Summary of Contents for Kronoterm ADAPT
- Page 1 USAGE OPERATING INSTRUCTIONS Technician, user ADAPT, VERSI, ETERA, WPLV KT – 2A Controller...
- Page 2 ADAPT, VERSI, ETERA and WPLV systems DESCRIPTION OF DOCUMENT AND APPROACH This document is a part of the KRONOTERM instruction system, which follows our products’ lifecycle from design phase to service support. The installation manual is the basis for a professional and expert approach to the installation of the KRONOTERM heat pump system.
-
Page 3: Table Of Contents
Operating instructions ADAPT, VERSI, ETERA and WPLV systems T A B L E O F C O N T E N T S IMPORTANT INFORMATION ......... 4 MENUS AND PARAMETERS IN OPERATING MODE ................17 SYMBOLS ..................4 SHORTCUT MENU ..............18 GENERAL WARNINGS ............ -
Page 4: Important Information
Operating instructions ADAPT, VERSI, ETERA and WPLV systems IMPORTANT INFORMATION NOTE These instructions were written to inform you of all Read these instructions thoroughly before using. important steps to take between commissioning and further use. They describe how to set and use the Any processing or replacement of the appliance’s... -
Page 5: Home Screen And Navigation
Operating instructions ADAPT, VERSI, ETERA and WPLV systems HOME SCREEN AND NAVIGATION WARNING The KT–2A Controller has 3 operational modes: This appliance is not to be played with. The appliance may only be used by people who have learned about its safe operation and who Thermostat. -
Page 6: Graphic Interface And Controller
Operating instructions ADAPT, VERSI, ETERA and WPLV systems GRAPHIC INTERFACE AND 3.2 QUICK VIEW CONTROLLER Access the Quick View by pressing on the home screen. Press a second time to toggle between the system overview and the weather forecast. BACK button for: •... -
Page 7: Thermostat
Operating instructions ADAPT, VERSI, ETERA and WPLV systems THERMOSTAT Alarm: Warning – verify the meaning of the warning Home screen in thermostat mode: code and take appropriate measures, it is not necessary to call a service technician. Error – verify the meaning of the error code and call a service technician if necessary. -
Page 8: Setting Parameters In Thermostat Mode
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 4.3 SETTING PARAMETERS IN SETTING BRIGHTNESS THERMOSTAT MODE Table 1 Settings for the heating loop’s operational mode: Brightness 15%. ON – the heating loop is working con- stantly in Normal mode. AUTO – the heating loop is working Brightness 30%. - Page 9 Operating instructions ADAPT, VERSI, ETERA and WPLV systems 4.4.1 SETTING THE DHW TEMPERATURE 4.4.2 TURNING ON THE ONE–TIME QUICK HEATING OF DHW Press to get to the parame- ter menu. Press to get to the parame- ter menu. Press to browse DHW parameters.
-
Page 10: Controller
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 4.4.3 SETTING THE HEATING LOOP OPERATION CONTROLLER MODE Home screen of the KT–2A controller in controller mode. Press to get to the parameter menu. Press to find the heating loop parameter. Press to begin setting parameters. -
Page 11: Status Line In Controller Mode
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.1 STATUS LINE IN CONTROLLER Status of additional heater: MODE Additional heater 2 is active (external source). Additional heater 1 is active (internal electric heater). Both additional heaters 1 and 2 are active. -
Page 12: Turning On/Off The Heat Pump And Heating System
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.2 TURNING ON/OFF THE HEAT PUMP 5.3 TURNING HEATING AND COOLING AND HEATING SYSTEM ON/OFF Press to get to the main Press to get to the main menu menu Choose the menu “shortcut”... -
Page 13: Setting The Desired Ambient
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.4 SETTING THE DESIRED AMBIENT 5.5 SETTING THE DHW TEMPERATURE TEMPERATURE Press to get to the main menu. Press to get to the main menu Press to search for the DHW settings. -
Page 14: Turning On The Quick Heating Of Dhw
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.6 TURNING ON THE QUICK HEATING OF DHW Confirm the settings by Press to get to the main pressing menu. Cancel the parameter value by pressing To return to the home screen press 2 times. -
Page 15: Manual Activation Of Anti-Legionella Program
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.7 MANUAL ACTIVATION OF ANTI– 5.8 SETTING THE HEATING LOOP LEGIONELLA PROGRAM OPERATING MODE Press to get to the main Press to get to the main menu. menu. Choose the offered shortcut... -
Page 16: Parallel Activation Of The Additional Heater 1
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 5.9 PARALLEL ACTIVATION OF THE 5.10 ACTIVATION OF BACKUP HEATING ADDITIONAL HEATER 1 MODE Press to get to the main Press to get to the main menu. menu Choose the offered shortcut... -
Page 17: Menus And Parameters In Operating Mode
Operating instructions ADAPT, VERSI, ETERA and WPLV systems MENUS AND PARAMETERS IN OPERATING MODE NOTE You can set various temperatures and operating modes for the heating loop, pool, buffer tank, and DHW tank. NORMAL The Normal Regulator mode keeps your set temperature. -
Page 18: Shortcut Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.1 SHORTCUT MENU Shortcut Menu Parameter name Parameter value range Note Turn on Holiday ON – Turn on ON – set the number of vacation days mode OFF – Turn off 0 – 999. -
Page 19: System Overview
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.2 SYSTEM OVERVIEW System overview Menu Parameter name Parameter value range Note Supply pipe temperature Return pipe temperature Pipe Show the temperature, water and source pressure. temperatures Heating system pressure Pressure of the source... -
Page 20: Appliance Alarms
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.3 APPLIANCE ALARMS Appliance alarms Menu Parameter name Parameter value range Note There is a disturbance in operation. The heat pump Error 2114–b3 to 2335–b8 and heating system do not work. There was a light operational disturbance. The hea- Warning 2115–b1 to 2341–b4... -
Page 21: Buffer Tank Heating Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.4 BUFFER TANK HEATING MENU Buffer tank Menu Parameter name Parameter value range Note Buffer tank ON – Turn on operational AUTO – Working schedule mode OFF – Turn off Buffer tank ECO –10 °C/ 0 °C... -
Page 22: Heating Loops With The Kt-1 Or Kt-2A Thermostats Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.5 HEATING LOOPS WITH THE KT–1 OR KT–2A THERMOSTATS MENU Note During the commisioning protocol set one KT–1 or KT–2A for each heating loop. Heating loop Menu Parameter name Parameter value range... -
Page 23: Menu Heating Loops Without The Kt-1 Or Kt-2A Thermostats Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.6 MENU HEATING LOOPS WITHOUT THE KT–1 OR KT–2A THERMOSTATS MENU Heating loop Menu Parameter name Parameter value range Note Heating loop ON – Turn on operational AUTO – Working schedule OFF – Turn off... -
Page 24: Menu Heating The Pool Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.7 MENU HEATING THE POOL MENU Pool Menu Parameter name Parameter value range Note Pool ON – Turn on heating loop AUTO – Working schedule operational OFF – Turn off mode Setting the pool loop +10 °C to 50 °C... -
Page 25: Seeing The Heating Loop Schedule
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.8 SEEING THE HEATING LOOP SCHEDULE The schedule allows up to 6 room or water temperature transitions in one day. Menu Weekly overview Choose settings Settings Operational mode Edit Setting interval Normal mode... -
Page 26: Menu Circulating Dhw
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.9.1 SETTING ANTI–LEGIONELLA HEATING Setting and activating a function requires 3 parameters: Menu Parameter name Parameter value range Note Temperature of Water at a temperature of 75 °C eliminates Legionella anti–Legionella 60–75 °C in 10 minutes, while water at 60 °C eliminates it in 25... -
Page 27: Operational Mode Menu
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.11 OPERATIONAL MODE MENU Operational mode Menu Parameter name Parameter value range Note Setting the schedule NOTE Boost mode: the appliance is more powerful, less efficient, and louder. Optimal mode: the appliance is optimized in terms of heating capacity, noise, and efficiency. -
Page 28: Menu Settings
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.13 MENU SETTINGS Setting Menu Parameter name Parameter value range Note Temperature General rise or fall of parameter NORMAL for heating –4 °C/+4 °C loop and buffer tank. offset Heating loop operational AUTO General heating loop operating mode. -
Page 29: Menu Setting The Regulator
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.14 MENU SETTING THE REGULATOR Regulator settings Menu Parameter name Parameter value range Note Setting the 0 − 24 h Setting the hour. hour Setting the 1 − 31 days Setting the date. - Page 30 Operating instructions ADAPT, VERSI, ETERA and WPLV systems Setting IP Setting Mask Setting GATEWAY Setting DNS1 Setting DNS2 6.14.2 SYSTEM INFORMATION Informacije o sitemu Menu Parameter name Parameter value range Note KT–2A regulator information information WEB module information Operating We distinguish between operating hours and counters.
- Page 31 Operating instructions ADAPT, VERSI, ETERA and WPLV systems 6.14.2.1. OPERATIONAL HOURS Depending on your commissioning parameters, your system records various operational hours and number of star- tups from commissioning of the system. The counter “Number of defrosting” resets every 24 hours.
-
Page 32: Heating Curve
Operating instructions ADAPT, VERSI, ETERA and WPLV systems HEATING CURVE The KSM regulator regulates the heating water temperature (buffer tank, heating loop) based on the current outdoor air temperature. In case you also install a KT–1 or KT–2A also the room temperature is also taken in to the calculation. -
Page 33: Setting The Schedule
8.2 SETTING THE SCHEDULE NOTE We recommend that you set your schedules online at cloud.KRONOTERM.com or with the mobile app. Read the instructions on using our cloud interface. The schedule allows for up to 6 temperature transitions in a single day, every day of the week. - Page 34 Operating instructions ADAPT, VERSI, ETERA and WPLV systems Here’s an example of setting schedules: Press to get to the main menu. Press to choose the Edit parameter. Follow the instructions bellow to copy a schedule from se- lected day to another day...
- Page 35 Operating instructions ADAPT, VERSI, ETERA and WPLV systems *Copying schedules Press to choose the copy parameter. Confirm the settings by pressing Press to choose to which day you want to copy preselected schedule. Confirm the settings by pressing Press izberite choose paste.
-
Page 36: Screed-Drying Program
The single-day activation of the program does not decisions based on this information. have a function. Kronoterm d.o.o. is also not liable for inability of In the heating mode, the water temperature in use, disruptions or malfunctions of the web service the system drops to the temperature of the anti- Cloud.KRONOTERM.com. -
Page 37: Errors, Warnings And Notifications
Operating instructions ADAPT, VERSI, ETERA and WPLV systems 14 ERRORS, WARNINGS AND 14.1 DISPLAYS NOTIFICATIONS All faults, warnings, and notifications are shown as a code comprised of a 4–digit number and a 2–digit In the alarm menu you will see a list of faults, war- number/letter combo. - Page 38 Operating instructions ADAPT, VERSI, ETERA and WPLV systems 14.2.3 ERROR LIST 2339-b4 Temperature sensor fault –3rd loop (T5) 2339-b5 Temperature sensor fault – 4th loop (T6) 2339-b6 Temperature sensor fault – pool (T7) 2339-b7 Temperature sensor fault – solar/biomass (T8)
- Page 39 Operating instructions ADAPT, VERSI, ETERA and WPLV systems 17-19-45-6702-07...
- Page 40 Kronoterm d.o.o. Trnava 5e, 3303 Gomilsko, SLO T +386 3 703 16 20 www.kronoterm.com info@kronoterm.com...
