- Page 2 Thank you for choosing the Hogtunes Wild Boar Audio WBA Retro Lid Kit for 2014-2023 Touring Models. Since positive word of mouth is the best way to grow our business, we want your new system to work as well as it was designed to.
- Page 3 **IF THIS IS THE THIRD AMP GOING ON THE BIKE If the amp in this kit is the third amp going in the bike, Hogtunes FLH Side Plate-RM is required to mount this amp. Follow the instructions that came with FLH Side Plate-RM to get this amp mounted.
- Page 4 **IF THIS IS THE THIRD AMP GOING ON THE BIKE If the amp in this kit is the third amp going in the bike, Hogtunes FLTR Side Plate-RM is required to mount this amp. Follow the instructions that came with FLTR Side Plate-RM to get this amp mounted.
- Page 5 Makes For a Cleaner Install. Leave the power and ground wires near the battery but don’t hook up just yet. Leave the end of the lid harness just behind the battery area for now. WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 6 3/4” (19mm) hole will be drilled. This hole is where the supplied Hogtunes rubber grommet will go (later in this install) to allow the speaker wire to pass in/out of the saddlebag. We strongly suggest putting masking tape over the painted area to be drilled.
- Page 7 Remove the T15 screw that holds the opening handle in place and pull the handle away from the factory lid. Remove the last 4x T15 screws securing the large latching mechanism to the underside of the factory lid. This entire mechanism is now removed. WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 8 DON’T KEYHOLE HAVE MASKING TAPE COVER THE DRILL CUT LINE 8” Figure 1.4 Figure 1.3 Underside of Template With Masking Underside of Template Tape Applied Around Perimeter No Masking Tape WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 9 Once you are satisfied the grill fits nicely in the opening, you can start to re-install the latching mechanism. See the passive crossover information on the next page before completing reinstallation of the latching mechanism. WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 10 The factory cloth tether will also be re-installed at this time. Figure 1.2 Figure 1.3 below shows the crossover correctly oriented. Figure 1.3 WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 11 Using hand tools, get each screw started. Once started, tighten each one down till they “stop”. They don’t need to be any tighter than that and will damage the rubber washer and cause leaking. WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 12 Note: we tooled in a “plug” in the center of the grommet that can be easily pulled out in case you have other wires going into the saddlebags for WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 13 Before re-installing outer fairing, turn front wheel to each extreme side making sure any wiring is not impeding the steering of the motorcycle. Failure to do so can result in serious injury or death! WILD BOAR AUDIO WBA RETRO LID KIT...
- Page 14 Inside the WBA 2694 box, there are 2 Wild Boar Audio metal badges that are meant to replace the Hogtunes badges that come on the Retro Lid-RM grills. Use a pick tool or something similar to carefully pry the 2 way tape on the Hogtunes badges off.
-
Page 15: Warranty Information
Please contact Hogtunes head office for all warranty claims. Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at Hogtunes sole discretion. Hogtunes/Wild Boar Audio’s complete warranty policy is available on our website at www.hogtunes.com... - Page 16 Hogtunes products will play much louder than the Original Equipment, which can be a distraction to the rider and/or passenger. Please use caution when adjusting, or playing your stereo at high volume, ESPECIALLY IN TRAFFIC. You are a valued customer so please:...
