Kongsberg ME70 Instruction Manual

Kongsberg ME70 Instruction Manual

Scientific multibeam echo sounder with bathymetry
Hide thumbs Also See for ME70:
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction manual
ME70 Bathymetric Option
Scientific Multibeam Echo sounder with bathymetry
kongsberg.com/me70bo
110-0080487/A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kongsberg ME70

Summary of Contents for Kongsberg ME70

  • Page 1 Instruction manual ME70 Bathymetric Option Scientific Multibeam Echo sounder with bathymetry kongsberg.com/me70bo 110-0080487/A...
  • Page 3 PUBLIC Kongsberg ME70 Bathymetric Option Multibeam scientific echo sounder Instruction Manual Release 2.0.0 110-0080487/A June 2024 © Kongsberg Discovery AS...
  • Page 4 The information contained in this document remains the sole property of Kongsberg Discovery AS. No part of this document may be copied or reproduced in any form or by any means, and the information contained within it is not to be communicated to a third party, without the prior written consent of Kongsberg Discovery AS. Warning The equipment to which this manual applies must only be used for the purpose for which it was designed.

  • Page 5: Table Of Contents

    Instruction Manual Table of contents ABOUT THIS MANUAL ..............7 KONGSBERG ME70 BATHYMETRIC OPTION........9 Important..........................10 System description ........................ 12 About the Bathymetric Option....................14 System diagram........................15 System units .......................... 16 Display – description....................16 Hydrographic Work Station – description..............17 ME70BO Processing Unit –...
  • Page 6 Operating procedures for bathymetric system ..............67 Starting the bathymetric application................67 Changing the bathymetric mode.................. 67 Operating the ME70BO in ME70 mode..............68 About the menus and menu buttons..................69 Bathymetric modes...................... 69 Parameter control for bathymetric operation............... 69 Calibration for the bathymetric application..............
  • Page 7 Display – environmental requirements................ 98 MC330 Hydrographic Work Station – environmental requirements ......98 ME70BO Processing Unit – environmental requirements .......... 99 IP addresses in the ME70 Bathymetric Option system............100 Compass safe distance ......................101 Display – compass safe distance ................101 Hydrographic Work Station –...
  • Page 8 Kongsberg ME70 Bathymetric Option 110-0080487/A...

  • Page 9: About This Manual

    About this manual About this manual The purpose of this publication is to provide an overview of the ME70 Bathymetric Option system functionality. This includes descriptions, and installation, operation and maintenance procedures and parameter explanations required to allow for safe and efficient use of the ME70 Bathymetric Option system.
  • Page 10 Kongsberg ME70 Bathymetric Option Instruction Manual Registered trademarks Observe the registered trademarks that apply. ® Windows is a registered trademark of Microsoft Corporation in the United States and other countries. We want your feedback We always want to improve our products. We also want our end-user documentation to be comprehensive and relevant.

  • Page 11: Kongsberg Me70 Bathymetric Option

    Kongsberg ME70 Bathymetric Option Kongsberg ME70 Bathymetric Option Topics Important, page 10 System description, page 12 About the Bathymetric Option, page 14 System diagram, page 15 System units, page 16 Scope of supply, page 19 Support information, page 26 110-0080487/A...

  • Page 12: Important

    The transducer can be damaged if it transmits in the open air. When the ME70 Bathymetric Option system is not used When you do not use the ME70 Bathymetric Option system, turn it off. If you are using a drop keel, make sure to retract it.
  • Page 13 Kongsberg ME70 Bathymetric Option Note If you turn off the ME70 Bathymetric Option system by means of the on/off switch on the Processing Unit you can damage the software and the interface settings used to communicate with external devices. Rules for transducer handling A transducer must always be handled as a delicate instrument.

  • Page 14: System Description

    The bathymetric units (Hydrographic Work Station and ME70BO Processing Unit) provided with the ME70 allows you to use the ME70 not only as a scientific multibeam echo sounder for fishery research applications, but also as a multibeam echo sounder for seabed...
  • Page 15 Kongsberg ME70 Bathymetric Option mapping. The Seafloor Information System (SIS) software is applied as user interface on the Hydrographic Work Station. 110-0080487/A...

  • Page 16: About The Bathymetric Option

    By using the remote control features of the ME70, the SIS application is allowed to control the entire operation. From an operating point of view, the user interface provided by the ME70 with the Bathymetric application is identical to the interface used by the hydrographic multibeam echo sounders provided by Kongsberg Discovery.

  • Page 17: System Diagram

    Kongsberg ME70 Bathymetric Option System diagram The system diagram identifies the main components of a basic ME70 Bathymetric Option system. Only the main connections between the units are shown. Detailed interface capabilities and power cables are not shown. Display (The second display is optional.)

  • Page 18: System Units

    The ME70 Bathymetric Option system supports the use of multiple displays, with a maximum of three. You may find it useful to have more than one display connected to the ME70 Bathymetric Option system. The number of displays must be chosen to fit the preferences of the crew.

  • Page 19: Hydrographic Work Station - Description

    One high capacity Ethernet cable connects the Hydrographic Work Station to the ME70BO Processing Unit. Note The operating system has been modified to make the computer work with the ME70 Bathymetric Option system. These modifications include removal of all safety features provided by Microsoft ®...
  • Page 20 Processing Unit is designed for mounting in a standard 19'' rack. The ME70BO Processing Unit is usually installed in the ME70 transceiver cabinet. Data is received from the ME70 Processing Unit, and then processed to create seabed mapping information. • One high capacity Ethernet cable is used to connect the ME70BO Processing Unit to the ME70 Transceiver Subracks.

  • Page 21: Scope Of Supply

    Additional required items, page 21 Basic items provided with a standard delivery To assemble a complete ME70 Bathymetric Option system you need all the system units. The main units you need are provided with the standard delivery. Additional items are required for operation.
  • Page 22 Kongsberg ME70 Bathymetric Option Instruction Manual Operational software Operational software is provided on a suitable media. End-user documentation End-user documentation is provided on paper and/or digital formats. All documentation related to operation and installation can be downloaded from our website.

  • Page 23: Additional Required Items

    These items must be added to the ME70 Bathymetric Option system for full operational functionality. The additional items can be provided by Kongsberg Discovery. You can order them with the other basic ME70 Bathymetric Option items. You can also purchase these items from your dealer, agent or local supplier.
  • Page 24 : The output AC voltage must be a sine wave. Output form Navigation system input The ME70 Bathymetric Option system requires input from the ship navigation system to determine the vessel's current geographical and angular position. The navigation system input is used for georeferencing and compensation of vessel movements.
  • Page 25 Kongsberg ME70 Bathymetric Option NMEA position datagram This datagram admits input reception both via network or serial lines. The typical rate is 1 Hz. NMEA time datagram This datagram admits input reception both via network or serial lines. The typical rate is 1 Hz.
  • Page 26 The ME70BO Processing Unit performs signal processing and function control. It is connected to the bottom Ethernet switch in the ME70 Transceiver Unit in order to retrieve beam data from the ME70 Operator Station, and it is connected to the Hydrographic Work Station (HWS).
  • Page 27 You may find it useful to have more than one display connected to the ME70 Bathymetric Option system. The number of displays must be chosen to fit the preferences of the crew. With more than one display connected, use the operating system functionality to control the presentations.

  • Page 28: Support Information

    Kongsberg ME70 Bathymetric Option Instruction Manual Support information If you need technical support for your ME70 Bathymetric Option, you must contact your local dealer, or one of our support offices. A list of all our offices and dealers is available on our website.

  • Page 29: Installation

    Installation Installation Topics Installation requirements, page 28 Installation summary, page 30 About installation drawings, page 31 Tools, equipment and consumables required for installation, page 32 Personnel qualifications, page 32 Installing the display, page 33 Installing the HWS – MC330 – Rack model, page 34 Installing the HWS - MC330 - Desktop model, page 36 Installing the ME70BO Processing Unit, page 37 Installing the network patch box, page 39...

  • Page 30: Installation Requirements

    The Uninterruptible Power Supply (UPS) must have the capacity to independently maintain power to the ME70 Bathymetric Option system for a minimum of 10 minutes. This allows you to turn off the ME70 Bathymetric Option system in a controlled manner in the event of a power failure.
  • Page 31 Installation trays. Note that the cables must not be installed in the vicinity of high-power supplies and cables, antenna cables or other possible sources of interference. All permanently installed cables associated with the system must be supported and protected along their entire lengths using conduits and/or cable trays. All transducer cables should be run in steel conduits.

  • Page 32: Installation Summary

    Kongsberg ME70 Bathymetric Option Instruction Manual Installation summary Installation of the ME70 Bathymetric Option system is a demanding task that requires careful preparations, a number of specific procedures, wiring and required system settings. Context Note In order to obtain maximum safety and optimal performance, it is very important that the installation procedures in this manual are complied to.

  • Page 33: About Installation Drawings

    Cable layout and interconnections, page 42 Turn on the ME70 Bathymetric Option system for the first time, and set it to work. Note In order to turn on the ME70 Bathymetric Option system in a safe and correct manner,...

  • Page 34: Tools, Equipment And Consumables Required For Installation

    Tools, equipment and consumables required for installation To install the ME70 Bathymetric Option system, all necessary tools and equipment for mechanical work, cabinet installation and electrical wiring must be available. It is not practical to provide a detailed list of all necessary tools and equipment. You must be equipped with a standard set of tools.

  • Page 35: Installing The Display

    Installation Installing the display A display is a required part of the ME70 Bathymetric Option system. For best readability, the display must be protected from glare and have the correct height and angle. The display is normally not included with the ME70 Bathymetric Option system delivery. A generic procedure is provided.

  • Page 36: Installing The Hws - Mc330 - Rack Model

    Kongsberg ME70 Bathymetric Option Instruction Manual Connect the cables. Note When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. Installing the HWS – MC330 – Rack model Follow this procedure to install the rack model of the computer.
  • Page 37 Installation Power cableThere is a converter which makes it possible to use the same cable as in previous versions of the HWS. Network cable from the Processing Unit Display cables Moving arm Ethernet switch for network connection Screw that holds removable SSDsRemove the front cover and open the drawer, then gently remove the SSD.

  • Page 38: Installing The Hws - Mc330 - Desktop Model

    Kongsberg ME70 Bathymetric Option Instruction Manual Installing the HWS - MC330 - Desktop model The MC330 computer is available as a rack model and a desktop model. Follow this procedure to install the desktop model of the computer. Prerequisites A suitable location for the computer must be defined prior to installation.

  • Page 39: Installing The Me70Bo Processing Unit

    ME70BO Processing Unit is usually installed in the ME70 transceiver cabinet. Prerequisites Unless specified in a contract, the 19" rack is not included in the ME70 Bathymetric Option delivery. The 19" rack must be provided and installed by the ship owner or the installation shipyard.
  • Page 40 Kongsberg ME70 Bathymetric Option Instruction Manual Context A suitable location for the ME70BO Processing Unit must be defined prior to installation. The unit can in principle be mounted anywhere on board the ship provided that the location is dry and ventilated.

  • Page 41: Installing The Network Patch Box

    Access to the rear of the ME70 transceiver cabinet via the two rear doors must be provided. You must be equipped with a standard set of tools.

  • Page 42: Connecting The Tx Enable Cable To The Lpt32 Transceiver Boards

    Kongsberg ME70 Bathymetric Option Instruction Manual Open the network patch box and `terminate the two Ethernet cables according the manufacturer's instructions. Connec the two supplied patch cables from the two RJ45 sockets and to the rear of the ME70BO Processing Unit.
  • Page 43 Installation Remove the two right-most panels on the lower subrack. Install the TX Enable cable mounting plate. Connect the two cables according to the cable plan. Use tie wraps to secure the cables. 110-0080487/A...

  • Page 44: Cable Layout And Interconnections

    Kongsberg ME70 Bathymetric Option Instruction Manual Cable layout and interconnections Topics Read this first, page 43 List of cables, page 44 Cable plans, page 46 Dimensional surveying and alignment, page 54 Setting to work, page 62 110-0080487/A...

  • Page 45: Read This First

    Commercial cables Commercial cables may be provided by Kongsberg Discovery as a part of the delivery. The cables may also be included with third party items that are used with the ME70 Bathymetric Option system. All electric installations and corresponding wiring must be in accordance with the vessel's national registry and corresponding maritime authority and/or classification society.

  • Page 46: List Of Cables

    Cat 5e STP (Shielded Twis- Processing Unit. ted Pair) The cable is connected to the patch box in the rear of the ME70 transceiver cabinet. The patch box is included in the delivery. Ethernet cable From Processing Unit to Ship...
  • Page 47 Pair) Comments The ME70 Bathymetric Option system is often a part of a project delivery. For such deliveries, specific project cable drawings are established to show all the main cables, and how the various products are connected. In such project cable drawings, the ME70...

  • Page 48: Cable Plans

    The Bathymetric system cables include those necessary to connect the units to mains power, and the control cables between them. Ethernet communication is used to connect the Hydrographic Processing Unit to the ME70 Bathymetric Option Processing Unit. Interface cables to external devices are also shown.
  • Page 49 Installing the ME70 Bathymetric Option cables Prerequisites for cable installation Correct wiring is crucial for the operational performance of the ME70 Bathymetric Option system. Electrical connections can only be made by skilled personnel (ship electricians, technicians or engineers). The installation shipyard must prepare detailed drawings of the electrical system, and identify each cable.
  • Page 50 Kongsberg ME70 Bathymetric Option Instruction Manual Installing the cables for the bathymetric system The ME70 Bathymetric Option system includes the cables used to connect the complete system. The complete list of cables includes the cables listed and the existing standard ME70 system cables.
  • Page 51 Connect the Ethernet cable from the ME70BO Processing Unit to the Processing Unit . via the patch box installed in the ME70 transceiver cabinet (C35). Connect the internal patch cable to the network switch on the rear of the ME70BO Processing Unit.
  • Page 52 Kongsberg ME70 Bathymetric Option Instruction Manual If applicable, connect the required interface serial cables from the ship navigation system to the ME70 Processing Unit. (C37) The C37 serial interface cables are connected to the ME70BO Processing Unit using RJ45 plugs as decribed in the table.
  • Page 53 ME70BO Processing Unit. Connect the TX Enable cable. This cable is an internal cable in the ME70 transceiver cabinet. There are two cables supplied depending on the type of the transceiver boards that it is used. A label on the front of the transceiver boards identifies the type of board.
  • Page 54 Kongsberg ME70 Bathymetric Option Instruction Manual Connect the RJ45 plug in the Port 4 socket on the rear side of the ME70BO Processing Unit. For TRX32 boards, use the cable with part number 110-0067903. Connect the RJ45 plug in the Port 4 socket on the rear side of the ME70BO Processing Unit.
  • Page 55 Installation Further requirements We recommend that you use tie wraps to secure all cables installed. 110-0080487/A...

  • Page 56: Dimensional Surveying And Alignment

    Kongsberg ME70 Bathymetric Option Instruction Manual Dimensional surveying and alignment Topics Quality assurance of bathymetric data, page 55 Surveying the transducer and the navigation sensors, page 57 Dimensional survey accuracy requirements, page 58 Vessel coordinate system, page 59 110-0080487/A...
  • Page 57 Modest accuracy requirements apply when your ME70 Bathymetric Option system is only used to investigate objects in the water column. With the bathymetric system installed and operational, all alignments and measurements must be done to the highest possible accuracy.
  • Page 58 A new calibration may also be required if the ME70 Bathymetric Option software is updated. Refer to the software release note.
  • Page 59 With ME70 Bathymetric Option, two calibration surveys are required. • Calibration for seabed mapping • Calibration for target strength measurements The information provided by the calibration is entered into the ME70 Bathymetric Option software as operational parameters. This is done automatically. Note Calibration must be taken seriously.
  • Page 60 A new calibration may also be required if the ME70 Bathymetric Option software is updated. Refer to the software release note.
  • Page 61 Installation Note The given accuracies are maximum values. If easily achievable, better accuracies should be obtained. Transducer • : ±0.05 m Position (x,y) • : ±0.02 m Position (z) • : ±0.05° Pitch • : ±0.020° Roll • : ±0.1° Heading Motion Reference Unit (MRU) •...
  • Page 62 Kongsberg ME70 Bathymetric Option Instruction Manual motion sensor is located close to the vessel’s centre of gravity. Both of these are physically positioned far away from the transducer, which may be located closer to the bow. Very often, the information from one sensor depends on data from an other. It is then important that the relevant measurements are compensated for these relative distances.
  • Page 63 Installation • Vessel’s centre of gravity • The physical location of the motion sensor Vessel coordinate system alternative origins If necessary, other origin locations may be defined for specific products or purposes. One example is the Navigation Reference Point that is frequently used. Whenever a vessel is surveyed to establish accurate offset information, the surveyor may also establish an alternative origin location.

  • Page 64: Setting To Work

    Kongsberg ME70 Bathymetric Option Instruction Manual Setting to work Topics Setting to work summary, page 63 Connecting the Seafloor Information System (SIS) program to the ME70 Bathymetric Option system, page 64 Installation remarks, page 65 110-0080487/A...
  • Page 65 Setting to work summary Once all the hardware units have been installed, and all the cables have been connected, the ME70 Bathymetric Option system can be turned on for the first time and set to work. Prerequisites Before you can set the ME70 Bathymetric Option system to work, the following prerequisites must be met: •...
  • Page 66 SIS program must be able to communicate with the ME70 Bathymetric Option system. Prerequisites The ME70BO and the ME70 systems are turned on, in inactive mode and ready to start. Procedure In the Seafloor Information System (SIS) software application: Observe the control bar.
  • Page 67 Installation Installation remarks Use this page to write down comments and remarks related to the ME70 Bathymetric Option installation. When the installation has been fully completed, and all functional tests have been made to full satisfaction, representatives from each party must sign.

  • Page 68: Operation

    Kongsberg ME70 Bathymetric Option Instruction Manual Operation Topics Operating procedures for bathymetric system, page 67 About the menus and menu buttons, page 69 110-0080487/A...

  • Page 69: Operating Procedures For Bathymetric System

    Changing the bathymetric mode There are several ME70BO modes available. Prerequisites The ME70BO system is turned on and communicates with the ME70 system. Use the Seafloor Information System (SIS) program to choose your preferred mode. Procedure In the Seafloor Information System (SIS) software application: In the...

  • Page 70: Operating The Me70Bo In Me70 Mode

    This may take up to 30 seconds. Operating the ME70BO in ME70 mode When the ME70 is operated in standard mode with the ME70 beam modes, the bathymetric option can be set to "listening mode". This allows the system to calculate bottom detections from the ME70 data output.

  • Page 71: About The Menus And Menu Buttons

    Geographical About the menus and menu buttons The ME70 Bathymetric Option provides you with the functionality of a multibeam echo sounder for seabed mapping. This functionality is controlled by means of the Seafloor Information System (SIS) software. For detailed information about each function and dialog box, refer to the multi beam echo sounder Reference Manual.

  • Page 72: Calibration For The Bathymetric Application

    • Message system • Raw data logging Calibration for the bathymetric application IN order to achieve correct data, the ME70 Multibeam scientific echo sounder system must be calibrated. Roll/Pitch calibration The ME70 Multibeam scientific echo sounder system must be roll and pitch calibrated as described in the documentation.

  • Page 73: Maintenance

    Maintenance Maintenance Topics Preventive maintenance, page 72 Corrective maintenance, page 77 Parts replacement, page 81 110-0080487/A...

  • Page 74: Preventive Maintenance

    Kongsberg ME70 Bathymetric Option Instruction Manual Preventive maintenance Topics Preventive maintenance schedule, page 73 Personnel for preventive maintenance tasks, page 74 Making sure that the environmental conditions in the sonar room meet the requirements, page 74 Inspecting and cleaning the display, page 75...

  • Page 75: Preventive Maintenance Schedule

    Maintenance Preventive maintenance schedule In order to secure a long and trouble-free operation of the ME70 Bathymetric Option system, certain specific preventive maintenance tasks must be done. The tasks are organized in a preventive maintenance schedule. The ME70 Bathymetric Option is a state of the art Multibeam scientific echo sounder. With the exception of the cabinet fans, there are no moving parts.

  • Page 76: Personnel For Preventive Maintenance Tasks

    Measure the ambient temperature in the room. Measure the relative humidity in the room. Compare the readings with the environmental requirements for the ME70 Bathymetric Option system. Make sure that neither the room itself nor any of the system units have been subjected to corrosive attacks.

  • Page 77: Inspecting And Cleaning The Display

    Maintenance Take the necessary corrective actions if the environmental conditions are poor. Inspecting and cleaning the display To ensure long and trouble-free operation of the display, it must be inspected and cleaned at regular intervals. Prerequisites No special tools are required for this task. You will however need a commercially available mild detergent and a lint free cloth.

  • Page 78: Inspecting And Cleaning The Hydrographic Work Station (Hws)

    Kongsberg ME70 Bathymetric Option Instruction Manual Procedure Make sure that the unit is kept clean and dry. Make sure that the unit is not exposed to excessive dust and vibrations. Check for physical damage to the cabinet and/or the cables.

  • Page 79: Corrective Maintenance

    Maintenance Corrective maintenance Topics Tools for corrective maintenance, page 78 Processing Unit corrective maintenance, page 79 110-0080487/A...

  • Page 80: Tools For Corrective Maintenance

    However, key components that fail will in most cases be detected by the tools you have available. The most important tool is your own knowledge about the ME70 Bathymetric Option. Based on a list of the main components in the system, brief descriptions of what they do and how they work, including suggested certain symptoms, you may work out the possible solutions.

  • Page 81: Processing Unit Corrective Maintenance

    For installation of a commercial computer, refer to the manual supplied by the manufacturer. Note Make sure that the chosen computer meets the ME70 Bathymetric Option requirements. The design and construction must allow for marine use, and the computer must be able to withstand the movements and vibrations normally experienced on a vessel.
  • Page 82 Kongsberg ME70 Bathymetric Option Instruction Manual Choose a position to fit the available cable lengths between the computer and the other units it connects to. Observe the compass safe distance. Make sure that enough space is made available for maintenance purposes.

  • Page 83: Parts Replacement

    Maintenance Parts replacement Topics Tools and equipment required for parts replacement, page 82 ME70BO processing unit – replacement, page 83 Hydrographic Work Station (HWS) – replacement, page 88 110-0080487/A...

  • Page 84: Tools And Equipment Required For Parts Replacement

    Kongsberg ME70 Bathymetric Option Instruction Manual Tools and equipment required for parts replacement To safely remove and replace printed circuit boards modules, generic and specific tools are required. You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electromechanical tasks.

  • Page 85: Me70Bo Processing Unit - Replacement

    The ME70BO Processing Unit is provided to process the depth information from the ME70 Processing Unit. This signal processing allows the seabed mapping functionality provided by the ME70.
  • Page 86 Refer to the detailed information in the Cable layout and interconnections chapter. Procedure Locate the unit you wish to remove. The ME70BO Processing Unit is usually installed in the ME70 transceiver cabinet. Turn off the ME70 Bathymetric Option. Disconnect the power cable on the rear side of the unit.
  • Page 87 ME70BO Processing Unit is usually installed in the ME70 transceiver cabinet. Prerequisites Unless specified in a contract, the 19" rack is not included in the ME70 Bathymetric Option delivery. The 19" rack must be provided and installed by the ship owner or the installation shipyard.
  • Page 88 Kongsberg ME70 Bathymetric Option Instruction Manual Context A suitable location for the ME70BO Processing Unit must be defined prior to installation. The unit can in principle be mounted anywhere on board the ship provided that the location is dry and ventilated.
  • Page 89 Maintenance Connect the cables. Note When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. 110-0080487/A...

  • Page 90: Hydrographic Work Station (Hws) - Replacement

    Kongsberg ME70 Bathymetric Option Instruction Manual Hydrographic Work Station (HWS) – replacement The Hydrographic Work Station is the operator station of the ME70 Bathymetric Option system. If the HWS fails to operate, it must be replaced with a new unit.
  • Page 91 The HWS can be installed inside a console, inside a suitable cabinet, in a 19" rack or on a desk. Turn off the ME70 Bathymetric Option. Disconnect the power cable on the rear side of the unit. Disconnect the cables.
  • Page 92 Kongsberg ME70 Bathymetric Option Instruction Manual Installing the Hydrographic Work Station If the Hydrographic Work Station fails to operate, it must be replaced with a new unit. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions.

  • Page 93: Technical Specifications

    Introduction to technical specifications, page 92 Performance specifications, page 92 Power requirements, page 94 Weights and outline dimensions, page 96 Environmental requirements, page 98 IP addresses in the ME70 Bathymetric Option system, page 100 Compass safe distance, page 101 Minimum display requirements, page 102 110-0080487/A...

  • Page 94: Introduction To Technical Specifications

    Kongsberg ME70 Bathymetric Option Instruction Manual Introduction to technical specifications These technical specifications summarize the main functional and operational characteristics of the ME70 Bathymetric Option Multibeam scientific echo sounder. They also provide information related to power requirements, physical properties and environmental conditions.
  • Page 95 Technical specifications – : Stabilized for roll and pitch Transmit – : Stabilized for roll and pitch Receive • : 3 - 600 m (Approximately) Depth range • : 0.384 + 0.768 ms (CW) Pulse length 110-0080487/A...

  • Page 96: Power Requirements

    ME70BO Processing Unit – power requirements, page 94 Display – power requirements Not applicable. The display is not a part of the ME70 Bathymetric Option scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.
  • Page 97 Technical specifications • : 15% Maximum voltage deviation • : 20% of nominal voltage, recovery time 3 seconds Maximum transient • : 200 VA (Approximately) Power consumption Related topics Power requirements, page 94 Technical specifications, page 91 110-0080487/A...

  • Page 98: Weights And Outline Dimensions

    MC330 Hydrographic Work Station – weights and outline dimensions, page 97 Display – weight and outline dimensions Not applicable. The display is not a part of the ME70 Bathymetric Option scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.

  • Page 99: Mc330 Hydrographic Work Station - Weights And Outline Dimensions

    Technical specifications MC330 Hydrographic Work Station – weights and outline dimensions • : MC330 Make and model • Outline dimensions – 520 – 742 mm Depth: – 483 mm Width: – 44.45 mm (1U) Height: • approximately 6.6 kg Weight: Related topics Technical specifications, page 91 110-0080487/A...

  • Page 100: Environmental Requirements

    ME70BO Processing Unit – environmental requirements, page 99 Display – environmental requirements Not applicable. The display is not a part of the ME70 Bathymetric Option scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.

  • Page 101: Me70Bo Processing Unit - Environmental Requirements

    Technical specifications Related topics Environmental requirements, page 98 Technical specifications, page 91 ME70BO Processing Unit – environmental requirements • : 0 °C – 50 °C Operating temperature • : -40 °C – 70 °C Storage temperature • : 5 – 95% (relative non‑condensing) Relative humidity Related topics Environmental requirements, page 98...

  • Page 102: Ip Addresses In The Me70 Bathymetric Option System

    IP addresses in the ME70 Bathymetric Option system The communication between the ME70 Bathymetric Option units is made using high speed Ethernet. Each port on each system unit has a dedicated IP address. The IP address for the Ship network depends on the installation and will vary.

  • Page 103: Compass Safe Distance

    ME70BO Processing Unit – compass safe distance , page 101 Display – compass safe distance Not applicable. The display is not a part of the ME70 Bathymetric Option scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.

  • Page 104: Minimum Display Requirements

    Kongsberg ME70 Bathymetric Option Instruction Manual Minimum display requirements Unless specifically ordered, the ME70 Bathymetric Option system is not provided with a display. The display must then be purchased locally. You can use one or two displays on your computer depending on personal and/or operational preferences.

  • Page 105: Equipment Handling

    The phrase box is used to describe all kinds of cases, wooden or cardboard boxes etc used to hold the unit. Topics Transporting Kongsberg Discovery equipment, page 104 Lifting units and transportation boxes, page 105 Inspection of units and transportation boxes after arrival, page 106...

  • Page 106: Transporting Kongsberg Discovery Equipment

    Kongsberg ME70 Bathymetric Option Instruction Manual Transporting Kongsberg Discovery equipment Unless otherwise stated in the accompanying documentation, electronic, electromechanical and mechanical units supplied by Kongsberg Discovery can be only transported using methods approved for delicate and fragile equipment. Prerequisites Transportation methods approved for delicate equipment includes transportation by road, rail, air or sea.

  • Page 107: Lifting Units And Transportation Boxes

    Handle all boxes and units with care. Note Due to the nature of Kongsberg Discovery’s products, and the extensive use of delicate electronic parts, all units and boxes must be regarded and handled as fragile equipment. Lifting units and transportation boxes Some of the boxes used to hold equipment units may be heavy.

  • Page 108: Inspection Of Units And Transportation Boxes After Arrival

    Handle all units and boxes with care. Note Due to the nature of Kongsberg Discovery’s products, and the extensive use of delicate electronic parts, all units and boxes must be regarded and handled as fragile equipment. Inspection of units and transportation boxes...

  • Page 109: Specifications For Storage Prior To Installation Or Use

    Equipment handling If units are not damaged, check the humidity absorbing material. If required, dry or replace the bags, then re-pack the unit(s) according to the packing instructions. Specifications for storage prior to installation or use Whenever a system, a unit or a spare part has been delivered, it may be subjected to long-time storage before installation and use.

  • Page 110: Unpacking Instructions

    Kongsberg ME70 Bathymetric Option Instruction Manual 10 Boxes must not be exposed to moisture from fluid leakages. 11 Boxes must not be exposed to direct sunlight or excessive warmth from heaters. 12 Boxes must not be subjected to excessive shock and vibration.

  • Page 111: Unpacking Standard Parts And Units

    Describe the damage, and collect photographic evidence if possible. Return the inspection report to Kongsberg Discovery as soon as possible. Place the box on a stable work bench or on the floor with the top of the box facing upwards.

  • Page 112: Unpacking Mechanical Units

    Kongsberg ME70 Bathymetric Option Instruction Manual In the absence of other instructions, always open the top of the carton first. The contents of the box will normally have been lowered into the carton from above, so this will usually be the easiest route to follow. Be careful when you open the box, and make sure that the contents are not damaged.
  • Page 113 Equipment handling Procedure Obtain the necessary lifting equipment, and make sure that the equipment is certified for the weight. Lift the unit out of the transportation box. Place it in a stable position on the floor/work bench. Inspect the unit for visual damage. Remove any packing material that may be inside the unit.

  • Page 114: Unpacking Electronic And Electromechanical Units

    Describe the damage, and collect photographic evidence if possible. Return the inspection report to Kongsberg Discovery as soon as possible. Assuming all is well, open the bag and remove the unit. Take out and keep the documentation.

  • Page 115: Specifications For Storage After Unpacking

    Do not break the seal to open a circuit board package before the board is to be used. If the board package is returned to Kongsberg Discovery with the seal broken, we will assume that the unit has been used and you will be billed accordingly.

  • Page 116: Packing Instructions For Storage Or Shipping

    Kongsberg ME70 Bathymetric Option Instruction Manual If a unit needs temperature protection, the box to be used for storage and transportation must be lined on all walls, base and lid, using minimum 5 cm thick polyurethane or polystyrene foam. Most system units can normally be stored in temperatures between -30° C and +70° C. Refer to the relevant technical specifications for details.

  • Page 117: Storage After Use

    Equipment handling Place the unit in a suitable cardboard box or wooden crate. Make sure that the unit is well be protected against physical damage by means of shock-absorbing insulation mats. Take the necessary precautions if the unit must be protected against high or low temperatures, and mark the box accordingly.
  • Page 118 Wipe clean all exposed cables, and check for damage. If a cable shows signs of wear or ageing, contact Kongsberg Discovery for advice. Check if the unit contains batteries. If the unit contains batteries, these may discharge slowly during storage. If the unit is to be stored for an extended period, disconnect or remove all internal batteries.

  • Page 119: Cleaning A Mechanical Or Electromechanical Unit

    Clean damaged or suspect areas, prepare and preserve these areas using the correct preservation mediums. Wipe clean all exposed cables, and check for damage. If a cable shows signs of wear or ageing, contact Kongsberg Discovery for advice. Secure and protect loose parts (shock absorbers, plug and sockets, protruding objects etc).
  • Page 120 - must take place according to national and international rules and regulations. Observe the relevant Waste Electrical and Electronic Equipment (WEEE) regulations. Product recycling service Kongsberg Discovery offers a product recycling service. See our website for more information. • https://www.kongsberg.com/maritime/services/product-recycling We accept all our products for recycling.
