Page 2: Getting Started
Gently pull the stock speaker out of each grill assembly. Step #4: “Clip” the Hogtunes front speakers (Model 352F-AA) into each grill assembly. Position your new speaker/grill assembly onto the inner fairing and re-attach each one using the OE screws. Although a hand screwdriver is recommended for this step, make sure these screws are tight! Let the factory speaker wires hang for now. - Page 3 Step #6: Locate the “Fader/No Fader” switch on the side of the amp and make sure it is in the “Fader” position. In this position, the amplifiers front and rear channels are controlled independently by the Ultra radios built in fader.
- Page 4 Side Plate Module Shelf Side Stove Plate Bolt Head wiring the ampliFier Step #1: With amplifier in place, take the yellow/black wires on the input connector of the amplifier and plug them into the front factory speaker wires on the clutch side of the bike. They will only go in one way. Take the brown/black wires on the “front out”...
- Page 5 Take a Hogtunes rear speaker (model 352R-AA) and plug the female connectors of the amp harness into the speaker. They will only go one way.
- Page 6 If using LED Brake Light and/or Turn Signal Modules on your bike, Hogtunes recommends the “Spread Spectrum” Signal Stabilizers from Custom Dynamics for noise ®...
-
Page 7: System Upgrade
#1 The Hogtunes HF-1 tweeter pod not only looks great, it’s easy to install and brings ANY audio system to the next level! Adding these tweeters to any system “fixes” the inherent audio issues created by the stock speaker locations and will give much better clarity, especially at speed. - Page 8 system upgrade #2 As per the manual, the amp powers the front speakers (and tweeter pod if present) and rear speakers. In this upgrade, the rear speakers will be run off the radios built in power. The front channels of the amp will power the front speakers and the rear channels of the amp will be used to power 692.2/Lid 6x9 lid speakers or FL-7W 7”...
- Page 9 (and tweeter pod if present) buts adds a Hogtunes REV 225-AA amplifier to power a set of Hogtunes 692.2/Lid saddlebag lid speakers or a set of FL-7W 7” woofers for the fairing lower glove boxes. This can be done at any time, all bolt in &...
-
Page 10: Warranty Information
Warranty InformatIon please record Your amplifier’s Serial # Here_________________________ Hogtunes speakers are warranted for a period of 20 years. The REV 450-AA Amplifier is warranted for 3 years from original purchase date. Proof of purchase is required for all warranty claims. The warranty applies to the original retail customer and is not transferable. -
Page 11: Technical Specifications
Harley-Davidson, Electra Glide, Road Glide, Street Glide, Ultra Classic, Tri Glide CVO, Screamin Eagle and Tour-Pak® are Trademarks, and/or Registered Trademarks of Harley-Davidson, Inc., Milwaukee, Wisconsin, USA, and if Used or Implied are for Reference Only. There is No Affiliation Between Harley-Davidson, Inc., and Hogtunes Inc. - Page 12 Any audio system can be a distraction to the rider and/or passenger. Please use caution when playing your stereo, ESPECIALLY IN TRAFFIC. www.hogtunes.com...
