ASSEMBLY INSTRUCTIONS
5pcs Pack Counter Height Set
Ant Oak Finish
This page lists all the contents included in the box. Please take the time to identify
the hardware as well as the individual components to this product. As you unpack
and prepare for assembly, place the contents on a carpeted or padded area to
protect them from damage.
c l e a n i n g & c a r e
Treat surface with care. Clean surfaces with a dry or
damp soft cloth. Do not use abrasive cleaners. Hardware may loosen over time.
Periodically check that all connections are tight.
A Phillips head screwdriver is necessary for assembly.
