Vertiv GXE3-1000IRT2UXL Quick Installation Manual

Vertiv™ Liebert® GXE UPS 1-3 kVA; 230V IN/OUT
GXE3-1000IRT2UXL, GXE3-1500IRT2UXL, GXE3-2000IRT2UXL, GXE3-3000IRT2UXL
Quick Installation Guide
IMPORTANT: Before installing, connecting to supply, or operating the Vertiv™ Liebert® GXE UPS, refer to the SL-55024 Safety
and Regulatory Statements Sheet. For detailed installation, operation, maintenance, and troubleshooting information, refer to
the Vertiv™ Liebert® GXE User Guide available at
Items Included in the Package
PROPRIETARY AND CONFIDENTIAL ©2023 VERTIV GROUP CORP.
Thank you for your recent purchase of a Vertiv UPS! We appreciate your business and are
confident that your new product will provide many years of uninterruptible power to your
connected equipment. With this purchase, you may also want to consider Vertiv's complete
line of racks, PDUs, thermal solutions, KVM switches, and serial consoles. If you require any
assistance or support, please don't hesitate to reach out to one of our resellers, local
representative firms, or refer to Vertiv contacts listed at the end of this document. We stand
ready to support you. We sincerely hope that you'll continue to select Vertiv for all of your
future infrastructure needs!
The Vertiv Team
www. V ertiv.com.
No.
1 Quick installation guide
2 4-post rack mounting kit (1U)
3 Rack mounting ears (left-right)
4 Foot stand (left-right)
5 Mounting hardware
6
4-post rack mounting kit — Quick installation guide
7 Safety and regulatory statements sheet
8 Factory test report
9 Schuko to IEC60320 C13 input power cable
10 Bristish to IEC60320 C13 input power cable
11 AUS to IEC60320 C13 input power cable
12 IEC60320 C13 to C14 output power cable
13 USB 2.0 A to B cable
NOTES
1. For items 9, 10, 11 power cables will be C19 for 2-3kVA.
2. There are two output power cables in 2-3kVA, 1-1.5kVA has one.
Items Quantity
1
1
1
2
26
1
1
1
1
1
1
See notes
1
SL-71081_REVA_09-23 1
