PS-3225: Wireless Smart Gate Replacement Instructions
Battery part number PS-3297; Li-Poly 500 mAH
Recommended Equipment: (PS-3299; Battery Replacement Tool Set)
Step 1:
Position the unit as shown. Remove the 4 screws from the top of the unit with a
Phillips Screwdriver and separate the top half from the unit as shown below.
PASCO Form Number
Description
Date
Revision
013-17363
PS-3225 Battery Replacement Instructions
11-29-22
Page 1 of 3
A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PASCO PS-3225
Summary of Contents for PASCO PS-3225
- Page 1 PS-3225: Wireless Smart Gate Replacement Instructions Battery part number PS-3297; Li-Poly 500 mAH Recommended Equipment: (PS-3299; Battery Replacement Tool Set) Step 1: Position the unit as shown. Remove the 4 screws from the top of the unit with a Phillips Screwdriver and separate the top half from the unit as shown below.
- Page 2 Unplug the existing battery and replace with the new battery. Reposition the Printed circuit assembly back into the unit as shown below. Make sure the wiring is put back exactly as shown below. PASCO Form Number Description Date Revision 013-17363 PS-3225 Battery Replacement Instructions 11-29-22 Page 2 of 3...
- Page 3 If you need further assistance, please contact Technical Support at support@pasco.com through www.pasco.com on chat. To access chat through your browser, please enable all cookies on our website. PASCO Form Number Description Date Revision 013-17363 PS-3225 Battery Replacement Instructions 11-29-22 Page 3 of 3...
