Homelegance 2319F-1 Assembling Instructions

* DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED
2319F-1/ 2319-1 PARTS LISTS
NO. SKETCH
DESCRIPTION
A Headboard
2319F-3/ 2319-3 PARTS LISTS
NO.
SKETCH DESCRIPTION
B
RSF Side Rail
LSF Side Rail
C
D
Footboard
Slat Support Leg
E
F Slat Roll
MADE IN VIETNAM
ASSEMBLING INSTRUCTIONS
ITEM NO.:
2319F-1 Full Headboard
2319-1 Queen Headboard
2319F-3 Full Footboard with Rails & Slats
2319-3 Queen Footboard with Rails & Slats
Thank you for purchasing this product. Please take time to read and follow the instructions below.
Check that you have all parts and hardware before assembly. Parts apparently missing are often found
in the packing materials. If you do not have all the parts listed, have your dealer contact us and they be
sent to you immediately.
It is recommended to install protective pads under all legs and support to avoid damage or
scratches when placing furniture on a wood floor or orther hard surface, and to limit Indentation
and prevent discoloration if placing on carpet.
NO.
SKETCH
QTY
1 PC 1
2
3
QTY
1 PC
4
1 PC
5
1 PC
6
5 PCS
* ABOVE HARDWARE ARE PACKED IN 2319-3/ 2319F-3
FOR ASSEMBLY
1 ROLL/
13 PCS
HARDWARE LISTS
DESCRIPTION
Full - Thread Bolt Ø5/16 " x 2-3/16"
Curve Washer
Ø5/16" x 1-3/16"
Hex Nut Ø5/16"
Screw #4 x 1-3/16"
Open Wrench
Screwdriver Not Provided
SIZE
QTY
8 PCS
8 PCS
8 PCS
26 PCS
1 PC
Page: 1/4
