Homelegance 2319K-1 Assembling Instructions

* DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED
2319K-1 PARTS LISTS
SKETCH
NO. DESCRIPTION
Headboard
A
2319K-3EK PARTS LISTS
NO.
SKETCH DESCRIPTION
RSF Side Rail
B
LSF Side Rail
C
Footboard
D
E Slat Support Leg
Slat Roll
F
MADE IN VIETNAM
ASSEMBLING INSTRUCTIONS
ITEM NO.:
2319K-1
2319K-3EK Eastern King Footboard with Rails & Slats
Thank you for purchasing this product. Please take time to read and follow the instructions below.
Check that you have all parts and hardware before assembly. Parts apparently missing are often found
in the packing materials. If you do not have all the parts listed, have your dealer contact us and they be
sent to you immediately.
It is recommended to install protective pads under all legs and support to avoid damage or
scratches when placing furniture on a wood floor or orther hard surface, and to limit Indentation
and prevent discoloration if placing on carpet.
NO. SKETCH
QTY
1 PC 1
2
3
QTY
1 PC
4
1 PC
5
1 PC
6
10 PCS
* ABOVE HARDWARE ARE PACKED IN 2319K-3EK FOR
ASSEMBLY
1 ROLL/
13 PCS
California/Eastern King Headboard
HARDWARE LISTS
DESCRIPTION
Ø5/16 " x 2-3/16"
Full - Thread Bolt
Curve Washer Ø5/16" x 1-3/16"
Hex Nut
Ø5/16"
Screw #4 x 1-3/16"
Open Wrench
Screwdriver Not Provided
SIZE QTY
8 PCS
8 PCS
8 PCS
26 PCS
1 PC
Page: 1/4
