ASSEMBLY INSTRUCTIONS
NEWPORT
VINYL PICKET
FENCE WITH POST
AND NO-DIG STEEL
PIPE ANCHOR KIT
(36" H X 72"W)
Approximate assembly time
Want to see a video on how to
assemble this product?
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
60 MIN
Scan the QR code
ASSEMBLY
ZP19002
ZP19002
Finishing Post
(ZP19003)
Kit
sold separately.
1
VER. 111424
Advertisement
Related Manuals for WamBam Newport ZP19002
Summary of Contents for WamBam Newport ZP19002
- Page 1 ZP19002 ASSEMBLY INSTRUCTIONS NEWPORT ASSEMBLY VINYL PICKET ZP19002 FENCE WITH POST AND NO-DIG STEEL PIPE ANCHOR KIT (36” H X 72”W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Finishing Post Scan the QR code (ZP19003) sold separately.
- Page 2 ZP19002 ASSEMBLY INSTRUCTIONS GENERAL INFORMATION MISSING DAMAGED PARTS? Visit Our Website so we can help you right away! parts.nychbrands.com You can also reach us via phone or email. Hours of Operation - Weekdays 9am-5pm EST To better help you, Your product number (ZP19002) please have the following Your original product box...
- Page 3 ZP19002 ASSEMBLY INSTRUCTIONS TIPS: It is extremely difficult to move pipe anchors once they are driven into the ground, so carefully planning and measuring your fence is essential. After you’ve installed your first fence panel and feel familiar with the process, you can opt to temporarily remove your fence panel and posts, and continue driving all of your pipe anchors.
- Page 4 ZP19002 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS 68 1/2 in 2 15/16 in 3 in 6 in 36 in 33 1/2 in 18 1/2 in 22 7/8 in 20 3/4 in 4 in Ground 2 in 24 in 70 3/8 in 72 in This fence can easily be trimmed down horizontally to fit your custom space.
- Page 5 ZP19002 ASSEMBLY INSTRUCTIONS MATERIALS LAY OUT Post Cap (1) Picket (11) Post (1) ⅞” x 3” x 29¾” 2” x 3½” x 38⅝” Note: Top rail has picket holes on both sides. Bottom Rail (1) Top Rail (1) Rail Bracket (4) 1½”...
- Page 6 ZP19002 ASSEMBLY INSTRUCTIONS PIPE ANCHORS INSTALL STEP 1 After establishing the placement of your fence, drive your first Pipe Anchor into the ground. The bottom of the plastic collar should sit just above the ground when finished. TOOL OPTIONS FOR DRIVING THE PIPE ANCHOR INTO THE GROUND: BETTER NOT RECOMMENDED BEST...
- Page 7 ZP19002 ASSEMBLY INSTRUCTIONS STEP 2 Note: Check level in both directions. Try and drive the pipe anchor as level as possible. Check level about every 12”. After about 18”, the trajectory of the pipe anchor is usually established, and you cannot manually pull the pipe back to make it level.
- Page 8 ZP19002 ASSEMBLY INSTRUCTIONS POST OVER PIPE ANCHOR INSTALL STEP 4 Orient the Post correctly with tabs at the top, and slide the post over the pipe anchor and into the ground. STEP 5 Using a wood block (or something to protect the top of the post), pound the post down another 2”...
- Page 9 ZP19002 ASSEMBLY INSTRUCTIONS POST TO PIPE ANCHOR (OPTIONAL): SECURE This step is only to be completed if you are concerned that Top View someone may pull your fence posts out of the ground. Drive a ¾” – 1¼” self-drilling hex head tek screw (NOT INCLUDED) through the post until it meets the pipe anchor and back the screw out of the post.
- Page 10 ZP19002 ASSEMBLY INSTRUCTIONS FENCE PANEL INSTALL STEP 6 Install one Rail Bracket on the post using (4) ¾” Self-Drilling Stainless Steel Screws (H). The rail bracket should be approximately 2” off the ground. 2 in STEP 7 Slide another rail bracket over the opposite end of the Bottom Rail (F), and slide the bottom rail down into...
- Page 11 ZP19002 ASSEMBLY INSTRUCTIONS STEP 8 Use a level on the top of the bottom rail to determine where to install the opposing rail bracket, and mark the height. STEP 9 Temporarily remove the bottom rail, and install the rail bracket using (4) ¾” self-drilling stainless steel screws.
- Page 12 ZP19002 ASSEMBLY INSTRUCTIONS STEP 8 Insert the bottom rail into the rail brackets. Measure 18½” from the top of the bottom rail bracket as illustrated below, and install the top rail brackets. 18 ½ in STEP 9 Make sure the bottom and top rails line up in order to align the pickets, and slide the Top Rail into the rail brackets.
- Page 13 ZP19002 ASSEMBLY INSTRUCTIONS PICKETS AND POST CAPS INSTALL STEP 6.1 Insert the Pickets through the top rail until they lock into the bottom rail. STEP 6.2 Install the Post Caps (A). Push down on the post cap to lock it onto the post.
- Page 14 ZP19002 ASSEMBLY INSTRUCTIONS INSTALLING BOTTOM FENCE BRACKETS AT A 90° ANGLE TIPS: TIP 1 Place the rail bracket on the post and mark the locations of the four holes on the post. STEP 7.2 Using a 1/8” drill bit for steel (NOT INCLUDED), pre-drill the post and internal pipe anchor. STEP 7.3 Secure each rail bracket with (4) 3/4”...
- Page 15 ZP19002 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
