGEFINDER

Press the main switch
- The device switches on and the target mark appears.

ACCESSING THE MAIN MENU

Press and hold the menu selection button (≥3 s)
- appears.

NAVIGATING IN THE MAIN MENU

Press the menu selection button repeatedly (<2 s each time) until the desired menu item appears

Menu item Options Description

Yard display

Meter display

Activate EHR

Deactivate EHR

SELECTING SETTINGS

Press the main switch repeatedly (<2 s each time) until the desired menu item appears
- The selected setting is initially lit continuously as confirmation, then the display switches to the next menu item and then disappears if no further settings are made.

MENU OVERVIEW

SETTING THE UNIT OF MEASURE

The Leica Rangemaster CRF 2400-R can be set to the metric () or imperial system ().

Press and hold the menu selection button
- appears.
Press the main switch several times briefly until the desired setting appears

Display in meters

Display in yards
Press the menu selection button briefly

Note

The current setting is always visible in the display: a dot will be shown at the bottom right next to the reticule if metric values are selected.

METERING OPERATION

DISTANCE MEASUREMENT MADE EASY

Press the main switch briefly
Aim the target mark at the object
Press the main switch again
- The target mark disappears briefly and the measured value is displayed.
- You can do another measurement at any time by pressing the main button while the target mark remains lit.

will appear in the following scenarios:

Distance to the object is less than 10 meters//11 yards
Range capability is exceeded
Object is not sufficiently reflective

SCAN MODE (OBJECT TRACKING)

Press the main switch briefly
Aim at the object while target mark is lit
Press and hold main switch for approx. 2.5 seconds
- The device switches to scan mode and will then measure continuously. Scan mode is indicated by a change in the display. A new measured value appears after approx. 0.5 seconds.

METERING RANGE / ACCURACY

Maximum range is achieved in the following scenarios.

Highly reflective target objects
at a visual range of about 10 km (6 mi)

Long ranges can be reliably measured or achieved by holding the rangefinder very steady and/or placing it on a solid surface.

Maximum ranges are:

on highly reflective targets = approx. 1800 m/1969 yds
Trees = approx. 1400 m/1530 yds
Game = approx. 900 m/984 yds

The measuring range is influenced by the following factors:

Range	higher	lower
Color	white	black
Angle to lens	perpendicular	acute
Object size	large	small
Sunlight	low light (cloudy)	high light (midday sun)
Atmospheric conditions	clear	hazy
Object structure	homogeneous (house wall)	inhomogeneous (underbrush, tree)

The following range/accuracy applies in sunlight and with good visibility:

Range (in meters)	Accuracy (1σ) Normal Operation	Accuracy (1σ) Scan mode
<350	±1	±2
350–700	±2	±3
>700	0.5%	0.5%

EQUIVALENT HORIZONTAL RANGE ()
Shots at higher or lower elevation targets are subject to changed ballistic conditions. They require knowledge of the equivalent horizontal range, which is relevant for hunting. Knowledge of the equivalent horizontal range is important, for example when using ballistic reticles. values are indicated by the additional display.

Press and hold the menu selection button
Press the menu selection button 1x briefly
- appears.
Press the main switch several times briefly until the desired setting appears ()
Press the menu selection button briefly

Note

values are provided only between 10 m/11 yd and 1100 m/1203 yd for safety reasons. Beyond that, only the actually measured, linear range is provided.

CARE/CLEANING

Your Leica rangefinder requires no special care.
Coarse dirt particles like sand can be removed with a soft brush or simply blown off.
Do not use excessive force when cleaning a severely soiled lens surface. The coating is abrasion resistant, but not impervious to sand or salt crystals.
Always rinse off any traces of salt water! Dried salt crystals could damage the surfaces.
Fingerprints, etc. on front lenses and eyepiece lenses can be precleaned with a damp cloth and then wiped dry with a clean leather or lint-free cloth.
The rangefinder should be stored in a well-ventilated, dry and cool place to prevent fungal growth (particularly important in humid climates).
Do not use alcohol or chemical cleaning solutions on the optics or housing.

TECHNICAL DATA

Designation	Leica Geovid R 8 x 42	Leica Geovid R 10 x 42
Device type	Binoculars	Binoculars
Type No.	4058	4058
Order No.	40 811	40 812
Scope of delivery	Binoculars, carry strap, eyepiece cover, carry case, lens cleaning cloth, 2x protective lens cap, quick start guide, certificate, 3 V lithium cell (type CR2)	Binoculars, carry strap, eyepiece cover, carry case, lens cleaning cloth, 2x protective lens cap, quick start guide, certificate, 3 V lithium cell (type CR2)
Magnification	8x	10x
Lens diameter	42 mm	42 mm
Exit pupil	5.25 mm	4.2 mm
Eye relief	15 mm	14 mm
Closest focusing distance	Approx. 5.6 m/61 yd	Approx. 5.6 m/61 yd
Prism system	Roof	Roof
Coating	HDC® multi-coating	HDC® multi-coating
Field of view	7.2° (125m/1000m)	6.3° (110m/1000m)
Diopter compensation	±3.5 dpt	±3.5 dpt
Eye relief	Adjustment range: 56 – 74 mm	Adjustment range: 56 – 74 mm
Range	On highly reflective targets max. approx. 1800 m/1969 yd	On highly reflective targets max. approx. 1800 m/1969 yd
Measuring accuracy	±1 m to 350 m, ±2 m to 700 m, ±0.5% beyond 700 m	±1 m to 350 m, ±2 m to 700 m, ±0.5% beyond 700 m
Display/Unit of measure	LED display with 4 digits and ambient light-controlled brightness	LED display with 4 digits and ambient light-controlled brightness
Max. measurement time	Approx. 0.3 s	Approx. 0.3 s
Protection type	Waterproof to a depth of 5 m (5.5 yd)	Waterproof to a depth of 5 m (5.5 yd)
Operating temperature	Electrical: -20 to 55°C Mechanical: -25 to 55°C	Electrical: -20 to 55°C Mechanical: -25 to 55°C
Storage temperature	-40 to +85°C	-40 to +85°C
Material	Aluminum die-cast with rubber reinforcement	Aluminum die-cast with rubber reinforcement
Dimensions (WxHxD)	125 x 173 x 70 mm	125 x 168 x 70 mm
Weight (without battery)	960 g	955 g

Designation	Leica Geovid R 8 x 56	Leica Geovid R 15 x 56
Device type	Binoculars	Binoculars
Type No.	4058	4058
Order No.	40 813	40 814
Scope of delivery	Binoculars, carry strap, eyepiece cover, carry case, lens cleaning cloth, 2x protective lens cap, quick start guide, certificate, 3 V lithium cell (type CR2)	Binoculars, carry strap, eyepiece cover, carry case, lens cleaning cloth, 2x protective lens cap, quick start guide, certificate, 3 V lithium cell (type CR2)
Magnification	8x	15x
Lens diameter	56 mm	56 mm
Exit pupil	7 mm	3.7 mm
Eye relief	18 mm	15 mm
Closest focusing distance	Approx. 5.6 m/61 yd	Approx. 5.6 m/61 yd
Prism system	Roof	Roof
Coating	HDC ® multi-coating	HDC ® multi-coating
Field of view	6,8° (118m/1000m)	4,3° (75m/1000m)
Diopter compensation	±3.5 dpt	±3.5 dpt
Eye relief	Adjustment range: 58 – 74 mm	Adjustment range: 58 – 74 mm
Range	On highly reflective targets max. approx. 1800 m/1969 yd	On highly reflective targets max. approx. 1800 m/1969 yd
Measuring accuracy	±1 m to 350 m, ±2 m to 700 m, ±0.5% beyond 700 m	±1 m to 350 m, ±2 m to 700 m, ±0.5% beyond 700 m
Display/Unit of measure	LED display with 4 digits and ambient light-controlled brightness	LED display with 4 digits and ambient light-controlled brightness
Max. measurement time	Approx. 0.3 s	Approx. 0.3 s
Protection type	Waterproof to a depth of 5 m (5.5 yd)	Waterproof to a depth of 5 m (5.5 yd)
Operating temperature	Electrical: -20 to 55°C Mechanical: -25 to 55°C	Electrical: -20 to 55°C Mechanical: -25 to 55°C
Storage temperature	-40 to +85°C	-40 to +85°C
Material	Aluminum die-cast with rubber reinforcement	Aluminum die-cast with rubber reinforcement
Dimensions (WxHxD)	135 x 182 x 70 mm	134 x 210 x 70 mm
Weight (without battery)	1090 g	1260 g)

Subject to changes in design, production, and scope of delivery.

LEICA CUSTOMER CARE

Please contact the Customer Care department of Leica Camera AG for the maintenance of your Leica equipment and for help and advice regarding Leica products and how to order them. You can also contact the Customer Care department or the repair service provided by your regional Leica subsidiary for repairs or warranty claims.
Leica Camera AG Leica Customer Care
Am Leitz-Park 5
35578 Wetzlar
Germany
Phone: +49 (0)6441 2080-189
Fax: +49 (0)6441 2080-339
Email: customer.care@leica-camera.com www.leica-camera.com

SAFETY REMARKS

Non-compliance with the following points may result in serious injury or death.

LASER

The use of any operations not described in this manual or any alterations on the device may result in hazardous radiation exposure.
The laser device is active and emitting an invisible laser beam as long as the display in the eyepiece is active. Never point the laser focusing optics at a person or animal.
Do not depress any of the two buttons while aiming at a human eye or while looking into the optics from the lens side.
Never aim the laser at an eye.
Do not aim the laser at people or animals.

GENERAL INFORMATION

Avoid looking directly at bright light sources with your Leica Geovid to prevent eye injury.

Non-compliance with the following points may result in personal injury or damage to the device.

LASER

Avoid touching any of the two buttons while the distance measurement function is not in use to prevent an accidental activation of the laser beam.
Do not attempt to disassemble, reassemble or repair the Leica Geovid yourself. Emitting laser radiation may pose a serious health risk. The manufacturer warranty is void, once a device was disassembled, reassembled or repaired.
Remove the battery immediately and stop using the device if the device housing is damaged or if it emits a strange sound after being dropped or behaves unexpectedly for any other reason.

GENERAL INFORMATION

Keep the device out of the reach of small children.
Do not use the device while walking. You might trip and fall.
Do not combine the operation of your Leica Geovid with other optical components, e.g. lenses or binoculars. Using the Leica Geovid in conjunction with another optical device increases the danger of damaging your eyes.
Do not attempt to disassemble or modify the device; exposing the internal electronics may cause damage, injury or electric shock.

BATTERY

Only the battery type stated and described in this manual must be used. Any improper use of the batteries or the use of unapproved battery types may result in an explosion!
Do not expose the battery to sunlight, heat, humidity or moisture for prolonged periods of time. It must not be placed in a microwave oven or a high-pressure container as this would pose a fire or explosion hazard!
Never dispose of batteries in fire and never attempt to heat, recharge, dismantle or break open a battery.
Batteries must always be stored out of the reach of children. Do not leave batteries lying around, as they could be swallowed by children or pets.

CARRY STRAP

The carry strap is usually made of very robust material. You should therefore keep it out of the reach of children. A carry strap is not a toy and poses a strangulation risk.
Use the carry strap only for its intended purpose on a camera or on binoculars. Any other use poses the risk of injury and may possibly result in damage to the carry strap and is therefore not permitted.
Carry straps should also not be used for cameras/binoculars during sports activities that pose a risk of entanglement (e.g. when mountain climbing and similar outdoor activities).

IMPORTANT INFORMATION

GENERAL INFORMATION

Do not attempt to take the device apart yourself. Repairs must only be carried out in authorized workshops.
Remove the battery from the housing if you will not be using the product for an extended period of time.
Low temperatures impair battery performance. Carry the device close to the body in cold conditions and use a fresh battery.
Make sure to store the batteries in a cool, dry place.
Depleted batteries must never be disposed of in household waste as they contain toxic materials that are harmful to the environment. Battery collection points are provided at most large retail outlets; alternatively, you can dispose of old batteries at a local special waste collection point to ensure correct recycling.
Do not touch the glass surfaces with your fingers, especially if you have previously applied hand cream, insect repellent, etc. These substances may contain chemicals that damage or destroy the coatings on the glass surfaces.

EYEPIECE

An eyepiece can have the effect of a magnifying glass when exposed to direct frontal sunlight. The device must therefore be protected against extended exposure to direct sunlight. Storing the device in the shade or ideally in its case will help prevent damage to the device interior.

MEASURING VALUES

The influence of all ballistically relevant influencing factors is greatly increased at longer ranges and considerable variations may occur. The ballistic values displayed should therefore only be viewed as a guideline.
Regardless of whether this information is used, you are responsible for assessing the relevant hunting situation.
Leica Camera AG does not accept liability for the accuracy of values transmitted from third-party devices.
Powerful electric fields, e.g. emanating from radar systems, may cause errors and/or faulty values.
The geomagnetic field can similarly cause value deviations.

Definition of the various categories of information found in this manual
Note
