Page 2: Getting Started
Thank you for choosing Wild Boar Audio’s WBA FLHT-BT KIT. We want your new system to work as well as it was designed to, so if you have any questions or concerns, please email: techsupport@hogtunes.com or call us during regular business hours at 705-719-6361 (EST). If you still need help, please consider a professional installation by your dealer. - Page 3 locations are common for both brake and clutch side cabinets. In Fig 1.1 you will see where the speaker wire exits the cabinets. The 3 cabinet fasteners below the speaker wire are 7/16” heads that will also accept a 3/16” allen head. A “ratcheting box end” or “ball end” allen wrench will make removing these 3 fasteners much easier! Step #5: With the cabinet removed from the bike, take a WBC 1654 speaker,...
-
Page 4: Mounting The Amplifier
MOUNTING THE AMPLIFIER MOUNTING THE AMPLIFIER MOUNTING THE AMPLIFIER On the top of where a radio would normally go, you will see a fairly flat plane as part of a metal “framework.” This is where the amplifier will be mounted. •... - Page 5 WIRING THE AMPLIFIER WIRING THE AMPLIFIER WIRING THE AMPLIFIER Step #1: There is a male audio plug on the wiring for the WBA-BT (Bluetooth piece) that needs to plug into the female audio plug on the amp. Make sure this is plugged in all the way. Locate the amplifier power harness, and plug it into the amp, letting the rest of this harness hang for now.
- Page 6 OPERATING THE OPERATING THE OPERATING THE WBA- - BT CONTROLLER WBA-BT CONTROLLER BT CONTROLLER PAIRING WBA-BT TO YOUR WIRELESS DEVICE WBA-BT is always discoverable and requires no 4 digit code. With WBA-BT powered on, you will see a flashing blue led. When the light is flashing, WBA-BT is not paired to any device.
- Page 7 AUX IN Tapping the main control knob twice (fairly quickly) allows music be heard through something plugged into the Aux In cable from a peripheral device such as a GPS or satellite radio. When WBA-BT is in AUX mode, the AUX light (circle with arrow) will illuminate.
-
Page 8: Warranty Info
What Is Not Covered: 1) Any expense related to the removal or re-installation of products. 2) Repairs to these products performed by anyone other than Hogtunes, Inc. 3) Subsequent damage to any other components. 4) Any product purchased from a non-authorized Wild Boar Audio dealer.
