Hogtunes 362F-RM Installation Manual

Road Glide Specific Front Speaker Instructions:

Make sure your ignition stays in the off position! Each factory speaker grill can
pry off from the front using your fingers or a tool can be used to pry the grill
out, but be careful not to damage your inner fairing when doing so! With the
grill off, remove the 4 screws that hold the speaker to the bike. Carefully pull
speaker away from the fairing and undo the factory wires from the speaker.
Take a new speaker and attach the wires noting they will only go on one way.
You will have to work the speaker around tabs etc. to get it properly positioned.
NOTE: The speaker must be oriented so the speaker wires are in the 12 o'clock
(top) position. Damage will occur if the wires are in the 6 o'clock position!
With the wires in the 12 o'clock position, secure the new speaker into place
using the factory screws. When both sides are complete, verify both speakers
are working and re-install the grills. Your new speakers can now be enjoyed!

Warranty Information:

IMPORTANT: In the event of a warranty claim, please fill out the form in the Warranty
section of our website, or contact us by email or by phone. Valid claims will have an
Return Authorization Number (RA#) generated which MUST appear on the
outside of the box when it arrives to our offices.
Goods Arriving Without an RA# Will Be Refused!
Hogtunes speakers are warranted for a period of 20 years to the original
purchaser. Proof of purchase is required for all warranty claims. Please contact
Hogtunes for all warranty claims. Products found to be defective during the
warranty period will be repaired or replaced (with a product deemed to be
equivalent) at Hogtunes sole discretion. Hogtunes complete warranty policy is
available on our website at www.hogtunes.com/warranty.html
What Is Not Covered:
1) Any expense related to the removal or re-installation of these speakers.
2) Repairs to these speakers performed by anyone other than Hogtunes Inc.
3) Subsequent damage to any other components.
4) Any product purchased from a non-authorized Hogtunes dealer.
5) Damage to speakers from an accident or collision.
6) Damage from incorrect installation, improper use, abuse or modifications.
7) Damage to inbound product due to improper packing.

Technical Stuff

Power Handling:
Frequency Response:
Sensitivity:
Nom. Impedance :
125 RMS-200 Peak
55hz-25Khz
92 db 1watt/1meter
2 Ohms
HOGTUNES
Audio Solutions For The Great American Cruiser
Designed and Engineered in North America
Replacement Speaker
Installation Manual
Models 362F-RM & 362R-RM
The Speakers In This Kit Are 2 Ohms And Are
Made Specifically For Rushmore
Road Glide Specific Instructions
Are On The Back Cover
Rev 1.3
