PASCO PS-3234 Product Manual

Wir Wireless Spir eless Spirometer
PS-3234
Note: Note: This is not a medical device. It is designed for educational
use only and should not be used in any medical process such as life
support or patient diagnosis. It is also not intended for use in
graduate research or industry including industrial control or any
type of industrial testing.
Note: Note: Read the instructions before using this product. Students
should be supervised by their instructors. When using this product,
follow the instructions in this manual and all local safety guidelines
that apply to you.
Note: Do not share mouthpieces or filters. The mouthpieces Note:
and filters are intended for a single-use occasion, which may
include several tests with the same individual.
CAUTION: CAUTION: In medical settings, pulmonary function tests are
performed under the supervision of a medical professional. When
using a spirometer without medical supervision, use extra caution.
A person with a medical condition that may be affected by a
pulmonary function test should not use the PASCO Spirometer.
Discontinue use if the subject encounters breathing difficulty or
discomfort.
What' What's included s included
• Wireless Spirometer
• 3× Mouthpiece
• 3× Mouthpiece Filter
• USB Cable
ometer
F F eatur eatures es
7
1. Device ID Device ID
Use to identify the sensor when connecting using Bluetooth.
2. Bluetooth Status Light Bluetooth Status Light
Indicates the status of the Bluetooth connection.
L L
IGHT
Red, blink
Green, blink
Yellow, blink
3. USB Port USB Port
Use with the USB cable to connect to a USB wall charger to charge
the battery. Also use to send measurement data to software
when connected to a USB port of a computer or mobile device
(iOS devices not supported).
4. Power Button Power Button
Press and hold for one second to turn the sensor on or off.
5. Battery Status Light Battery Status Light
Indicates the battery level and charging status.
L L
IGHT
Red, blink
Green, solid
Yellow, solid
6. Threaded Hole Threaded Hole
Use for mounting the sensor, such as to a mounting rod. Accepts
1/4-in–20 screws.
7. Handle Handle
Attach the mouthpiece to the handle. Hold the handle upright
and steady while collecting data.
Product Guide
012-16752A
1 2
123-456
6 5
S S
TATUS
Ready to pair
Paired
Remotely logging data
S S
TATUS
Low battery level
Fully charged
Charging
Wireless Spirometer | 1
3
4
