Homelegance 2320K-1 Assembling Instructions

* DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED
2320K-1 PARTS LISTS
NO. SKETCH DESCRIPTION
A
Headboard
2320K-3 PARTS LISTS
NO.
DESCRIPTION
SKETCH
B
RSF Side Rail
C
LSF Side Rail
D
Footboard
E
Slat Support Leg
F
Slat Roll
MADE IN VIETNAM / FABRIQUÉ AU VIETNAM
ASSEMBLING INSTRUCTIONS
ITEM NO.:
2320K-1
2320K-3EK Eastern King Footboard with Rails & Slats
Thank you for purchasing this product. Please take time to read and follow the instructions below.
Check that you have all parts and hardware before assembly. Parts apparently missing are often found
in the packing materials. If you do not have all the parts listed, have your dealer contact us and they be
sent to you immediately.
It is recommended to install protective pads under all legs and support to avoid damage or
scratches when placing furniture on a wood floor or orther hard surface, and to limit Indentation
and prevent discoloration if placing on carpet.
QTY NO.
SKETCH
1 PC 1
2
3
QTY
1 PC
4
1 PC
5
1 PC
6
* ABOVE HARDWARE ARE PACKED IN 2320K-3
10 PCS
FOR ASSEMBLY
1 ROLL /
13 PCS
California/Eastern King Headboard
HARDWARE LISTS
DESCRIPTION
Full - Thread Bolt
Curve Washer
Hex Nut
Screw
Open Wrench
Screwdriver
QTY
SIZE
Ø5/16 " x 2-3/16"
8 PCS
Ø5/16" x 1-3/16" 8 PCS
Ø5/16" 8 PCS
#4 x 1-3/16" 26 PCS
1 PC
Not Provided
Page: 1/4
