- Page 2 IMPORTANT NOTES The factory saddlebag hinges limit the size of speaker magnet that can be used and allow the lids to open and close without issue. Hogtunes assumes ZERO RESPONSIBILITY for fitment issues, or water leaks when any speaker brand other than Hogtunes are used.
- Page 3 The supplied grommet in Fig 1.2 is “split” to make the install much easier once the wire is in the bag. The white circle in the picture shows a “plug” that can easily be removed. If the only wire you have going into your saddlebag is the speaker wire, leave the plug in place.
- Page 4 All fasteners should be installed with HAND TOOLS ONLY! The large latching mechanism just removed will now be installed into the Hogtunes lid using the factory screws just removed. You will need to jostle the mechanism gently to get it in place.
- Page 5 Press the filler piece into the lid as shown by the large circle in Fig 1.5. With the filler piece in place, take another black gummy strip and tear off 2 short strips about 3/8” (9mm) each. Squish each piece across the small seam where the filler piece meets the lid on the plane the speaker will sit on as shown by the small circles in Fig 1.5.
- Page 6 The 4 pin connector will plug into any Hogtunes “REV” series amp, or any Hogtunes 4 Channel amp. If your using another brand of amp, you will see that the wires near the 4 plug are labeled. Simply cut the plug off and wire the lids to...
- Page 7 Harley-Davidson, Electra Glide, Road Glide, Street Glide, Ultra Classic, Tri Glide, CVO, Screamin Eagle and Tour-Pak® are Trademarks, and/or Registered Trademarks of Harley-Davidson, Inc., Milwaukee, Wisconsin, USA, and if Used or Implied are for Reference Only. There is No Affiliation Between Harley-Davidson, Inc., and Hogtunes Inc.
- Page 8 WARRANTY INFO WARRANTY INFO Hogtunes HT LID-RM are warranted against defects out of the box only. Proof of purchase is required for all warranty claims. The warranty applies to the original retail customer, and is not transferable. Please visit www.hogtunes.com for more information or to start a warranty claim.
