Quick Install Guide
Package content and Prerequisites
AudioPoint 3.0 Encoder
Power supply
RCA / cinch cable
Ethernet cable (not included)
Headset (not included, recommended)
Safety Precautions
Copy to clipboard
Please make sure to first read the safety information in order to avoid
Setup the Device
Step 1
Connect the AudioPoint to your network or WiFi-Router using a standard ethernet cable. Be aware that the AudioPoint only works in the same network than
the WiFi devices.
AudioPoint 3.0 Doc Current:Quick Install Guide
hazards.
Advertisement
Related Manuals for BARIX AudioPoint 3.0
Summary of Contents for BARIX AudioPoint 3.0
- Page 1 AudioPoint 3.0 Doc Current:Quick Install Guide Quick Install Guide Package content and Prerequisites AudioPoint 3.0 Encoder Power supply RCA / cinch cable Ethernet cable (not included) Headset (not included, recommended) Safety Precautions Copy to clipboard Please make sure to first read the safety information in order to avoid hazards.
- Page 2 Step 2 Connect your audio sources (up to two per unit) to the RCA interfaces. Since the AudioPoint can only stream mono audio to the listeners mobile phone, both interfaces work independently. They will show up as two seperate channels on the Mobile Phone.
- Page 3 Step 3 Connect a headset to the connector on the front panel to listen to the IP-Address of the device.
- Page 4 Step 4 Connect the power supply to the device and then to an appropriate electrical source. While the device is booting you should hear the IP-Address announced at startup (DHCP by default). You can connect to the device by putting the IP-Address into a Browser as described later at the configuration part.
- Page 5 When LED1 becomes solid green, the system is up and running.
- Page 6 After Powering the device, download the App for receiving the AudioPoint stream. Barix recently released a new developed App with a new Design named AudioPoint. For compatibility to older devices, the old AudioSignage app is still available (not maintained anymore)! AudioPoint App: https://apps.apple.com/ch/app/audiopoint/id1508163144...
-
Page 7: Change The Channel Settings
Copy to clipboard The Barix AudioPoint Device is preconfigured to work on both RCA Connectors out of the Box! To change one of them, enter the CONFIGURATION tab, select your channel and click on Edit Channel. A new window will pop up with all the possible settings, the most important one are.. - Page 8 Click on Update Channel, when you are done with your changes. After the Configuration window is closed click on apply for the changes to take effect! Reset Through the Web UI Access the Web UI with the password on the back of the device. Go to the DEFAULTS tab and click on Factory defaults. The device will reboot and the settings are on default.
- Page 9 Compliance and further Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 10 Privacy Policy. Please follow Safety and Precaution Recommendations. Barix is a ISO 9001:2015 certified company. All rights reserved. All information is subject to change without notice. All mentioned trademarks belong to their respective owners and are used for reference only.
