Vertiv™ Liebert® GXE UPS 1-3 kVA; 230V IN/OUT
GXE3-1000IMT, GXE3-1500IMT, GXE3-2000IMT, GXE3-3000IMT
Quick Installation Guide
IMPORTANT: Before installing, connecting to supply, or operating Vertiv™ Liebert® GXE UPS, refer to the SL-55024 Safety and
Regulatory Statements Sheet. For detailed installation, operation, maintenance, and troubleshooting information, refer to the
Vertiv™ Liebert® GXE User Guide available at
Items Included in the Package
PROPRIETARY AND CONFIDENTIAL ©2023 VERTIV GROUP CORP.
Thank you for your recent purchase of a Vertiv UPS! We appreciate your business and are
confident that your new product will provide many years of uninterruptible power to your
connected equipment. With this purchase, you may also want to consider Vertiv's
complete line of racks, PDUs, thermal solutions, KVM switches, and serial consoles. If you
require any assistance or support, please don't hesitate to reach out to one of our
resellers, local representative firms, or refer to Vertiv contacts listed at the end of this
document. We stand ready to support you. We sincerely hope that you'll continue to
select Vertiv for all of your future infrastructure needs!
The Vertiv Team
www. V
ertiv.com.
NOTES
1.
2.
No.
1
Quick installation guide
2
Safety and regulatory statements sheet
3
Factory test report
4
Schuko to IEC60320 C13 input power cable
5
Bristish to IEC60320 C13 input power cable
6
AUS to IEC60320 C13 input power cable
7
IEC60320 C13 to C14 output power cable
8
USB 2.0 A to B cable
For items 4, 5, 6 power cables will be C19 for 2-3kVA.
There are two output power cables in 2-3kVA, 1-1.5kVA has one.
Items
Quantity
1
1
1
1
1
1
See notes
1
SL-71079_REVA_09-23 1
