- Page 1 QDB13S Operations & Maintenance Manual Electric Stacker EB14C-98LI/EB14C-118LI/EB14C-138LI/EB14C-145LI/ EB14CS-118LI/EB14CS-138LI/EB14CS-145LI/ EB14C/EB14C-138...
-
Page 2: Table Of Contents
Catalogue 1. Main parts overview ................2 2. External drawing .................. 3 3. Main technical parameters ..............3 4. Purpose and scope of use ..............5 5. Instructions for use and operation ............5 6. Use and maintenance of batteries ............8 7. -
Page 3: Main Parts Overview
1.Main parts overview Item no. Description Item no. Description Fork Handle Loading wheel Drive wheel Inner mast Balance wheel Outer mast Battery Oil pump Emergency stop button Mesh guard... -
Page 4: External Drawing
2.External drawing Figure 1-1... -
Page 5: Main Technical Parameters
3. Main technical parameters EB14CS EB14C Model number (Side Shift) Driving mode Electric (battery) Trait Driving mode WALKIE Rated load Q(lbs.) 2860 c(in) Load center distance Lifting height h3(in) 98/118/138/145 118/138/145 81.6/91.5/95.4 Height when mast is lowered h1(in) 75.2/85/94.8/98.81 147.2/167/174. Maximum vehicle height h4(in) 127.5/147.2/167/174.8... -
Page 6: Purpose And Scope Of Use
4.Purpose and scope of use The electric straddle stacker is powered by a battery and features a DC drive system for electric walking and lifting. It is designed to be labor-saving, lightweight, efficient, stable, simple to operate, safe, reliable, low-noise, and environmentally friendly. Use environment: a. - Page 7 Fault light Charging plug Emergency stop USB charging port Charging light Fig 2-1 5.2. Forward and reverse driving The flower-shaped turning knob, located above and to the left of the rudder handle, is used for speed control. It can be operated using the left-hand thumb or the right-hand fingers, either individually or simultaneously, as shown in Figure 2-2.
- Page 8 5.3 Emergency Reverse Switch The red button located at the top of the rudder handle serves as the emergency reverse switch, as shown in Figure 2-3. When this switch is activated, the vehicle will immediately reverse direction. Horn Emergency reverse switch Rise and fall...
-
Page 9: Use And Maintenance Of Batteries
Figure 2-5 6. Use and Maintenance of Batteries Timely Charging: Ensure the battery is fully charged regularly. Avoid letting the battery drain completely before charging, as excessive discharge can damage the battery. Connection Check: Frequently inspect the battery connections to ensure they are secure, and the terminal surfaces are clean for proper contact. -
Page 10: Possible Faults During Use And Troubleshooting Methods
improperly. Possible faults during use and troubleshooting methods Table 2 shows common troubleshooting methods for reference in fault diagnosis and maintenance. Breakdown Cause analysis Elimination method The meter does not display The 10A fuse on the panel of the after the power switch is turned electrical box is blown or the Replace the fuse or power switch. - Page 11 9.11 Do not place any part of your body under heavy objects or forks! 9.12 The stacker is suitable for use on flat surfaces or flat work platforms. Long-term parking on slopes is strictly prohibited. Do not perform high-altitude or heavy-duty operations on uneven terrain. 9.13 Overloading or driving on inclines is strictly prohibited.
-
Page 12: Electrical Schematic Diagram
10.Electrical schematic diagram... -
Page 13: Hydraulic Schematic Diagram
11. Hydraulic schematic diagram 1. oil tank 2. oil filter 3. DC motor 4. gear oil pump 5. relief valve 6. check valve 7. Electromagnetic reversing valve 8. built-in balancing valve 9. cylinder...
